Peugeot 2008 (2016 year). Instruction - part 21





319

.

Audio and Telematics

2008_en_Chap12b_SMEGplus_ed01-2016

QUESTION

ANSWER

SOLUTION

Certain traffic jams along
the route are not indicated
in real time.

On starting, it is several minutes before the system begins to receive
the traffic information.

Wait until the traffic information is being received
correctly (display of the traffic information icons
on the map).

The filters are too restrictive.

Modify the settings.

In certain countries, only major routes (motorways...) are listed for
the traffic information.

This phenomenon is normal. The system is
dependent on the traffic information available.

The altitude is not
displayed.

On starting, the initialisation of the GPS may take up to 3 minutes to
receive more than 4 satellites correctly.

Wait until the system has started up completely so
that there is GPS coverage by at least 4 satellites.

Depending on the geographical environment (tunnel...) or the
weather, the conditions of reception of the GPS signal may vary.

This phenomenon is normal. The system
is dependent on the GPS signal reception
conditions.

320

Audio and Telematics

2008_en_Chap12b_SMEGplus_ed01-2016

Radio

QUESTION

ANSWER

SOLUTION

The quality of reception of
the radio station listened
to gradually deteriorates
or the stored stations do
not function (no sound,
87.5 Mhz is displayed...).

The vehicle is too far from the transmitter used by the station
listened to or there is no transmitter in the geographical area
through which the vehicle is travelling.

Activate the "RDS" function by means of the
short-cut menu to enable the system to check
whether there is a more powerful transmitter in
the geographical area.

The environment (hills, buildings, tunnels, basement car parks...)
block reception, including in RDS mode.

This phenomenon is normal and does not indicate
a fault with the audio system.

The aerial is absent or has been damaged (for example when going
through a car wash or into an underground car park).

Have the aerial checked by a PEUGEOT dealer.

I cannot find some radio
stations in the list of
stations received.

The station is not received or its name has changed in the list.

Press and hold the "List" button at the steering
mounted controls to update the list of stations
received or press on the system update function:
"Update list".

Some radio stations send other information in place of their name
(the title of the song for example).
The system interprets this information as the name of the station.

The name of the radio
station changes.

321

.

Audio and Telematics

2008_en_Chap12b_SMEGplus_ed01-2016

Media

QUESTION

ANSWER

SOLUTION

Playback of my USB
memory stick starts only
after a very long wait
(around 2 to 3 minutes).

Some files supplied with the memory stick may greatly slow down
access to reading the memory stick (multiplication by 10 of the
catalogue time).

Delete the files supplied with the memory stick
and limit the number of sub-folders in the file
structure on the memory stick.

When I connect my iPhone
as a telephone and to the
USB port at the same time,
I am unable to play the
music files.

When the iPhone connects automatically as a telephone, it forces
the streaming function. The streaming function takes the place of
the USB function which is then not useable, there is a period without
sound of the track being played with Apple

®

 players.

Disconnect and reconnect to the USB port (the
USB function takes priority over streaming).

The CD is ejected
automatically or is not
played by the player.

The CD is inserted upside down, is unplayable, does not contain any
audio data or contains an audio format which the player cannot play.

Check that the CD is inserted in the player the
right way up.
Check the condition of the CD: the CD cannot be
played if it is too badly damaged.
Check the content in the case of a recorded CD:
refer to the advice in the "AUDIO" section.
The audio system's CD player does not play
DVDs.
Some recorded CDs will not be played by the
audio system because they are not of adequate
quality.

The CD has been recorded in a format that is not compatible with the player (udf...).

The CD is protected by an anti-pirating protection system which is
not recognised by the audio system.

There is a long waiting
period following the insertion
of a CD or connection of a
USB memory stick.

When a new medium is inserted, the system reads a certain
amount of data (directory, title, artist, etc.). This may take from a few
seconds to a few minutes.

This phenomenon is normal.

322

Audio and Telematics

2008_en_Chap12b_SMEGplus_ed01-2016

QUESTION

ANSWER

SOLUTION

The CD player sound is
poor.

