Peugeot 508 (2016 year). Instruction

Instruments

508_en_Chap01_instrument-bord_ed01-2016

Setting the date and time

Audio system without touch screen

Press MENU.

using the arrows, select "Personalisation-
configuration" and confirm.

using the arrows, select "Display
configuration" and confirm.

using the arrows, select "Date and time
adjustment" and confirm.

Select the setting to be modified. Confirm
by pressing OK, then make the change and
confirm again to save the modification.

Adjust the settings one by one, confirming by
pressing the OK button. Next select the "OK"
tab on the screen then confirm to exit from the
"Date and time adjustment" menu.

Instruments

508_en_Chap01_instrument-bord_ed01-2016

Audio system with touch screen

F Select the "Settings" menu.

F In the secondary page, press on

"Time/Date".

F Select "Adjust time" or "Adjust date"

and modify the settings using the numeric
keypad, then confirm.

F Press "Confirm" to quit.

Access

508_en_Chap02_ouvertures_ed01-2016

System for the central locking or unlocking
of the vehicle using the door lock or from a
distance.
It is also used to open and close the fuel filler
cap, locate and start the vehicle, as well as
providing protection against theft.

Remote control key

Unfolding / Folding the key

F Press this button to unfold or fold the key.

Total unlocking

Using the key

F turn the key toward the front of the vehicle

to unlock the vehicle.

If you do not press the button, you risk
damaging the remote control.

F Press the open padlock to unlock

the vehicle.

Using the remote control

Holding this button down
opens the windows
automatically.

unlocking is confirmed by rapid
flashing of the direction indicators for
approximately two seconds.
According to version, the door mirrors
unfold at the same time.

Access

508_en_Chap02_ouvertures_ed01-2016

Selective unlocking

Unlocking the boot

Using the remote control

Boot only function activated

Don't forget to lock your boot
afterwards.

each unlocking action is confirmed by
rapid flashing of the direction indicators
for about two seconds.
According to version, the door mirrors
unfold at the same time as the first
unlocking action.

F Press this button to unlock the

vehicle and open the boot.

this is set in the instrument panel
configuration menu.

this function is deactivated by default.
F the use of the remote control then unlocks

and/or opens only the boot.

Normal locking

Using the key

F turn the key toward the rear of the vehicle

to lock the vehicle totally.

F Press the closed padlock to lock

the vehicle totally.

Using the remote control

this is set via the instrument panel
screen configuration menu.
total unlocking is activated by
default.

Using the remote control

F to unlock the driver's door only

press the open padlock once.

F to unlock the other doors and the boot,

press the open padlock again.

Access

508_en_Chap02_ouvertures_ed01-2016

Maintaining the locking action
(remote control or manual
key) automatically closes the
windows and sunroof.
Contact a PeugeOt for
deactivation of this function.

Locking is confirmed by fixed
illumination of the direction indicators
for about two seconds.
According to version, the door mirrors
fold at the same time.

Deadlocking

Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the manual central
locking control button.
You should therefore never leave
anyone inside the vehicle when it is
deadlocked.

Using the key

F turn the key rearward in the driver's door

lock to totally lock the vehicle.

F turn the key rearward again within five

seconds to deadlock the vehicle.

Using the remote control

Deadlocking is confirmed by the fixed
illumination of the direction indicators
for approximately two seconds.

F Press the closed padlock to lock

the vehicle completely or press
the closed padlock for more
than two seconds to close the
windows automatically in addition
to locking.

F Press the closed padlock again within

five seconds to deadlock the vehicle.

Access

508_en_Chap02_ouvertures_ed01-2016

F Press the closed padlock to

locate your locked vehicle in a
car park.

Locating your vehicle

this is indicated by lighting of the courtesy
lamps and flashing of the direction indicators
for a few seconds.

Anti-theft protection

Electronic engine immobiliser

the key contains an electronic chip which has
a special code. When the ignition is switched
on, this code must be recognised in order for
starting to be possible.
this electronic engine immobiliser locks the
engine management system a few moments
after the ignition is switched off and prevents
starting of the engine by anyone who does not
have the key.

In the event of a fault, you are
informed by illumination of this
warning lamp, an audible signal and
a message in the screen.

Keep safely, away from your vehicle,
the label attached to the keys given to
you on acquisition of the vehicle.

In this case, your vehicle will not start; contact
a PeugeOt dealer as soon as possible.

