Peugeot 1007 (2008 year). Instruction

Behaviour in the case of a
steep slope

It is possible to open and close the
doors electrically up to a gradient
of 20 %.

In the case of a steep slope,
the door may be driven by its

own weight and as a conse-

quence may open or close
sharply. Therefore:

There would not be time for

operation of one of the electric
controls to be taken into
account.

There would not be time for the

obstacle detection system to be
triggered.

Take care not to leave the vehicle on
a  steep  slope  with  the  door(s)  open
without  supervision.  If  this  advice  is
not followed, injuries or damage may
occur if a part of the body or an  object
is trapped or caught.

In the event of an impact

The electric controls are deactivated
in the event of an impact. Manual
opening and closing is still possible.

Special features of operation

With the ignition off,
doors open, power consuming

equipment on (radio, lights…),

or
doors in an intermediate

position (door neither fully open
nor fully closed).

After 30 minutes, the vehicle auto-

matically switches to energy economy
mode.

However, if your vehicle is on a slope,
with the front of the vehicle facing up,
open the door with care. The door
may open more quickly due to the
incline of the ground.

However, if your vehicle is on a slope,
with the front of the vehicle facing
down, the door may not stay open
and may close again sharply with the
risk of injury.

Before any opening or clo-

sing and during any move-

ment of the doors, ensure that
no person, animal or object is

preventing  the  required   manoeuvre,
either  inside  or   outside  the  vehicle.
If this advice is not  followed,  injuries
or  damage  may   occur  if  a  part  of
the  body  or  an   object  is  trapped  or
caught.
Electric  closing  and  opening  of  the
doors  is  not  possible  above  3  mph
(5 km/h):
       If  you  set  off  with  the  door(s)

open,  you  must  slow  down  to
below  the  threshold  of  3  mph
(5  km/h)  in  order  to  close  the
door(s).

Any attempt to open a door elec-

trically using the interior handle,
while driving, results in the door
opening partially and, as a safety

measure, locking in this posi-

tion  immediately.  The  audible
warning, the lighting of the "door
open"  warning  light  and  the
message  on  the  multifunction

display accompany this situa-

tion. In order to release the door
and  be  able  to  operate  it  again,
you  must  slow  down  to  below
the  threshold  of 3 mph (5 km/h)
again.

TAILGATE

Tailgate release

This  enables  the  tailgate  to  be
unlocked  in  the  event  of  a  central
locking fault.
   -

Fold back the rear seats to gain

access to the lock from inside
the boot,

Insert a small screwdriver into

hole A of the lock to unlock the
tailgate.

"Tailgate open" warning

In this case, or following reconnection
of the battery, with the doors open, it
may be necessary to close the doors
manually, in order to reinitialise them,
and start the engine.

If the tailgate is not closed
properly, you are warned:

with the engine running , by

lighting of the "door open" war-

ning light, accompanied by a

message displayed brieﬂ y on the

multifunction display.

when the vehicle is moving , by

lighting of the "door open" war-

ning light, accompanied by an
audible signal and a message

displayed brieﬂ y on the multi-

function display.

The tailgate locks automati-

cally when the vehicle speed
reaches 6 mph (10 km/h).
It unlocks when one of the

doors is opened if the speed is below
3 mph (5 km/h) or when the central
locking button on the centre console
is pressed.

  When the door has stopped in an
intermediate position (neither  fully
open  nor  fully  closed),  only  the
remote control or the controls per-
mit electric operation of the door.
When  closing  requests  are  made
when  the  door  is  in  a  partially  open
position,  the  door  may  open  slightly
before closing.
When closing a door electrically when
the battery is low, you are advised to
guide  the  door  manually.  Recharge
the battery as soon as possible.
If the electric controls (remote control
or controls) no longer operate,  reini-
tialise the door(s) as follows:
   1.   Start the engine.
  2.   Manually open the door(s) fully.
  3.   Close the door(s) fully.
On  completion  of  this  procedure,
electric  operation  of  the  doors  is
restored.
However,  if  a  problem  persists
following  this  procedure,  contact  a
PEUGEOT  dealer.

