Peugeot 2008 (2016 year). Instruction - part 24

01-16

Automobiles PEUGEOT declares, by
application of the provisions of the European
legislation (Directive 2000/53) relating
to End of Life Vehicles, that it achieves
the objectives set by this legislation and
that recycled materials are used in the
manufacture of the products that it sells.

Printed in the EU

Reproduction or translation of all or part of
this document is prohibited without written
authorisation from Automobiles PEUGEOT.

Anglais

Labels are applied at various
points on your vehicle. They carry
safety warnings as well as vehicle
identification information. Do not
remove them: they form an integral
part of your vehicle.

Anglais

AN. 16288.0040

www.peugeot.com

170

Practical information

2008-add_en_Chap09_info-pratiques_ed01-2016

  Low  fuel  level

 When the low fuel level is reached
this warning lamp comes on in the
instrument panel. There remains

approximately 5 litres  of fuel in

the tank. When the warning lamp
flashes, there is

very little fuel left .

  The key cannot be removed from the
lock until the cap is refitted.
 Removing the filler cap may cause an
inrush of air. This vacuum is perfectly
normal and results from the sealing of
the  system.

                   Fuel  tank

  Fuel tank capacity: approximately

50 litres   ( 45 litres  for the BlueHDi Diesel engine).

1.   Open the filler flap.

2.   Remove the filler cap.

3.   Hook  the  filler  cap.

  Refuelling

  To fill the tank safely:




the engine must be switched off,



   open the fuel filler flap

1 ,



   insert the key in the cap

2 , then turn it to

the left,

      With Stop & Start, never refuel with the
system in STOP mode; you must switch
off the ignition with the key.



   remove the cap and hook it onto the clip

located on the inside of the flap

3 ,



   fill the tank,

but do not continue after the

3rd cut-off of the pump ; this could cause

malfunctions.

 You must refuel as soon as possible to avoid
running out of fuel.
 For more information on

Running out of fuel

(Diesel) , refer to the corresponding section.

  A self-adhesive label on the inner face of the
filler flap reminds you of the type of fuel to use
depending on your engine.
 Additions of fuel must be of at least 5 litres to
be registered by the fuel gauge.

171

9

Practical information

2008-add_en_Chap09_info-pratiques_ed01-2016

  Fuel  supply  cut-off

 Your vehicle is fitted with a safety system that
cuts off the supply of fuel in the event of an
impact.

 When you have filled the tank:


   put the cap back in place,



   turn the key to the right, then remove it

from the cap,



   close  the  flap.

If you have put in the wrong fuel for

the engine of your vehicle, you must

have the fuel tank drained and filled

with the correct fuel before starting

the engine.

26

Monitoring

2008-add_en_Chap01_controle-de-marche_ed01-2016

Warning / indicator lamp State

Cause

Action / Observations

Engine oil

pressure

  fixed.

 There is a fault with the engine
lubrication system.

 You must stop as soon it is safe to do so.
 Park, switch off the ignition and contact a PEUGEOT
dealer or a qualified workshop.

Battery charge  *

  fixed.

 The battery charging circuit has a
fault (dirty or loose terminals, slack or
cut alternator belt, ...).

 The warning lamp should go off when the engine is
started.
 If it does not go off, contact a PEUGEOT dealer or a
qualified workshop.

Low fuel level

  fixed with the needle
in the red zone.

 There remains approximately

5 litres

of fuel in the tank.
At this point, you begin to use the fuel
reserve.

 Refuel as soon as possible to avoid running out of
fuel.
This warning lamp will come on every time the ignition
is switched on, until a sufficient addition of fuel is
made.
 Fuel tank capacity: approximately

50 litres   ( 45 litres

for the BlueHDi Diesel engine).
 Never continue to drive until you run out of fuel, as
this could damage the emission control and injection
systems.

  flashing  with  the
needle in the red
zone.

 There remains very little fuel in the
tank.

Under-inflation

  fixed.

 The pressure in one or more wheels
is too low.

 Check the pressure of the tyres as soon as possible.
This check should preferably be carried out when the
tyres are cold.

  +

  flashing  then  fixed,
accompanied by the
Service warning lamp.

 The tyre pressure monitoring system
has a fault or no sensor is detected
on one of the wheels.

 Under-inflation detection is not assured.
 Have the system checked by a PEUGEOT dealer or a
qualified workshop.

  *   Depending on the country of sale.