The CD used is scratched or of poor quality.

Insert good quality CDs and store them in suitable
conditions.

The audio equipment settings (bass, treble, ambiences) are
unsuitable.

Set the treble or bass level to 0, without selecting
an ambience.

Some characters in the
media information are not
displayed correctly while
playing.

The audio system does not display some types of characters.

Use standard characters to name tracks and
folders.

Playing of streaming files
does not start.

The peripheral device connected does not support automatic play.

Start the playback from the device.

The names of tracks and
the track length are not
displayed on the screen
when streaming audio.

The Bluetooth profile does not allow the transfer of this information.

323

.

Audio and Telematics

2008_en_Chap12b_SMEGplus_ed01-2016

QUESTION

ANSWER

SOLUTION

In changing the setting
of treble and bass the
equalizer setting is
deselected.

The selection of an equalizer setting imposes the balance settings.
Modifying one without the other is not possible.

Modify the balance or equalizer settings to obtain
the desired musical ambience.

In changing the equalizer
setting, treble and bass
return to zero.

When changing the
balance settings, the
distribution setting is
deselected.

The selection of a distribution setting imposes the balance settings.
Modifying one without the other is not possible.

Modify the balance or distribution settings to
obtain the desired musical ambience.

When changing an
distribution setting,
the balance setting is
deselected.

Settings

324

Audio and Telematics

2008_en_Chap12b_SMEGplus_ed01-2016

QUESTION

ANSWER

SOLUTION

There is a difference in
sound quality between the
different audio sources.

For optimum sound quality, the audio settings for Loudness,
Ambience, Treble, Bass, Volume can be adapted to the different
sound sources, which may result in audible differences when
changing source.

Check that the audio settings (Loudness,
Ambience, Treble, Bass, Volume) are adapted to
the sources listened to. Adjust Balance, Treble
and Bass to the middle position, select the
"None" musical ambience and set the loudness
correction to the "Active" position in CD mode or
to the "Inactive" position in radio mode.

With the engine off, the
system switches off after a
few minutes of use.

When the engine is switched off, the system's operating time
depends on the state of charge of the battery.
The switch-off is normal: the system switches to economy mode and
switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery
charge.

325

.

Audio and Telematics

2008_en_Chap12b_SMEGplus_ed01-2016

QUESTION

ANSWER

SOLUTION

I cannot connect my
Bluetooth telephone.

The telephone's Bluetooth function may be switched off or the
telephone may not be visible.

Check that your telephone's Bluetooth function is
switched on.
Check in the telephone settings that it is "visible
to all".

The Bluetooth telephone is not compatible with the system.

You can check the compatibility of your
telephone at www.peugeot.co.uk (services).

The volume of the
telephone connected
in Bluetooth mode is
inaudible.

The volume depends both on the system and on the telephone.

Increase the volume of the audio system, to
maximum if required, and increase the volume of
the telephone if necessary.

The ambient noise level has an influence on the quality of
telephone communication.

Reduce the ambient noise level (close the
windows, reduce the booster fan speed, slow
down...).

Some contacts are
duplicated in the list.

The options for synchronizing contacts are synchronizing the
contacts on the SIM card, the contacts on the telephone, or both.
When both synchronizations are selected, some contacts may be
duplicated.

Select "Display SIM card contacts" or "Display
telephone contacts".

Contacts are not shown in
alphabetical order.

Some telephones offer display options. Depending on the settings
chosen, contacts can be transferred in a specific order.

Modify the display setting in the telephone
directory.

The system does not
receive SMS text messages.

The Bluetooth mode does not permit sending SMS text messages
to the system.

Telephone

327

.

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

Audio system / Bluetooth

®

Contents

First steps

328

Steering mounted controls

329

Radio 330
Media 332
Telephone 336
Audio settings

339

Configuration

340

Screen menu map(s)

341

Frequently asked questions

342

As a safety measure, the driver must only carry out operations
which require prolonged attention while the vehicle is stationary.
When the engine is switched off and to prevent discharging of
the battery, the system switches off after activation of energy
economy mode.

