127

Press the dial to conﬁ rm the selection.

Turn the dial and select the letters of

the town one by one conﬁ rming each

time by pressing the dial.

Turn the dial and select OK.

Press the dial to conﬁ rm the selection.

To speed up the process, the POST

CODE can be entered instead of the

name of the town.

Use the alphanumeric keypad to

enter the letters and digits and "C" to

correct.

Press the dial to conﬁ rm the selection.

Select OK on the ENTER AN

ADDRESS page.

Repeat steps 8 to 12 for the ROAD and N° functions.

Select the STORE function to record the address entered in a

directory record and press the dial to conﬁ rm the selection.

The points of interest (POI) indicate all of the service locations in

the vicinity (hotels, various businesses, airports, ...).

STORE

PARIS

POI

128

GUIDANCE OPTIONS

GPS

The route chosen by the audio equipment depends directly on the guidance

options.

Changing these options may completely change the route.

Press the MENU button.

Turn the dial and select the

NAVIGATION GUIDANCE function.

Press the dial to conﬁ rm the selection.

Turn the dial and select the

GUIDANCE OPTIONS function.

Turn the dial and select the DEFINE

CALCULATION CRITERIA function.

Press the dial to conﬁ rm the selection.

Turn the dial and select, for example,

the DISTANCE/TIME function.

GUIDANCE OPTIONS

DISTANCE/TIME

DEFINE CALCULATION CRITERIA

129

Turn the dial and select the TRAFFIC

INFO function if it is not ticked.

Press the dial to conﬁ rm the selection.

Select OK and press the dial to

conﬁ rm.

Press the dial to conﬁ rm the selection.

Tick this box for optimum operation of the trafﬁ c information,

diversions will be suggested.

SETTING HAZARDOUS AREAS
ALERT PARAMETERS

Turn the dial and select the

SET HAZARDOUS AREAS

PARAMETERS function, then press

the dial to conﬁ rm the warning

message. Press the dial to conﬁ rm

the selection.

Select:

- visual warnings,

- audible warnings with an

announcement duration

(in seconds),

- warn during guidance only, then

select OK and press the dial to

conﬁ rm.

These functions are only available if the hazardous areas have

been downloaded and installed on the system.

The hazardous areas are, in general, ﬁ xed speed cameras, level

crossings, dangerous uphill and downhill gradients. They may

change on a regular basis.

Repeat steps 1 to 5 of the guidance option.

TRAFFIC INFO

SET HAZARDOUS AREAS PARAMETERS

130

Press the dial then adjust the volume
of the speech synthesis or select the

DEACTIVATE function and press the

dial to conﬁ rm.

GPS

GUIDANCE SPEECH SYNTHESIS

Press the dial to conﬁ rm the selection.

During announcements, the volume of each speech synthesis

function (guidance, trafﬁ c information...) can be adjusted directly

using the volume button.

Select the ADJUST SPEECH

SYNTHESIS function and press the

dial to conﬁ rm.

Select OK and press the dial to

conﬁ rm.

Press the MENU button.

Turn the dial and select the

NAVIGATION GUIDANCE function.

Press the dial to conﬁ rm the selection.

Turn the dial and select the

GUIDANCE OPTIONS function.

GUIDANCE OPTIONS

ADJUST SPEECH SYNTHESIS

DEACTIVATE

131

GPS

Press the MENU button.

Turn the dial and select the MAP

function.

Press the dial to conﬁ rm the selection.

Turn the dial and select the

MAP DETAILS function.
Permits selection of the services

which can be seen on the map (hotels,

restaurants, hazardous areas...).

ACTIONS ON THE MAP

Press the dial to conﬁ rm the selection.

Turn the dial and select the

orientation of your choice.

Select OK and press the dial to

conﬁ rm.

Repeat steps 1 to 3 then turn the dial

and select the MAP ORIENTATION

function.

MAP ORIENTATION

For improved visibility, beyond the scale of 6 miles (10 km), the map

automatically switches to North Orientation.

MAP DETAILS

MAP ORIENTATION

132

Press the MENU button.

Press the dial to conﬁ rm the selection.

Turn the dial and select the MAP

function.

Turn the dial and select the MAP IN

WINDOW or FULL SCREEN MAP

tab.

Select OK

and press the dial to conﬁ rm.

Press the dial to conﬁ rm the selection.

Turn the dial and select the DISPLAY

MAP function.

DISPLAYING THE MAP IN A WINDOW OR
IN FULL SCREEN MODE

GPS

DISPLAY MAP

FULL SCREEN MAP

MAP IN WINDOW

133

List of POI

GPS

Flying club

Airport

Lay-by

Bowling alley

Casino

Business park

Sports centre

Town centre

Cinema

Sports complexes

Culture/Museum

Vineyard

Garage

Station

Dock station

Bus station

Hospitals

Hotels

Vehicle hire

Town halls

Historical monuments

Tourist information

Theme park

Park/Garden

Park and ride

Car park

Covered parking

Skating rink

Ports

Restaurant

Shopping

Show/Exhibition

Winter sports centre

Service station

Supermarkets

Golf course

Tourism

University

Night life

134

During guidance, press the MENU

button.