1

1

Monitoring

2008-additif_en_Chap01_controle-de-marche_ed01-2016

State

Cause

Action / Observations

Engine oil

pressure

  fixed.

 There is a fault with the engine
lubrication system.

 You must stop as soon it is safe to do so.
 Park, switch off the ignition and contact a PEUGEOT
dealer or a qualified workshop.

Battery charge  *

  fixed.

 The battery charging circuit has a
fault (dirty or loose terminals, slack or
cut alternator belt, etc.).

 The warning lamp should go off when the engine is
started.
 If it does not go off, contact a PEUGEOT dealer or a
qualified workshop.

Low fuel level

  fixed with the needle
in the red zone.

 There remains approximately

5 litres

of fuel in the tank.
At this point, you begin to use the fuel
reserve.

 Refuel as soon as possible to avoid running out of fuel.
This warning lamp will come on every time the ignition
is switched on, until a sufficient addition of fuel is made.
 Fuel tank capacity: approximately

50 litres   ( 45 litres

for the BlueHDi Diesel engine).
 Never continue to drive until you run out of fuel, as
this could damage the emission control and injection
systems.

  flashing  with  the
needle in the red
zone.

 There remains very little fuel in the
tank.

Under-inflation

  fixed.

 The pressure in one or more wheels
is too low.

 Check the pressure of the tyres as soon as possible.
This check should preferably be carried out when the
tyres are cold.

  +

  flashing  then  fixed,
accompanied by the
Service warning lamp.

 The tyre pressure monitoring system
has a fault or no sensor is detected
on one of the wheels.

 Under-inflation detection is not assured.
 Have the system checked by a PEUGEOT dealer or a
qualified workshop.

  *   Depending on the country of sale.

2

Monitoring

      Touch  screen

For

For

For safety    reasons, the driver

, the driver

, the driver must

only carry out operations that

require close attention    with the

vehicle stationary.

 Some functions are not accessible
when  driving.

  It gives access to:
   -   menus for adjusting settings for vehicle

functions and systems,

  -   audio and display configuration menus,
  -   audio system and telephone controls and

the display of associated information.

  And, depending on equipment, it allows:
   -   the display of alert messages and the

visual parking sensors information,

  -   access to the controls for the navigation

system and Internet services, and the
display of associated information.

  General  operation

  Recommendations

 It is necessary to press firmly, particularly for
"flick" gestures (scrolling through lists, moving
the map, etc.).
 A light wipe is not enough.
 The screen does not recognise pressing with
more than one finger.
 This technology allows use at all temperatures
and when wearing gloves.
 Do not use pointed objects on the touch
screen.
 Do not touch the touch screen with wet hands.
 Uses a soft clean cloth to clean the touch
screen.

  State of indicator lamps

 Some buttons contain an indicator lamp that
gives the state of the corresponding function.
 Green indicator: you have switched on the
corresponding function.
 Orange indicator: you have switched off the
corresponding  function.

  Principles

 Press the "

MENU " button for access to the

different menus, then press the virtual buttons
on the touch screen.
 Each menu is displayed over one or two pages
(primary page and secondary page).

  Use this button to go to the
secondary  page.

  After a few moments with no action on
the secondary page, the primary page
is displayed automatically.

  Use this button to return to the
primary  page.

  Use this button for access to
additional information and to the
settings for certain functions.

  Use this button to confirm.

  Use  this  button  to  quit.

1

3

Monitoring

2008-additif_en_Chap01_controle-de-marche_ed01-2016

  Menus

 Press this button for access to the
different menus.

Navigation

 Depending on trim level, navigation
may be unavailable, an option or
standard.
 See the "Audio equipment and
telematics"  section.

Radio Media

 See the "Audio equipment and
telematics"  section.

Settings

 Allows configuration of the display
and the system.
 Gives access to interactive help
for the vehicle's main systems and
warning / indicator lamps.

Connected services

 Run some of your smartphone's
applications via MirrorLink

TM

applications via MirrorLink

applications via MirrorLink    or CarPlay

®

.

 See the "Audio equipment and telematics"
section.

Telephone

 See the "Audio equipment and
telematics"  section.

Driving

 Allows access to the trip computer and,
depending on version, the adjustment
of settings for certain functions.
 See the corresponding section.

1.   Volume  /  mute.

 See the "Audio equipment and telematics"
section.

4

Practical information

2008-additif_en_Chap09_info-pratiques_ed01-2016

  Low  fuel  level

 When the low fuel level is reached,
this warning lamp comes on in the
instrument panel. There remains

approximately 5 litres  of fuel in

the tank. When the warning lamp
flashes, there is

very little fuel left .

