Peugeot 2008 (2016 year). Instruction

335

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

Bluetooth

audio streaming

Streaming allows music files on a telephone to
be heard via the vehicle's speakers.

Connect the telephone: see the "Telephone"
section.

In the "Bluetooth: Audio" menu, select the
telephone to connect.
The audio system connects automatically to a
newly paired telephone.

Control of playback is via the audio system. The control
of common tracks is possible via the audio system
control buttons and the steering mounted controls**.
Contextual information can be displayed in the screen.

Activate the streaming source by
pressing the SRC/TEL* button.

Connecting Apple

players

Connect the Apple

player to the USB port

using a suitable cable (not supplied).
Play starts automatically.

Management of the device is via the audio
system controls.

The classifications available are those on the
portable player connected (artists / albums /
genres / playlist s/ audiobooks / podcasts).

The software version of the audio system may
not be compatible with the generation of your
Apple

player.

The audio quality depends on the quality of the
transmission from the telephone.

* In certain cases, the play of audio files must

be initiated from the keypad.

** If the telephone supports the function.

336

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

Telephone

Pairing a Bluetooth

telephone

For safety reasons and because they
require prolonged attention on the part
of the driver, the operations for pairing
of the Bluetooth mobile telephone
with the Bluetooth hands-free system
of your audio system must be carried
out with the vehicle stationary and the
ignition on.

Visit www.peugeot.co.uk for more information
(compatibility, more help, ...).

Activate the telephone's Bluetooth function and
ensure that it is set as visible to all (refer to the
telephone instructions).

Press the MENU button.

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth telephone
used.
Consult your telephone's manual and
your operator to find out which services
are available to you.

Only one telephone can be paired at a time.

A message is displayed in the screen of the
telephone: enter the same code and confirm.

If pairing fails, try again; the number of attempts is not limited.

A message appears in the screen to confirm
the result of the connection.

Pairing can also be initiated from the
telephone by searching for detected
Bluetooth devices.

The directory and the calls list can be
accessed after the synchronisation
period (if the telephone is compatible).
Automatic connection must be
configured in the telephone to allow
the connection each time the vehicle is
started.

Select "Bluetooth".

Select the telephone to be paired
from the list.

A virtual keypad is displayed on the
screen: choose a 4 digit code.

Select "Search".

A window is displayed with "Searching
device".

In some cases, the Bluetooth address of the
telephone may appear instead of the name of
the telephone.

Confirm with "OK".

337

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

Press the MENU button.

Managing connections

Making a call

From the directory

Select "Bluetooth".

Select "Telephone".

Select "Call".

Select "Directory".

"Delete" to delete the pairing.

Select or deselect:
-

"Tel.": hands-free connection

"Audio": play audio files

Indicates connection of the audio
profile.

Indicates connection of the
hands-free profile.

Select "BT management" and
confirm. The list of paired telephones
is displayed.

In the list, select a telephone to pair.

Confirm with "OK".

"OK" to confirm the choice.

Select the desired number.

Confirm with "OK" to start the call.

It is not possible to pair more than
5 telephones. Press MENU and
select "Bluetooth". Select "BT
management". If 5 telephones are
already paired, select the telephone to
delete by pressing "OK" and selecting
"Delete" (refer to the "Managing
connections" section).

338

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

For access to the calls list, it is also
possible to press MENU, select
"Telephone", then select "Call", and
finally select "Calls list".

The calls list includes the calls sent
from and by from the vehicle via the
connected telephone.
It is possible to make a call directly from
the telephone; stop the vehicle as a
safety measure.

Making a call

Recently called numbers*

In the list of calls, select the number
and choose "Missed calls", "Dialed
calls" or "Answered calls".

Press and hold SRC/TEL to display
the calls list.

Press SRC/TEL.

on SRC/TEL also rejects an
incoming call.

Scroll through the calls list.

Confirm with "OK".

"OK" starts the call.

Press one of these buttons to go to
the previous or next page in the list.

* Depending on the compatibility of the

telephone.

select "YES" to accept the call,

select "NO" to reject the call.

Pressing and holding the back
button,

339

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

Managing calls

In the contextual menu, select "Hang
up" to end the call.

Select "Micro OFF" to switch off the
microphone.

Select "Combined mode" to transfer
the call to the telephone.

Press ¯ to display the audio settings
menu.
Press ¯ to go to the next setting.

Select "Micro OFF" to switch the
microphone on again.

Select "Combined mode" to transfer
the call to the vehicle.

In the contextual menu:

From the contextual menu:

In certain cases, the combined mode has
to activated from the telephone.
The Bluetooth connection will be restored
automatically if the ignition has been
switched off, then on again (depending on
the compatibility of the telephone).

The distribution, or spatialisation of sound,
is an audio process which allows the
sound quality to be improved according to
the setting chosen, corresponding to the
position of the listeners in the vehicle.

Hang up

Secret - Mute

Combined mode

Pressing and holding on SRC/TEL
also ends the call.