Simultaneous locking or
unlocking of the tailgate and the
doors
The tailgate is locked or unlocked by
the remote control or from the driver’s
door lock.
To open, press the control 1 and lift
the tailgate.

TAILGATE

Tailgate release

This  enables  the  tailgate  to  be
unlocked  in  the  event  of  a  central
locking fault.
   -

Fold back the rear seats to gain

access to the lock from inside
the boot,

Insert a small screwdriver into

hole A of the lock to unlock the
tailgate.

"Tailgate open" warning

In this case, or following reconnection
of the battery, with the doors open, it
may be necessary to close the doors
manually, in order to reinitialise them,
and start the engine.

If the tailgate is not closed
properly, you are warned:

with the engine running , by

lighting of the "door open" war-

ning light, accompanied by a

message displayed brieﬂ y on the

multifunction display.

when the vehicle is moving , by

lighting of the "door open" war-

ning light, accompanied by an
audible signal and a message

displayed brieﬂ y on the multi-

function display.

The tailgate locks automati-

cally when the vehicle speed
reaches 6 mph (10 km/h).
It unlocks when one of the

doors is opened if the speed is below
3 mph (5 km/h) or when the central
locking button on the centre console
is pressed.

PANORAMIC SUNROOF

This sunroof is a panoramic assembly
which provides maximum brightness

and visibility in the passenger com-

partment.
It consists of two parts:
-

a ﬁ xed rear part,

a moving front part.

Each part has an independent
manual shutter.
The sunroof is controlled electrically
by a dial with 9 opening positions.

Operation

  To  open:   turn  the  dial  to  the  left
(nine possible settings).
Once  the  roof  is  open,  the  front
shutter cannot be closed.
  To  close:   return  the  control  to  the
initial position  "O" .

Reinitialisation

Following reconnection of the bat-

tery, in the event of a malfunction or
in the event of unwanted opening of

the roof on closing, the safety auto-

reverse must be reinitialised:
-

place the dial in the fully closed

position (initial position "O" ),

press the dial immediately,

continue to press until the roof

is fully closed.

Always remove the ignition
key when leaving the vehicle,
even for a short time.

In the event of contact during  operation
of  the  roof,  the  movement  of  the  roof
must be reversed. To do this, operate
the control concerned.
When  the  driver  operates  the  roof
control,  he  must  ensure  that  no  one
is  preventing  the  roof  from  closing
correctly.
The  driver  must  ensure  that  the
passengers use the sunroof correctly.
Be aware of children when operating
the roof.
Check  that  the  slides  are  clean
to   ensure  that  the  sunroof  slides
correctly.

  Safety auto-reverse
When  the  roof  meets  an   obstacle
while  closing,  it  partially  opens
again.

You  can  close  the  sunroof
using  the  remote  control
when  locking  (refer  to  the
corresponding chapter).

  The  safety  auto-reverse   function
is  not  operational  during  this
operation.

The tank must be ﬁ lled with fuel with

the engine off.


Open the fuel ﬁ ller ﬂ ap.

 Insert the key then turn it to

the left.

 Remove the cap and attach it to

the clip located on the inside of

the ﬂ ap.

A label on the inside of the ﬂ ap

indicates which type of fuel to use.
If you ﬁ ll your tank, do not continue

after the third cut-off of the pump

nozzle.  This  could  result  in  vehicle
malfunctions.
  The capacity of the tank is appro-
ximately 9 gallons (40 litres).
   

After ﬁ lling the tank, lock the cap

and close the ﬂ ap.

You have enough fuel left to cover
approximately 30 miles (50 km).

The electric opening of the

left-hand door is inhibited

when the fuel ﬁ ller ﬂ ap is

open.

The key cannot be removed from the

cap’s lock until the cap is reﬁ tted on

the tank.

FILLING THE FUEL TANK

When the tank’s minimum

level is reached, this war-

ning light comes on, accom-

panied by a message on the
multifunction display.