Turn the dial and select the

NAVIGATION GUIDANCE function.

Press the dial to conﬁ rm the selection.

Turn the dial and select the

JOURNEY LEGS AND ROUTE

function.

Select OK and press the dial to

conﬁ rm the order of the stages.

When the new address has been
entered, select OK and press the dial

to conﬁ rm.

Enter for example a new address.

Select the ADD A STAGE function

(9 stages maximum) and press the

dial to conﬁ rm.

Press the dial to conﬁ rm the selection.

Select STRICT (the stage must be completed in order to continue to

the next destination) or PROXIMITY then press the dial to conﬁ rm.

GPS

JOURNEY LEGS AND ROUTE

ENTER AN ADDRESS

ADD A STAGE

135

We recommend a ﬁ lter on the route and a ﬁ lter around the vehicle of:
   -   3 miles (5 km) or 6 miles (10 km) for a region with heavy trafﬁ c,
  -   12 miles (20 km) for a region with a normal level of trafﬁ c,
  -   60 miles (100 km) for long journeys (motorway).

Press the MENU button.

Turn the dial and select the TRAFFIC

INFORMATION function.

Press the dial to conﬁ rm the selection.

Turn the dial and select the FILTER

TRAFFIC INFORMATION function.

TRAFFIC INFORMATION

Press the dial to conﬁ rm the

selection.

Select the GEOGRAPHIC FILTER

function and press the dial to conﬁ rm.

Turn the dial and select the ﬁ lter of

your choice.

Select OK and press the dial to

conﬁ rm.

FILTER TRAFFIC INFORMATION

GEOGRAPHIC FILTER

136

Turn the dial and select the

CONFIGURE MESSAGE

ANNOUNCEMENT function.

Select the READ MESSAGES tab.

The Trafﬁ c Information Messages will

be read by the voice synthesiser.

Select the NEW MESSAGE DISPLAY

tab.

The trafﬁ c information messages

are extended to the ﬁ lters selected

(geographic...) and can also be

displayed when guidance is not active.

Press the MENU button.

CONFIGURING THE TMC MESSAGE
ANNOUNCEMENTS

We recommend that you do not tick the NEW MESSAGE DISPLAY tab for regions with heavy trafﬁ c.

Turn the dial and select the TRAFFIC

INFORMATION function.

Press the dial to conﬁ rm the selection.

TRAFFIC INFORMATION

Select OK and press the dial to

conﬁ rm.

NEW MESSAGE DISPLAY

READ MESSAGES

CONFIGURE MESSAGE ANNOUNCEMENT

137

RADIO

SELECTING A STATION

Press the SOURCE button several
times in succession and select the

RADIO.

Press the BAND AST button to select

a waveband: FM1, FM2, FMast, AM.

Brieﬂ y press one of the buttons to
carry out an automatic search of the

radio stations.

Press one of the buttons to carry out a

manual search of the radio stations.

Press the LIST button to display the
list of stations received locally

(60 maximum).
To update this list, press for more than

two seconds.

The external environment (hills, buildings, tunnels, basement car parks, ...) may block reception,
including in RDS mode. This is a normal effect of the way in which radio waves are transmitted and does
not indicate any failure of the audio equipment.

RDS

Select ACTIVATE FREQUENCY

FOLLOWING (RDS) then press OK.

RDS appears on the display.

Select the FM WAVEBAND

PREFERENCES function then press OK.

Select AUDIO FUNCTIONS then

press OK.

Press the MENU button.

The RDS, if displayed, enables you to continue listening to the same

station by automatic retuning to alternative fequencies. However, in

certain conditions, coverage of an RDS station may not be assured

throughout the country as radio stations do not cover 100 % of the

territory. This explains the loss of reception of the station during a

journey.

FM WAVEBAND PREFERENCES

ACTIVATE FREQUENCY FOLLOWING (RDS)

138

05 AUDIO/VIDEO

The MP3 format, an abbreviation of MPEG 1.2 & 2.5 Audio Layer

3, is an audio compression standard which permits the recording of

several tens of music ﬁ les on a single disc.

In order to be able to play a recorded CDR/DVDR or CDRW/

DVDRW, when recording it is preferable to select standards

ISO 9660 level 1.2 or Joliet.

If the disc is recorded in another format, it may not be played

correctly.

It is recommended that the same recording standard is always used

for an individual disc, with as low a speed as possible (4x maximum)

for optimum sound quality.

In the particular case of a multi-session CD, the Joliet standard is

recommended.