328

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

First steps

On / Off, volume adjustment.

Select the source:
Radio: FM1, FM2, AM, CD, USB,
AUX, Streaming.
Telephone: accept an incoming call.
Telephone, press and hold: end
a call, access the calls log for the
connected telephone.

Display the list of stations received,
the CD/USB tracks or folders.
Press and hold: update the list of
stations received.

Automatic search for a lower radio
frequency.
Select the previous CD, USB track.
Navigation in a list.
Press and hold: fast back.

Automatic search for a higher radio
frequency.
Select the next CD, USB track.
Navigation in a list.
Press and hold: fast forward.

Adjust audio settings: sound
ambience, treble, bass, loudness,
distribution, left/right balance, front/
rear balance, automatic volume.

Abandon the current operation.
Go up one level (menu or folder).

Select a preset radio station.
Radio, press and hold: preset a radio
station.
Other than radio: see the
corresponding sections.

Eject CD.

Open the main menu.

329

.

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

Steering mounted controls

Radio: select the previous / next
preset station.
CD / USB: select the genre /
artist / folder / playlist from the list
depending on classification.
Select the previous / next item
in a menu.

Volume decrease.

Radio: automatic search for a higher
frequency.
CD / MP3 / USB: select the next
track.
CD / USB: press and hold: fast
forward.

Mute: cut the sound by
simultaneously pressing the volume
increase and decrease buttons.
Restore the sound: by pressing one
of the two volume buttons.

Radio: automatic search for a lower
frequency.
CD / MP3 / USB: select the previous
track.
CD / USB: press and hold: fast back.

Change the audio sound.
Confirm a selection.
Start/end call with the telephone.
Press and hold: access to the
call log.

Volume increase.

330

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

Radio

Presetting a station

Selecting a station

Managing a list

Entering a frequency

Press SRC/TEL repeatedly to select
the FM1, FM2 or AM waveband.

Press and hold one of the buttons to
preset the station being listened to.
The name of the station is displayed
and an audible signal confirms the
preset.

Press a button to listen to the
corresponding preset station.

Select "Radio".

Select "Write freq.".

Press +.

or

press - to select the desired
frequency.

Briefly press one of the buttons to
change to the next or previous letter.

Press and hold on LIST to build or
update the list of stations; audio
reception is cut momentarily.

Press LIST to display the list of
stations received in alphabetical
order.

Select the desired radio station using
one of the buttons.

Confirm with "OK".

Confirm with "OK".

The exterior environment (hills, buildings,
tunnel, car park, below ground...) may
prevent reception, even in RDS station
tracking (alternative frequencies) mode. This
phenomenon is normal in the propagation of
radio waves and is in no way indicative of a
fault with the audio system.

Press on MENU.

331

.

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

Select "Radio".

Select "Radio".

Select "Radio".

Select or deselect "RDS" to switch
RDS on or off.

Select or deselect "TXT" to activate
or deactivate the display of Radio
Text.

Select or deselect "TA" to activate
or deactivate the reception of traffic
messages.

Confirm with "OK" to save the
setting.

Confirm with "OK" to save the
setting.

Confirm with "OK" to save the
setting.

Receiving TA messages

RDS

Displaying RADIO TEXT

The TA (Traffic Announcement)
function gives priority to TA alert
messages. To operate, this function
needs good reception of a radio station
transmitting this type of message.
When a traffic report is transmitted,
the current audio source (Radio, CD,
USB, ...) is interrupted automatically to
play the TA message. Normal playback
of the audio source resumes at the end
of the transmission of the message.

RDS, if activated, enables you to continue
listening to the same station by automatic
retuning to alternative frequencies.
However, in certain conditions, coverage
of an RDS station may not be assured
throughout the country as radio stations
do not cover 100 % of the territory. This
explains the loss of reception of the
station during a journey.

Radio text is information transmitted by
the radio station related to the current
programme or song.

With source FM1 or FM2,
press MENU.

With the radio displayed on the
screen, press MENU.

Press MENU.