(so that the caller cannot hear)

(to leave the vehicle without ending the call)

The settings available are:
-

AMBIANCE: BASS, TREBLE and
LOUDNESS.

BALANCE (left/right balance), FADER
(front/rear balance)

SOUND DIST. (driver or passenger).

AUTO VOLUME.

The AMBIANCE, TREBLE and BASS
audio settings are different and
independent for each sound source.

Audio settings

340

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

Configuration

Press the MENU button.

Select "Config.".

Select "Displaying" to activate or
deactivate scrolling text.

Select "Language" to modify the
display language.

Select "Version" for information on
the software.

Select "Unit" to modify the units for
temperature (Celsius, Fahrenheit).

Select "System" when you want to
install an update. Information can be
obtained from a PEUGEOT dealer.

Display and language settings

341

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

Screen menu map(s)

Directory

Scrolling text

Deutsch

Italiano

Español

Português

Русский

Celsius

English

Nederlands

Français

Português-Brasil

Türkçe

Fahrenheit

Calls list

Missed calls

Dialed calls

Answered calls

Radio

Telephone

Bluetooth

Config.

RDS

TXT

Write freq.

Media

Normal

Random all

Call

BT management

Unit

Search

Displaying

Language

Version

System

Phone status

MENU

Random

Repeat

342

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

Frequently asked questions

The following tables contain answers to the most frequently asked questions.

QUESTION

ANSWER

SOLUTION

There is a difference in
sound quality between the
different audio sources
(radio, CD...).

For optimum sound quality, the audio settings (volume, bass,
treble, ambience, loudness) can be adapted to the different sound
sources, which may result in audible differences when changing
source (radio, CD...).

Check that the audio settings (volume, bass,
treble, ambience, loudness) are adapted to the
sources listened to. It is advisable to adjust
audio settings (bass, treble, Front-Rear balance,
Left-Right balance) to the middle position, select
the musical ambience and set the loudness
correction to the "Active" position in CD mode or
to the "Inactive" position in radio mode.

When changing the
settings for treble and
bass, the ambience setting
is deselected.
When changing the
ambience setting, treble
and bass are reset
to zero.

Choosing an ambience imposes settings for treble and bass.
Modifying one without the other is only possible with a personalised
ambience.

Modify the treble and bass settings or the
ambience setting to obtain the desired sound
quality.

When changing the
balance setting,
distribution is deselected.

Choosing the "driver" distribution setting imposes a balance setting.

Modify the balance setting or the distribution
setting to obtain the desired sound quality.

343

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

QUESTION

ANSWER

SOLUTION

The quality of reception of
the radio station listened
to gradually deteriorates
or the stored stations do
not function (no sound,
87.5 MHz is displayed...).

The vehicle is too far from the transmitter used by the station
listened to or there is no transmitter in the geographical area
through which the vehicle is travelling.

Activate the RDS function to enable the system
to check whether there is a more powerful
transmitter in the geographical area.

The environment (hills, buildings, tunnels, basement car parks...)
block reception, including in RDS mode.

This phenomenon is normal and does not
indicate a failure of the audio equipment.

The aerial is absent or has been damaged (for example when going
through a car wash or into an underground car park).

Have the aerial checked by a PEUGEOT dealer.

Sound cut-outs of 1 to
2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for any frequency
permitting better reception of the station.

Deactivate the RDS function if the phenomenon
is too frequent and always on the same route.

Traffic announcement
TA is displayed. I do
not receive any traffic
information.

The radio station does not broadcast traffic information.

Tune to a radio station which broadcasts traffic
information.

The stored stations are not
found (no sound,
87.5 MHz is displayed...).

An incorrect waveband is selected.

Press the SRC/TEL button to return to the
waveband (FM1 or FM2) on which the stations
are stored.

344

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

QUESTION

ANSWER

SOLUTION

The CD is ejected
automatically or is not
played by the player.

The CD is inserted upside down, is unplayable, does not contain
any audio data or contains an audio format which the player cannot
play.
The CD is protected by an anti-pirating protection system which is
not recognised by the audio equipment.

Check that the CD is inserted in the player
the right way up.

Check the condition of the CD: the CD
cannot be played if it is too damaged.

Check the content in the case of a recorded
CD: consult the advice in the "Audio" section.

The audio equipment's CD player does not
play DVDs.

Due to their quality level, certain writeable
CDs will not be played by the audio system.

The CD player sound is
poor.

The CD used is scratched or of poor quality.

Insert good quality CDs and store them in
suitable conditions.

The audio settings (bass, treble, ambience) are unsuitable.

Set the treble or bass level to 0, without selecting
an ambience.

The Bluetooth connection
is cut.

The battery of the peripheral may not be sufficiently charged.

Recharge the battery of the peripheral device.

The message "USB device
error" is displayed on the
screen.

The USB memory stick is not recognised.