Low fuel level

LIGHTS STALK

Lights off

Automatic switching on
of lights.

Side lights

Dipped/main beam
headlamps

Dipped/Main beam change
Pull the stalk fully towards you.

Front fog lamps and rear fog
lamp

Rotate the ring B or C forwards to
switch on and backwards to switch
off. The status is displayed by the in-
dicator light on the instrument panel.

Vehicles ﬁ tted with a rear fog

lamp (ring B)

Rear fog lamp

Vehicles ﬁ tted with front fog

lamps and a rear fog lamp (ring C)

Front fog lamps (1st rotation
of the ring forwards)

These operate with the side lights
and dipped headlamps.

  Lights on
With the ignition off, a buzzer sounds
when  the  driver’s  door  is  opened,  if
you have left your lights on.
If  the  dipped  headlamps  remain
on,  with  the  ignition  off,  they  will  be
switched off automatically after thirty
minutes  maximum  to  prevent  dis-
charging of the battery.

This can only operate with the dipped
and main beam headlamps.

Front and rear lights

Selection is by turning ring A .

Front fog lamps and rear
fog lamp (2nd rotation of
the ring forwards)

Note : to switch off the rear fog lamp
and the front fog lamps, turn the ring
backwards twice in succession.

  Notes:
When the main beam headlamps are
switched on, the front fog lamps are
switched off.
When the lights are switched off au-
tomatically,  with  the  engine  running,
the front fog lamps and the side lights
will  remain  on  (turn  the  ring  back-
wards to switch the fog lamps off).

Direction indicators (ﬂ ashers)

Left: downwards.
Right: upwards.

When the lights are switched
off  automatically  or  when
the  dipped  headlamps  are
switched  off  manually,  with
the  engine  running,  the  fog

lamps and the side lights will
remain on.

In  good  or  rainy  weather,  both  day
and  night,  the  front  fog  lamps  and
the  rear  fog  lamp  are  dazzling  and
are prohibited.
Do not forget to switch them off when
they are no longer needed.

  Follow me home lighting
Leaving  the  dipped  headlamps  on
temporarily, after switching off the ig-
nition, facilitates the driver’s exit from
the vehicle when the light is poor.

Switching on


With the ignition off, "ﬂ ash" the

headlamps.



A second "headlamp ﬂ ash"

switches the function off.

  Switching off
The  follow  me  home  lighting  is
switched  off  automatically  following

locking of the doors, after a speciﬁ ed

time.

Daytime lights *

On vehicles which are equipped with
daytime lights, the dipped headlamps
come on when the vehicle is started.

Automatic switching on of

lights

The  side  lights  and  dipped  beam
headlamps  switch  on  automatically  if
the  light  is  poor  and  when  the  wind-
screen  wipers  operate  continuously.
They  switch  off  when  the  light  be-
comes  bright  enough  or  the  wind-
screen wipers are switched off.

In foggy weather or in

snow, the brightness

sensor can detect sufﬁ -

cient light, the lights will

not come on automati-

cally.

Do not cover the brightness sen-

sor, coupled with the rain sensor,

located in the centre of the wind-

screen behind the interior mirror.

It is used for automatic switching

on of the lights.

Coupling with the Follow Me

Home lighting
The  association  with  the  automatic
lighting  function  provides  the  follow
me  home  lighting  with  the  following
additional options:
   -

selection of maintaining of the
lighting for a duration of 15, 30
or 60 seconds in the vehicle pa-
rameters of the multifunction dis-

play conﬁ guration menu (except

in the case of the monochrome
display A for which the duration
is pre-set),

automatic  activation  of  the  fol-
low  me  home  lighting  when  the
automatic  lighting  function  is  in
operation.

  Activation
Turn  the  lighting  control  to  the
" AUTO " position.

Disarming
Turn the lighting control to a position
other than " AUTO ".

  Operating fault
If  the  brightness  sensor  does  not
function correctly, the lights come on
accompanied by the service warning
light,  an  audible  signal  and  a  mes-
sage on the multifunction display.
  Consult a PEUGEOT dealer.