Access

508_en_Chap02_ouvertures_ed01-2016

Back-up procedure - Remote controls

Locking - unlocking the
driver's door

Insert the key in the door lock to lock or unlock
the door.

Locking - unlocking the
passenger doors

Locking

F On the rear doors, check that the child lock

is not on.

F Remove the black cap located on the edge

of the door, using the key.

F Insert the key into the aperture without

forcing, then without turning, move the
latch sideways towards the inside of the
door.

F Remove the key and refit the cap.

Unlocking

Pull the interior door handles.

If your vehicle has an alarm, it will not
be activated and deactivated on locking
and unlocking the vehicle.
Opening a door will trigger the alarm; it
will stop when the ignition is switched
on.

Access

508_en_Chap02_ouvertures_ed01-2016

Battery ref.: CR2032 / 3 volts.
this replacement battery is available from a
PeugeOt dealer or a qualified workshop.
A message appears in the instrument panel
screen when replacement of the battery is
needed.
F unclip the cover using a small screwdriver

at the cutout.

F  Lift off the cover.
F  Remove the flat battery from its location.
F  Fit the new battery into its location

observing the original direction of fitment.

F Clip the cover onto the casing.

Remote control fault

Following disconnection of the vehicle battery,
replacement of the remote control battery or
in the event of a fault with the remote control,
you can no longer unlock, lock or locate your
vehicle.
F First of all, use the key in the door lock to

unlock or lock your vehicle.

F then, reinitialise the remote control.
If the problem persists, contact a PeugeOt
dealer or a qualified workshop as soon as
possible.

Reinitialisation

F Switch the ignition on.
F Immediately press one of the remote

control buttons for a few seconds.

F Switch the ignition off.
the remote control is fully operational again.

Do not throw the remote control
batteries away, they contain metals
which are harmful to the environment.
take them to an approved collection
point.

Changing the battery of the key

Access

508_en_Chap02_ouvertures_ed01-2016

System that allows the opening, closing
and starting of the vehicle while keeping the
electronic key on your person. It can also be
used as a remote control.

"Keyless entry and Starting" electronic key

Total unlocking

Using the remote control

F Press the open padlock to unlock

the vehicle.

With the key on your person

F With the electronic key on your person

and in the recognition zone, pass your
hand behind the door handle to unlock the
vehicle, then pull on the handle to open
the door.

Your passengers can also open the doors,
with the exception of the boot, as soon as the
electronic key is in the recognition zone.

Holding this button down
opens all of the windows
remotely.

For reasons of safety and theft protection,
do not leave your electronic key in the
vehicle, even when you are close to it.
It is recommended that you keep it on
your person.

unlocking is confirmed by rapid
flashing of the direction indicators for
approximately two seconds.
According to version, the door mirrors
unfold at the same time.

Access

508_en_Chap02_ouvertures_ed01-2016

Selective unlocking

F to unlock the driver's door only

press the open padlock once.

Using the remote control

this is set via the instrument panel
screen configuration menu.
total unlocking is activated by
default.

With the electronic key on your
person

F to unlock only the driver's door with the

electronic key on your person, pass your
hand behind the driver's door handle then
pull the handle to open the door.

F to unlock the vehicle totally, pass your

hand behind one of the passenger door
handles, on the side of the vehicle where
the electronic key is located, then pull the
door handle.

each unlocking is confirmed by rapid
flashing of the direction indicators for
about two seconds.
According to version, the door mirrors
unfold at the same time as the
first unlocking action.

F to unlock the other doors and the boot,

press the open padlock again.

Accumulations (water, dust, grime,
salt...) on the inner surface if the door
handle may affect detection.
If cleaning the inner surface of the door
handle using a cloth does not restore
detection, contact a PeugeOt dealer
or a qualified workshop.
A sudden splash of water (stream of
water, high pressure jet washer, …)
may be identified by the system as the
desire to open the vehicle.

Access

508_en_Chap02_ouvertures_ed01-2016

Unlocking the boot

Using the remote control

F Press this button to unlock the

vehicle and open the boot.

With the electronic key on your
person

F With the electronic key in the recognition

zone, press button 1 (Saloon) or press
button 2 (SW and non-hybrid RXH) to
unlock the vehicle and open the boot.

Boot only function activated

this is set in the instrument panel
configuration menu.

this function is deactivated by default.
F use of the remote control or the electronic

key then unlocks and/or opens only the
boot.