The audio equipment will only play audio ﬁ les with the extension

".mp3" with a sampling rate of 22.05 KHz or 44.1 KHz. No other type

of ﬁ le (.wma, .mp4, .m3u...) can be played.

It is advisable to restrict ﬁ le names to 20 characters without using

special characters (e.g.: " ? ; ù) to avoid any playing or displaying

problems.

Insert circular compact discs only. Some anti-pirating

systems, on original discs or CDs copied using

a personal recorder, may generate malfunctions

regardless of the quality of the original player.

Insert an audio CD or an MP3 compilation in the player,

play begins automatically.

If the player already contains a disc,

press the SOURCE button several
times in succession and select CD to

listen to it.

Press one of the buttons to select a

track on the CD.

Press the LIST button to display

the list of tracks on the CD or of the

directories of the MP3 compilation.

The playing and displaying of an MP3 compilation may depend on

the recording programme and/or the parameter settings used. We

recommend use of the ISO 9660 recording standard.

MP3 CD

INFORMATION AND ADVICE

PLAYING A CD OR AN MP3 COMPILATION

139

the dial to conﬁ rm.

Select COPY CD TO JUKEBOX and

press the dial to conﬁ rm.

Select COMPLETE CD to copy
the entire CD and press the dial to

conﬁ rm.

The AUTO CREATION tab automatically copies the CD by default

into an album of the type "album n°...".

The audio or MP3 CD is copied onto the hard disc. Copying may

take approximately 20 minutes depending on the duration of the CD.

During this copying phase, it is not possible to listen to the albums

previously recorded on the hard disc or the CDs.

Select the letters one by one and select

OK to conﬁ rm.

If it is not an MP3 CD, the Jukebox automatically compresses the

CD in MP3 format. The compression may take approximately

20 minutes depending on the duration of the CD. During this

compression phase, it is possible to listen to the CD or to albums

previously recorded on the hard disc.

Select AUDIO FUNCTIONS and press

the dial to conﬁ rm.

Insert a CD or an MP3 compilation

and press the MENU button.

JUKEBOX FUNCTION

COPYING A CD ONTO THE HARD DISC

COPY CD TO JUKEBOX

COMPLETE CD

CREATE ALBUM

A long press on the SOURCE button starts the copying of the CD.

When copying an MP3 CD, the Jukebox only retains the last album

level. It is not possible to copy ﬁ les from the Jukebox to a CD.

The STOP THE CD COPY action does not delete the ﬁ les which

have already been transferred onto the jukebox hard disc.

140

Select USB and press the dial to

conﬁ rm.

Select COPY USB TO JUKEBOX and

press the dial to conﬁ rm.

Select COMPLETE DISC to copy the

entire USB stick and press the dial to

conﬁ rm.

Select AUDIO FUNCTIONS and press

the dial to conﬁ rm.

Insert a USB stick in the space provided

and press the MENU button.

JUKEBOX FUNCTION

COPYING AN MP3 USB STICK ONTO THE HARD DISC

Press one of the buttons to select a

track on the USB stick.

Press the LIST button to display the list

of folders on the MP3 USB stick.

To eject the USB stick, press the MENU button, select AUDIO

FUNCTIONS, USB, then select EJECT USB.

The playing and displaying of an MP3 compilation may depend on

the parameters programme used.

JUKEBOX FUNCTION

PLAYING AN MP3 USB STICK

Insert a USB stick in the space provided.

If another source is being played, press the SOURCE

button several times in succession and select USB to

play it.

USB

COPY USB TO JUKEBOX

AUDIO FUNCTIONS

COMPLETE DISC

141

Press the MENU button.

Select AUDIO FUNCTIONS and

press the dial to conﬁ rm.

Select the JUKEBOX function and

press the dial to conﬁ rm.

Select the JUKEBOX MANAGEMENT

function and press the dial to conﬁ rm.

Select the album to be renamed and

press the dial to conﬁ rm.

Select the RENAME tab and press the

dial to conﬁ rm.

Turn the dial and select the letters of

the album title one by one conﬁ rming

each time by pressing the dial.

Use the alphanumeric keypad to enter the letters of the album title

one by one.

JUKEBOX FUNCTION

RENAMING AN ALBUM

AUDIO FUNCTIONS

JUKEBOX

JUKEBOX MANAGEMENT

RENAME

142

Press the SOURCE button several
times in succession and select the

JUKEBOX function.

Press the LIST button.

Turn the dial to select the ﬁ les.

Press the ESC button to return to the ﬁ rst ﬁ le level.

JUKEBOX

Select OK and press the dial to

conﬁ rm.

To rename the tracks of an album, follow the same procedure,

selecting the tracks to be renamed.

Use the ESC button to exit from the list of tracks.

Select the DELETE function to delete an album or a

track from the Jukebox.

JUKEBOX FUNCTION

LISTENING TO THE JUKEBOX

DELETE

Content .. 8 9 10 11 ..