Do not cover the brightness
sensor, coupled with the rain
sensor, located in the centre
of  the  windscreen  behind
the  interior  mirror;  the  as-
sociated functions would no
longer be controlled.

This warning light comes on
on the instrument panel.

The instruments and controls (instru-
ment  panel,  multifunction  display,
air  conditioning  control  panel,  ...)
are  only  lit  on  switching  to  the  auto-
matic switching on of the lights mode
or  when  the  lights  are  switched  on
manually.

* According to country.

Daytime lights *

On vehicles which are equipped with
daytime lights, the dipped headlamps
come on when the vehicle is started.

Automatic switching on of

lights

In foggy weather or in

snow, the brightness

sensor can detect sufﬁ -

cient light, the lights will

not come on automati-

cally.

Do not cover the brightness sen-

sor, coupled with the rain sensor,

located in the centre of the wind-

screen behind the interior mirror.

It is used for automatic switching

on of the lights.

Coupling with the Follow Me

Home lighting
The  association  with  the  automatic
lighting  function  provides  the  follow
me  home  lighting  with  the  following
additional options:
   -

selection of maintaining of the
lighting for a duration of 15, 30
or 60 seconds in the vehicle pa-
rameters of the multifunction dis-

play conﬁ guration menu (except

in the case of the monochrome
display A for which the duration
is pre-set),

automatic  activation  of  the  fol-
low  me  home  lighting  when  the
automatic  lighting  function  is  in
operation.

  Activation
Turn  the  lighting  control  to  the
" AUTO " position.

Disarming
Turn the lighting control to a position
other than " AUTO ".

Do not cover the brightness
sensor, coupled with the rain
sensor, located in the centre
of  the  windscreen  behind
the  interior  mirror;  the  as-
sociated functions would no
longer be controlled.

This warning light comes on
on the instrument panel.

* According to country.

HEADLAMP ADJUSTMENT

To avoid causing a nuisance to other
road  users,  the  height  of  the  head-
lamps should be adjusted in relation
to the load in the vehicle.
  0.   1 or 2 people in the front seats.

-.   3 people.
  1.   4 people.
  2.   4 people + maximum authorised

load.

3. Driver + maximum authorised

load.

The initial setting is position "0" .

WINDSCREEN WIPER STALK

Front windscreen wiper with

automatic wipe

Fast wipe (heavy rain).

Normal wipe (moderate
rain).

Intermittent wipe.

Off.

AUTO  Automatic or single wipe

(press downwards).

In the  I ntermittent position, the wiping
speed is in proportion to the speed of
the vehicle.
In   AUTO   mode,  the  wiping  speed  is
in  proportion  to  the  intensity  of  the

rainfall. The ﬁ rst press of the stalk

downwards activates the automatic
wipe.
Subsequent presses trigger a single
wipe.

Front windscreen wiper with

intermittent wipe

Fast wipe (heavy rain).

Normal wipe (moderate rain).

Intermittent wipe.

Off.

     Single wipe (press downwards).
In  the   I ntermittent  position,  the  wip-
ing  speed  is  in  proportion  to  the  ve-
hicle speed.

HEADLAMP ADJUSTMENT

To avoid causing a nuisance to other
road  users,  the  height  of  the  head-
lamps should be adjusted in relation
to the load in the vehicle.
  0.   1 or 2 people in the front seats.

-.   3 people.
  1.   4 people.
  2.   4 people + maximum authorised

load.

3. Driver + maximum authorised

load.

The initial setting is position "0" .

WINDSCREEN WIPER STALK

Front windscreen wiper with

automatic wipe

Fast wipe (heavy rain).

Normal wipe (moderate
rain).

Intermittent wipe.

Off.

AUTO  Automatic or single wipe

(press downwards).

In the  I ntermittent position, the wiping
speed is in proportion to the speed of
the vehicle.
In   AUTO   mode,  the  wiping  speed  is
in  proportion  to  the  intensity  of  the

rainfall. The ﬁ rst press of the stalk

downwards activates the automatic
wipe.
Subsequent presses trigger a single
wipe.