  The key cannot be removed from the
lock until the cap is refitted.
 Removing the filler cap may cause an
inrush of air. This vacuum is perfectly
normal and results from the sealing of
the  system.

                   Fuel  tank

  Fuel tank capacity: approximately

50 litres   ( 45 litres  for the BlueHDi Diesel engine).

1.   Open the filler flap.

2.   Remove the filler cap.

3.   Hook  the  filler  cap.

  Refuelling

  To fill the tank safely:




the engine must be switched off,



   open the fuel filler flap

1 ,



   insert the key in the cap

2 , then turn it to

the left,

      With Stop & Start, never refuel with the
system in STOP mode; you must switch
off the ignition with the key.



   remove the cap and hook it onto the clip

located on the inside of the flap

3 ,



   fill the tank,

but do not continue after the

3

rd



cut-off of the    nozzle ; this could cause

malfunctions.

 You must refuel as soon as possible to avoid
running out of fuel.
 For more information on

Running out of fuel

(Diesel) , refer to the corresponding section.

  A self-adhesive label on the inner face of the
filler flap reminds you of the type of fuel to use
depending on your engine.
 Additions of fuel must be of at least 5 litres to
be registered by the fuel gauge.

5

9

Practical information

2008-additif_en_Chap09_info-pratiques_ed01-2016

  Fuel  supply  cut-off

 Your vehicle is fitted with a safety system that
cuts off the supply of fuel in the event of an
impact.

 When you have filled the tank:


   put the cap back in place,



   turn the key to the right, then remove it

from the cap,



   close  the  flap.

If you have put in the wrong fuel for

the engine of your vehicle, you must

have the fuel tank drained and filled

with the correct fuel before starting

the engine.

6

Practical information

2008-additif_en_Chap09_info-pratiques_ed01-2016

 Compatibility  of

fuels

          Fuel  used  for  petrol

engines

  The petrol engines are compatible with biofuels
that conform to current and future European
standards and which can be obtained from
filling stations.

  The use of any other type of (bio)
fuel (vegetable or animal oils, pure or
diluted, domestic fuel, etc.) is strictly
prohibited (risk of damage to the engine
and fuel system).

  The only Diesel additives authorised for
use are those that meet the B715000
standard.

   Travelling  abroad

Certain fuels could damage the

engine of your vehicle. In certain

countries, the use of a particular fuel

may be required (specific octane

rating, specific sales name, etc.)

to ensure correct operation of the

engine.

 For any additional information, contact
your  dealer.

  The only petrol additives authorised for
use are those that meet the B715001
standard.

          Fuel  used  for  Diesel

engines

  The Diesel engines are compatible with
biofuels that conform to current and future
European standards and which can be
obtained from filling stations.

 Diesel fuel that meets standard EN590
mixed with a biofuel that meets standard
EN14214 (possibly containing up to 7%
Fatty Acid Methyl Ester).

 Paraffinic Diesel fuel that meets
standard EN15940 mixed with a biofuel
that meets standard EN14214 (possibly
containing up to 7% Fatty Acid Methyl
Ester).

 Diesel fuel that meets standard EN16734
mixed with a biofuel that meets standard
EN14214 (possibly containing up to 10%
Fatty Acid Methyl Ester).

  The use of B20 or B30 fuel meeting
standard EN16709 is possible in your
Diesel engine. However, this use, even
occasional, requires strict application
of the special servicing conditions
referred to as "Arduous conditions".

 Petrol that meets the EN228 standard,
mixed with a biofuel meeting the
EN15376  standard.

 For more information, contact a PEUGEOT
dealer or a qualified workshop.

           Diesel  fuel  at  low  temperature

 In temperatures below 0°C (+32°F), the
formation of paraffins in the summer Diesel
fuels may result in abnormal operation of the
fuel supply system. To avoid this, the use of
winter Diesel fuels is recommended, keeping
the tank topped up to more than 50% of its
capacity.
 If in spite of this you experience difficulties
starting the engine in temperatures below -15°C
(+5°F), simply leave the vehicle in a garage or a
heated workshop for a while.

11

7

Technical data

2008-additif_en_Chap11_caracteristiques-techniques_ed01-2016

                 Identifi cation markings

A.    Vehicle Identification Number (VIN)

under the bonnet.



This number is engraved on the bodywork
near the damper support.