332

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

Media

USB player

This unit comprises a USB port
and a Jack auxiliary socket,
depending on model.

Connect a USB memory stick to the USB port
or connect a USB device to the USB port using
a suitable cable (not supplied).

The system constitutes playlists (in
temporary memory) the creation time
for which can be from a few seconds to
several minutes at the first connection.
Limiting the number of non-music files
and the number of folders reduces this
waiting time. The playlists are updated
every time the ignition is switched off or
a USB memory stick is connected.
The lists are memorised: if there is no
change in the lists, the next loading
time will be shorter.

Press SRC/TEL repeatedly to
select "USB".

Press one of these buttons to select
the next or previous track in the list.

Press and hold one of these buttons
for fast forward or back.

Press one of these buttons to select
the next or previous folder in the
order chosen.

Press LIST to display the structure of
the folders in the compilation.

Select a line in the list.

Confirm with "OK".

Up a level in the menu.

Select "Media".

Select the play mode: "Normal"
"Random""Random all" or
"Repeat".

Select or deselect "TA" to switch
traffic announcements on or off.

Press MENU.

At a first connection, the order
suggested is by folder. When
connecting again, the order previously
chosen is retained.

333

.

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

Press the SRC/TEL button
repeatedly to select "CD".

Press one of these buttons to go to
the previous or next track in the list.

Press and hold one of these buttons
for fast forward or back.

Auxiliary socket (AUX)

Connect the portable device (MP3 player...) to
the Jack auxiliary socket using an audio cable
(not supplied).

Press SRC/TEL repeatedly to
select "AUX".

First adjust the volume on the portable device
(to a high level). Then adjust the volume on
your audio system. Control is from the portable
device.

Do not connect a given device to both
the Jack auxiliary socket and the USB
port at the same time.

CD player

Insert a CD into the player, play starts
automatically.
Insert an MP3 compilation CD into the CD
player.
The audio system searches for audio tracks,
which can take from a few to several dozen
seconds before play starts.

Press one of these buttons to select
the previous or next folder according
to the category chosen.

Press LIST to display the folder
structure of the compilation.

Select a line in the list.

Confirm with "OK".

Return to the top level of the folder structure to
select the type of tracks.
- By

Folders (CD or USB): all folders

containing audio files recognised on the
peripheral device, in alphabetical order
without following the folder structure.

- By

Artist (USB only): all of the artist names

defined in the ID3 Tags, in alphabetical
order.

- By

Genre (USB only): all of the genres

defined in the ID3 Tags.

- By

Playlist (CD or USB): if playlists have

been saved.

334

Audio and Telematics

2008_en_Chap12c_RDE2_ed01-2016

The audio system will only play files with
".mp3", ".wma" and ".wav" on a CD and can
play files with ".ogg" extension only on USB.

It is recommended that file names be of no
more than 20 characters and avoiding special
characters (ex: " ? ; ù) so as to avoid any
problem reading or displaying the files.

In order to be able to play a recorded CDR or
CDRW, when recording it is preferable to select
standards ISO 9660 level 1. 2 or Joliet.
If the disc is recorded in another format, it may
not be played correctly.
It is recommended that the same recording
standard is always used for an individual disc,
with as low a speed as possible (4x maximum)
for optimum sound quality.
In the particular case of a multi-session CD, the
Joliet standard is recommended.

Information and advice

Use only USB memory sticks formatted FAT32
(File Allocation Table).

The use of genuine Apple

®

 USB cables

is recommended to ensure correct
operation.

On a single disc, the CD player can read up
to 255 MP3 files spread over 8 folder levels
with a maximum of 192 folders. However, it is
recommended that this be kept to 2 levels so
as to limit the time taken to access and play
the CD.
During play, the folder structure is not
observed.

Do not connect a hard disk or USB device other
than audio players to the USB port. This may
cause damage to your installation.

The playlists accepted on CD, MP3, iPod and
USB connection are types ".m3u" and ".wpl".
The number of files recognised is limited to
5 000 in 500 folders on a maximum of 8 levels.















Content   ..  19  20  21  22   ..