Front windscreen wiper with

intermittent wipe

Fast wipe (heavy rain).

Normal wipe (moderate rain).

Intermittent wipe.

Off.

     Single wipe (press downwards).
In  the   I ntermittent  position,  the  wip-
ing  speed  is  in  proportion  to  the  ve-
hicle speed.

   Windscreen wash
Pull the wiper stalk towards you. The
windscreen  wash,  then  the  wind-
screen  wipers,  operate  for  a  speci-

ﬁ ed time.

Low wash-wipe/headlamp wash

ﬂ uid level

On vehicles ﬁ tted with headlamp

washers, this is indicated by an audi-
ble signal or a message on the multi-
function display.
This information is given each time
the front or rear wash-wipe control is

operated, until the reservoir is ﬁ lled.

When you stop, ﬁ ll the wash-wipe/

headlamp wash reservoir or have it

ﬁ lled.

Do  not  cover  the  rain  sen-
sor  located  on  the  wind-
screen  behind  the  interior
mirror.

When using an automatic car wash,
switch off the ignition.
In winter, it is advisable to wait for the
windscreen to completely clear of ice
before operating the automatic wipe.

Rear windscreen wiper

Turn ring A

to the ﬁ rst notch

for intermittent wiping.

When reverse gear is engaged, if the
windscreen wipers are in operation,
the rear wiper will start wiping.

Turn ring A

past the ﬁ rst

notch; the windscreen wash
then the windscreen wiper

operate for a ﬁ xed period.

Automatic windscreen wipers

In  AUTO  mode, the windscreen wip-
ers operate automatically and  adapt
their  speed  to  the  intensity  of  the
rainfall .

  Activation
Activation  of  the  function  is  accom-
panied  by  a  message  on  the  multi-
function display.

The automatic windscreen wipers

function must be reactivated if the

ignition has been switched off for

more than one minute, by press-

ing the stalk downwards.

  Deactivation
Deactivation  of  the  function  is  ac-
companied  by  a  message  on  the
multifunction display.
The function is deactivated when the
windscreen wipers stalk is moved to
position  I ,  1  or  2 .
  In  the  event  of    malfunction   of  the
automatic  windscreen  wipers,  the
windscreen wipers will operate in in-
termittent mode.
Contact a  PEUGEOT  dealer to have
the system checked.

Rear windscreen wash

To activate or deactivate
this function, go to the
multi-function

display

conﬁ guration menu.

If there is a signiﬁ cant ac-

cumulation of snow or ice
and when using a bicycle

carrier on the tailgate, deactivate the
automatic rear wiping by going to the

multifunction display conﬁ guration

menu.

Special position of the front

windscreen wiper
In  the  minute  following  switching  off
of the ignition, any action on the stalk
positions  the  wipers  in  the  centre  of
the windscreen.
This  action  enables  you  to  position
the  wiper  blades  for  winter  parking,
cleaning or replacement (See corre-
sponding section).
To  park  the  wipers  after  this  has
been done, switch on the ignition and
operate the stalk.

   Windscreen wash
Pull the wiper stalk towards you. The
windscreen  wash,  then  the  wind-
screen  wipers,  operate  for  a  speci-

ﬁ ed time.

Low wash-wipe/headlamp wash

ﬂ uid level

On vehicles ﬁ tted with headlamp

washers, this is indicated by an audi-
ble signal or a message on the multi-
function display.
This information is given each time
the front or rear wash-wipe control is

operated, until the reservoir is ﬁ lled.

When you stop, ﬁ ll the wash-wipe/

headlamp wash reservoir or have it

ﬁ lled.

Do  not  cover  the  rain  sen-
sor  located  on  the  wind-
screen  behind  the  interior
mirror.

When using an automatic car wash,
switch off the ignition.
In winter, it is advisable to wait for the
windscreen to completely clear of ice
before operating the automatic wipe.

Rear windscreen wiper

Turn ring A

to the ﬁ rst notch

for intermittent wiping.