Use only USB memory sticks formatted to FAT 32
(28-bit file allocation table).

A telephone connects
automatically,
disconnecting another
telephone.

Automatic connection overrides manual connection.

Modify the telephone settings to remove
automatic connection.

345

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

QUESTION

ANSWER

SOLUTION

An iPod is not recognised
when connecting to the
USB port.

The iPod is of a generation that is not compatible with the USB
connection.

The hard disk or device
is not recognised when
connecting to the USB
port.

Some hard disks and devices need a power supply greater than is
provided by the audio system.

Connect the device to the 230 V socket, the 12 V
socket or an external power supply.
Caution: ensure that the device does not
transmit a voltage greater than 5 V (risk of
destruction of the system).

When streaming, the
sound cuts momentarily.

Some telephones prioritise connection of the "hands-free" profile.

Delete the "hands-free" connection profile to
improve streaming.

In "Random all" play, not
all of the tracks are played.

In "Random all" play, the system can only take into account up
to 999 tracks.

With the engine off, the
audio system switches off
after a few minutes of use.

When the engine is switched off, the audio system operating time
depends on the battery charge.
The switch-off is normal: the audio system switches to economy
mode and switches off to prevent discharging the vehicle's battery.

Start the vehicle's engine to increase the battery
charge.

The message "the audio
system is overheated"
appears on the display.

In order to protect the installation if the surrounding temperature
is too high, the audio system switches to an automatic thermal
protection mode leading to a reduction of the volume or stopping of
the playing of the CD.

Switch the audio system off for a few minutes to
allow the system to cool.

347

Audio and Telematics

2008_en_Chap12d_RDE1_ed01-2016

Audio system

Contents

First steps

348

Steering mounted controls

349

Radio 350
Media 352
Audio settings

354

Screen menu map(s)

355

Frequently asked questions

356

As a safety measure, the driver must only carry out operations
which require prolonged attention while the vehicle is stationary.
When the engine is switched off and to prevent discharging of
the battery, the system switches off after activation of economy
mode.

348

Audio and Telematics

2008_en_Chap12d_RDE1_ed01-2016

First steps

On / Off, volume adjustment.

Selection of source:
FM1, FM2, AM, CD, AUX.

Display the list of stations received,
the CD/MP3 tracks or folders.
Press and hold: update the list of
stations received.

Manual search step by step for a
higher radio frequency.
Select the next MP3 track.
Navigation in a list.

Manual search step by step for a
lower radio frequency.
Select the previous MP3 track.
Navigation in a list.

Automatic search for a lower/higher
radio frequency.
Select the next CD track.
Navigation in a list.
Press and hold: fast forward or back.

Automatic search step by step for a
higher radio frequency.
Select the next CD track.
Navigation in a list.
Press and hold: fast forward.

Adjust audio settings:
sound ambience, treble, bass,
loudness, left/right balance,
automatic volume.

Abandon the current operation.
Go up one level (menu or folder).

Select a preset radio station.
Radio, press and hold: preset a radio
station.

Eject CD.

Open the main menu.

349

Audio and Telematics

2008_en_Chap12d_RDE1_ed01-2016

Steering mounted controls

Radio: select the previous / next
preset station.
Select the previous / next item in
a menu.

Volume down.

Radio: automatic search for a higher
frequency.
CD / MP3: select the next track.
CD: press and hold: fast forward.

Mute on: cut the sound by
simultaneously pressing the volume
up and down buttons.
Mute off: press one of the volume
buttons.

Radio: automatic search for a lower
frequency.
CD / MP3: select the previous track.
CD: press and hold: fast back.

Change audio source.
Confirm a selection.

Volume up.

350

Audio and Telematics

2008_en_Chap12d_RDE1_ed01-2016

Radio

Presetting a station

Selecting a station

Managing the list

Press the SRC/BAND button
repeatedly to select the FM1, FM2 or
AM waveband.

Press and hold a button to preset the
station being listened to. The name
of the station is displayed and an
audible signal confirms that it has
been preset.

Press a button to listen to the
corresponding preset station.

Select "Radio".

Select "RDS".

RDS

RDS, if displayed, enables you to continue
listening to the same station by automatic
retuning to alternative frequencies.
However, in certain conditions, coverage
by an RDS station may not be assured
throughout the country as radio stations
do not cover 100 % of the territory. This
explains the loss of reception of the
station during a journey.

The external environment (hills,
buildings, tunnels, basement car
parks) may block reception, including
in RDS mode. This is a normal effect
of the way in which radio waves are
transmitted and does not indicate any
failure of the audio equipment.

Press MENU.

Briefly press one of the buttons to
change to the next or previous letter.

Press and hold on LIST to construct
or update the list of stations; the
sound is interrupted temporarily.

Press LIST to display the list of
stations received, in alphabetical
order.

Select the desired radio station by
pressing one of the buttons.

Confirm with OK.

Peugeot 2008 (2016 year). Instruction - part 22