  The tyre pressures must be checked
when the tyres are cold, at least once
a month.

  Low tyre pressures increase fuel
consumption.

B.    Vehicle Identification Number (VIN) at

the bottom of the windscreen aperture.



This number is indicated on a self-
adhesive label which is visible through the
windscreen.

C.    Manufacturer's label.



This number is indicated on a self-
destroying label affixed to the centre pillar,
on the left-hand or right-hand side.

D.    Tyre/paint label.



This self-adhesive label is affixed to the
centre pillar, on the driver's side.

 It bears the following information:
   -   the tyre inflation pressures with and without

load,

  -   the tyre sizes,
  -   the inflation pressure of the spare wheel,
  -   the paint colour code.

 Various visible markings for the identification of your vehicle.

  The original tyres fitted to the vehicle
may have a load index or speed rating
higher than those given on the label;
this has no effect on the inflation
pressures.

 Audio and Telematics

8

2008-additif_en_Chap12a_BTA-2-BTA-3R_ed01-2016

       Emergency  or  assistance  call

        PEUGEOT  Connect  SOS

             In  an  emergency,  press  this
button for more than 2 seconds.
 Flashing of the green indicator
lamp and a voice message
confirm that the call has been
made to the "PEUGEOT Connect
SOS" *   centre.

  Pressing this button again immediately cancels
the request.
 The green indicator lamp goes off.

  The green indicator lamp remains on (without
flashing) when communication is established.
 It goes off at the end of the call.

  "PEUGEOT Connect SOS" immediately locates
your vehicle, makes contact with you in your
language **  and - if necessary - organises
sending of the appropriate emergency
services ** . In countries where the service is not
operational, or if the locating service has been
expressly declined, the call is directed straight
to the emergency services (112) without
location.

  **    Depending on the geographic cover for

"PEUGEOT Connect SOS", "PEUGEOT
Connect Assistance" and the official national
language selected by the owner of the
vehicle.

   The list of countries covered and the

PEUGEOT CONNECT services is available
from dealers or on your country's website.

  *    Depending on the general terms and

conditions of use for the service, available
from dealers, and technological and technical
limits.

  If an impact is detected by the airbag
control unit, and independently of
the deployment of any airbags, an
emergency  call  is  made  automatically.

      If  you  benefit  from  the  PEUGEOT
Connect Packs offer with the SOS and
assistance pack included, there are
additional services available to you in
your personal space, via your country's
website.

  Type  1

.

 Audio and Telematics

9

2008-additif_en_Chap12a_BTA-2-BTA-3R_ed01-2016

  PEUGEOT  Connect  Assistance

  The fault with the system does not
prevent the vehicle being driven.

  Press this button for more than
2 seconds to request assistance
if the vehicle breaks down.
 A voice message confirms that
the call has been made ** .

  Pressing this button again immediately cancels
the request.
 The cancellation is confirmed by a voice
message.

  Geo-location

  You can deactivate geo-location by
simultaneously pressing the "PEUGEOT
Connect SOS" and "PEUGEOT Connect
Assistance" buttons, followed by a press on
"PEUGEOT Connect Assistance" to confirm.

  To reactivate geo-location, simultaneously
press the "PEUGEOT Connect SOS" and
"PEUGEOT Connect Assistance" buttons
again, followed by a press on "PEUGEOT
Connect  Assistance"  to  confirm.

 If the orange indicator lamp is on fixed: replace
the back-up battery.
 In both cases, the emergency and assistance
calls service may not work.
 Contact a qualified repairer as soon as
possible.

  Operation  of  the  system

  When the ignition is switched on,
the green indicator lamp comes
on for 3 seconds indicating that
the system is operating correctly.

  If the orange indicator lamp
flashes then goes off: the system
has a fault.

  If you purchased your vehicle outside
the Brand's dealer network, we suggest
that you have a dealer check and, if
desired, modify the configuration of
these services.
 In a multi-lingual country, configuration
is possible in the official national
language of your choice.

  For technical reasons, in particular
to improve the quality of PEUGEOT
CONNECT services to customers,
the manufacturer reserves the right to
carry out updates to the vehicle's on-
board telematic system at any time.

**    Depending on the geographic cover for

"PEUGEOT Connect SOS", "PEUGEOT
Connect Assistance" and the official national
language selected by the owner of the
vehicle.

   The list of countries covered and the

PEUGEOT CONNECT services is available
from dealers or on your country's website.