When reverse gear is engaged, if the
windscreen wipers are in operation,
the rear wiper will start wiping.

Turn ring A

past the ﬁ rst

notch; the windscreen wash
then the windscreen wiper

operate for a ﬁ xed period.

Automatic windscreen wipers

In  AUTO  mode, the windscreen wip-
ers operate automatically and  adapt
their  speed  to  the  intensity  of  the
rainfall .

  Activation
Activation  of  the  function  is  accom-
panied  by  a  message  on  the  multi-
function display.

The automatic windscreen wipers

function must be reactivated if the

ignition has been switched off for

more than one minute, by press-

ing the stalk downwards.

Rear windscreen wash

To activate or deactivate
this function, go to the
multi-function

display

conﬁ guration menu.

If there is a signiﬁ cant ac-

cumulation of snow or ice
and when using a bicycle

carrier on the tailgate, deactivate the
automatic rear wiping by going to the

multifunction display conﬁ guration

menu.

Special position of the front

COURTESY LIGHT

1. Front courtesy light
2. Map reading lights

In the permanently on posi-
tion, there are different dura-
tions of lighting:

Boot light

The  boot  light  is  located  in  the  left
boot trim.
It  comes  on  automatically  when  the
boot is opened and switches of auto-
matically when the boot is closed.

Front courtesy light

Permanently off.

Permanently on.

In this position, the courtesy
light comes on gradually:

when the vehicle is unlocked,

when the key is removed from
the ignition,

when the remote control locking
button is pressed, in order to
locate your vehicle.

It switches off gradually:
-

when the vehicle is locked,

when the ignition is switched on,

30 seconds after the last door is
closed.

Map reading lights

With the ignition on, press
the corresponding switch 2 .

when the ignition is off,
approximately ten minutes,

in energy economy mode,
approximately thirty seconds,

when the engine is running, no limit.

HORN

Press one of the spokes of the stee-
ring wheel.

HAZARD WARNING LIGHTS

Press the button, the direction indica-

tors ﬂ ash.
They can operate with the ignition
off.

Automatic lighting of hazard
warning lights

When braking in an emergency, de-
pending on the force of deceleration,
the hazard warning lights come on au-
tomatically. They switch off automati-

cally the ﬁ rst time you accelerate.
It is also possible to switch them off
by pressing the button on the fascia.

TYRE UNDER-INFLATION
DETECTION

Sensors ﬁ tted in each valve check

the pressure of the tyres while dri-

ving and trigger a warning in the

event of malfunction (speed above

12 mph (20 km/h)).

The tyre under-inﬂ ation detection

system is an aid to driving which does

not replace the need for the driver to

be vigilant or to drive responsibly.

Flat tyre

This warning light comes

on on the instrument panel,

accompanied by an audible

signal and a message on the

multifunction display locating

the wheel concerned.

 Check the tyre pressures as

soon as possible.

This check must be carried out when

the tyres are cold.

HORN

Press one of the spokes of the stee-
ring wheel.

HAZARD WARNING LIGHTS

Press the button, the direction indica-

tors ﬂ ash.
They can operate with the ignition
off.

Automatic lighting of hazard
warning lights

When braking in an emergency, de-
pending on the force of deceleration,
the hazard warning lights come on au-
tomatically. They switch off automati-

cally the ﬁ rst time you accelerate.
It is also possible to switch them off
by pressing the button on the fascia.

TYRE UNDER-INFLATION
DETECTION

Sensors ﬁ tted in each valve check

the pressure of the tyres while dri-

ving and trigger a warning in the

event of malfunction (speed above

12 mph (20 km/h)).

The tyre under-inﬂ ation detection

system is an aid to driving which does

not replace the need for the driver to

be vigilant or to drive responsibly.

Flat tyre

This warning light comes

on on the instrument panel,

accompanied by an audible

signal and a message on the

multifunction display locating

the wheel concerned.

 Check the tyre pressures as

soon as possible.

This check must be carried out when

the tyres are cold.

Peugeot 1007 (2008 year). Instruction - part 6