Don't forget to lock your boot
afterwards.

Access

508_en_Chap02_ouvertures_ed01-2016

Normal locking

Using the remote control

F Press the closed padlock to lock

the vehicle totally.

With the electronic key on your person

Maintaining the locking action
(remote control or manual
key) automatically closes the
windows and sunroof.
Contact a PeugeOt for
deactivation of this function.

Locking is confirmed by fixed lighting
of the direction indicators for about
two seconds.
According to version, the door mirrors
fold at the same time.

F From the boot (SW and non-hybrid

RXH only), with the electronic key in the
recognition zone, press the right-hand
tailgate button to lock the vehicle.

F With the electronic key in the recognition

zone, press with a finger or thumb on
the door handle (at the markings) to lock
the vehicle.

Access

508_en_Chap02_ouvertures_ed01-2016

If one of the doors or the boot is still
open or if the key for Keyless entry and
Starting system has been left inside
the vehicle or if the ignition is on, the
central locking does not take place.
When the vehicle is locked, if it is
unlocked inadvertently, it will lock itself
again automatically after about thirty
seconds unless a door is opened.
If the alarm was previously activated,
it will not be reactivated automatically.
the folding and unfolding of the door
mirrors by the remote control can be
deactivated by a PeugeOt dealer or a
qualified workshop.

As a safety measure (children on
board), never leave the vehicle without
taking the key for the Keyless entry and
Starting system, even for a short period.
guard against theft when the key for the
Keyless entry and Starting system is
in the recognition zone with the vehicle
unlocked.
In order to preserve the charge of the
cell battery in the remote control, the
"hands-free" functions go into extended
stand-by after 21 days of non-use. to
restore these functions, press one of
the remote control buttons or start the
engine with the electronic key in the
reader.

Access

508_en_Chap02_ouvertures_ed01-2016

Deadlocking

Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the manual central
locking button.
You should therefore never leave
anyone inside the vehicle when it is
deadlocked.

Using the remote control

F Press the closed padlock to

lock the vehicle totally or press
the closed padlock for more
than two seconds to close the
windows automatically in addition
to locking.

With the electronic key on your
person

At the doors:
F With the electronic key in the recognition

zone, press with a finger or thumb on the
door handle (at the markings) to lock the
vehicle.

F Within five seconds, press the door handle

again to deadlock the vehicle.

At the tailgate (SW and non-Hybrid RXH only) :
F With the electronic key in the recognition

zone, press the button to lock the vehicle.

F Within five seconds, press the button again

to deadlock the vehicle.

F Press the closed padlock again within

five seconds to deadlock the vehicle.

Deadlocking is confirmed by the fixed
illumination of the direction indicators
for approximately two seconds.

Access

508_en_Chap02_ouvertures_ed01-2016

F Press the closed padlock to

locate your locked vehicle in
a car park.

Locating your vehicle

this is indicated by lighting of the courtesy
lamps and flashing of the direction indicators
for a few seconds.

Anti-theft protection

Electronic engine immobiliser

In the event of a fault, you are
informed by illumination of this
warning lamp, an audible signal and
a message in the screen.

In this case, your vehicle will not start; contact
a PeugeOt dealer as soon as possible.

Keep safely, away from your vehicle,
the label attached to the keys given to
you on acquisition of the vehicle.

Access

508_en_Chap02_ouvertures_ed01-2016

Locking - unlocking using
the integral key

Locking-unlocking the
driver's door

Insert the key in the door lock to lock or unlock
the door.

Locking-unlocking the
passenger doors

Back-up procedure - electronic keys

the integral key is used to lock and unlock the
vehicle when the electronic key cannot operate:
-

cell battery flat, vehicle battery discharged
or disconnected, ...

vehicle located in an area with strong
electromagnetic emissions.

F Pull on button 1, to extract the integral

key 2.

F unlock or lock the vehicle using the key.

Locking

F On the rear doors, check that the child lock

is not on.

F Remove the black cap located on the edge

of the door, using the integral key.

F Insert the integral key into the aperture

without forcing, then without turning, move
the latch sideways towards the inside of
the door.

F Remove the integral key and refit the cap.

Unlocking

Pull the interior door handles

If your vehicle has an alarm, it will not
be activated and deactivated on locking
and unlocking the vehicle.
Opening a door will trigger the alarm; it
will stop when the ignition is switched
on.

Peugeot 508 (2016 year). Instruction - part 4
