Peugeot 607 Dag (2009 year). Instruction - part 12

159

Press the MENU button for more
than 2 seconds to access the

following ﬂ ow chart.

VOICE COMMANDS LIST

Press the Music button several
times in succession to access the

following settings.

AUTO VOLUME CORRECTION

Each audio source (Radio, CD, MP3,

Jukebox, CD changer) has its own

separate settings.

AUDIO/TELEPHONE DIAGNOSTICS

GPS COVERAGE

UNIT BACKUP POWER

UNIT DESCRIPTION

NAVIGATION DEMONSTRATION

SERVICES CONFIGURATION

LOUDNESS CORRECTION

TREBLE

BASS

MUSICAL AMBIENCE

FR - RR BALANCE

LH - RH BALANCE

160

There is a difference in

sound quality between
the different audio

sources (radio, CD...).

Check that the audio settings (Volume, Bass,

Treble, Ambience, Loudness) are adapted to

the sources listened to. It is advisable to set

the AUDIO functions (Bass, Treble, Front-Rear

Balance, Left-Right Balance) to the middle

position, select the musical ambience "None"

and set the loudness correction to the "Active"

position in CD mode or to the "Inactive" position

in radio mode.

For optimum sound quality, the audio settings (Volume, Bass, Treble,

Ambience, Loudness) can be adapted to the different sound sources,

which may result in audible differences when changing source (radio,

CD...).

The CD is ejected
automatically or is not

played by the player.

The CD is protected by an anti-pirating protection

system which is not recognised by the audio equipment.

The CD is inserted upside down, is unplayable, does not contain any audio

data or contains an audio format which the player cannot play.

The CD player sound

is poor.

Insert good quality CDs and store them in

suitable conditions.

The CD used is scratched or of poor quality.

The audio equipment settings (bass, treble, ambiences) are unsuitable.

Set the treble or bass level to 0, without selecting

an ambience.

The table below groups together the answers to the most frequently asked questions.

QUESTION

SOLUTION

ANSWER

FREQUENTLY ASKED QUESTIONS

- Check that the CD is inserted in the player the

right way up.

- Check the condition of the CD: the CD cannot

be played if it is too damaged.

- Check the content in the case of a recorded

CD: consult the advice in the Audio section.

- The audio equipment’s CD player does not

play DVDs.

- Due to inadequate quality, certain recorded

CDs will not be played by the audio system.

161

QUESTION

SOLUTION

ANSWER

The environment (hills, buildings, tunnels, basement car parks...) block

reception, including in RDS mode.

The aerial is absent or has been damaged (for example when going

through a car wash or into an underground car park).

This phenomenon is normal and does not

indicate a failure of the audio equipment.

Have the aerial checked by a PEUGEOT dealer.

Sound cut-outs of
1 to 2 seconds in radio

mode.

During this brief sound cut-out, the RDS searches for any frequency

permitting better reception of the station.

Deactivate the RDS function if the phenomenon

is too frequent and always on the same route.

With the engine off,
the audio equipment
switches off after a few

minutes of use.

When the engine is switched off, the audio equipment operating time

depends on the battery charge.

The switch-off is normal: the audio equipment switches to economy mode

and switches off to prevent discharging of the vehicle’s battery.

The stored stations do

not function (no sound,

87.5 Mhz is displayed...)

An incorrect waveband is selected.

Press the BAND AST button to return to the

waveband (AM, FM1, FM2, FMAST) on which the

stations are stored.

Start the vehicle’s engine to increase the battery

charge.

The quality of reception
of the radio station

listened to gradually
deteriorates or the stored
stations do not function

(no sound, 87.5 Mhz is

displayed...).

The vehicle is too far from the transmitter used by the station listened to or

there is no transmitter in the geographical area through which the vehicle

is travelling.

Activate the RDS function to enable the system

to check whether there is a more powerful

transmitter in the geographical area.

162

QUESTION

SOLUTION

ANSWER

The TRAFFIC INFO

box is ticked. However,

certain trafﬁ c jams

along the route are not

indicated in real time.

On starting, it is several minutes before the system begins to receive the

trafﬁ c information.

Wait until the trafﬁ c information is being received

correctly (displaying of the trafﬁ c information

symbols on the map).

In certain countries, only major routes (motorways, ...) are listed for the

trafﬁ c information.

The time taken to
calculate a route
sometimes seems

longer than usual.

This phenomenon is normal. The system is

dependent on the trafﬁ c information available.

The performance of the system may slow down temporarily if a CD is

being copied onto the Jukebox at the same time as a route is being

calculated.

Wait until the CD has been copied or stop the

copying before starting the guidance function.

Does the emergency call

function work without a

SIM card?

Certain national regulations impose the presence of a SIM card in order to

make an emergency call.

Insert a valid SIM card in the slot on the system.

My SIM card is not

recognised.

The system accepts 3.3 V SIM cards, the old 5 V and 1.8 V SIM cards are

not recognised.

Contact your telephone operator.

The altitude is not

displayed.

On starting, the initialisation of the GPS may take up to 3 minutes to

receive more than 4 satellites correctly.

Wait until the system has started up completely.

Check that there is a GPS coverage of at least

4 satellites (long press on the MENU button, then

select AUDIO/TELEPHONE DIAGNOSTICS,

then GPS COVERAGE).

Depending on the geographical environment (tunnel, ...) or the weather,

the conditions of reception of the GPS signal may vary.

This phenomenon is normal. The system is
dependent on the conditions of reception of the

GPS signal.

163

QUESTION

SOLUTION

ANSWER

The route is not

calculated successfully.

The exclusion criteria may conﬂ ict with the current location (exclusion of

toll roads on a motorway with tolls).

Check the exclusion criteria.

There is a long wait after

inserting a CD.

When a new medium is inserted, the system reads a certain amount of

data (folder, title, artist, etc.). This may take a few seconds.

This phenomenon is normal.

I cannot connect my

Bluetooth telephone.

The telephone’s Bluetooth function may be switched off or the equipment

may not be visible.

- Check that your telephone’s Bluetooth function

is switched on.

- Check that your telephone is visible.

164

JBL EQUIPMENT

The JBL Hi-Fi system guarantees full respect

of the musical nuances to provide high ﬁ delity

sound reproduction in your vehicle.

At the heart of the system, a 240 watt

multifunction ampliﬁ er (1) independently

controls 12 high-deﬁ nition acoustic speakers.

These speakers make it possible to obtain

optimum reproduction and distribution of the

sound in the vehicle, both in the front and in the

rear.

The basic functions remain those of the audio

equipment.

No further adjustment is required.

However, to beneﬁ t fully from your JBL audio

system, we recommend that you set the AUDIO

functions (BASS, TREB, FAD, BAL) to the

central position and the Loudness to the "ON"

position.

PRESENTATION

ADJUSTMENT IN CD MODE

EQUIPMENT

If your 607 is ﬁ tted with a JBL Hi-Fi audio
system, this is designed speciﬁ cally for
the passenger compartment of your
vehicle.

The speakers are located:

in the fascia panel: two Tweeters (4) incorporated in two

Mid Range Speakers (5) for clear front reproduction of the

sound image.

in the front doors: two Woofers (6) for reproduction of the

bass tones (low frequencies).

in the rear doors: two Tweeters (2) and two Woofers (3)

permitting a balance of the frequencies (from bass to treble) in

the rear seats.

on the rear shelf: two Subwoofers (7) designed speciﬁ cally for

reproduction of the extreme bass tones (very low frequencies)

for true listening pleasure; you will appreciate the impact and

the depth without noticing that the sound is coming from the

rear of the vehicle.

607: the concert hall
