SUMMARY TABLE FOR THE
LOCATION OF ISOFIX CHILD
SEATS

IUF:

seat approved for a U niversal

soﬁ x child seat, " F orward

facing" with the "Top Tether"

upper strap.

IL-SU:

seat approved for a S emi-

U niversal I

soﬁ x child seat,

"forward facing" with a sup-

port, "rear facing" or infant car

seat with a support or a "Top

Tether" upper strap.

X: seat not suitable for the installation

of an ISOFIX child seat of the size

category indicated.

In accordance with the European regu-

lation ECE 16 , this table indicates the

options for the installation of ISOFIX

child seats on the vehicle seats ﬁ tted

with ISOFIX mountings.

In the case of the universal and semi-

universal ISOFIX child seats, the child

seat's ISOFIX size category, deter-

mined by a letter A, B, B1, C, D, E, F,

G , is indicated on the child seat next to

the ISOFIX logo.

Weight of the child

/indicative age

Less than 10 kg

(group 0)

Up to 6 months approx

Less than 10 kg

(group 0)

Less than 13 kg

(group 0+)

Up to 1 year approx

From 9 to 18 kg (group 1)

1 to 3 years approx

Type of ISOFIX child seat

Infant car seat

"rear facing"

"forward facing"

ISOFIX size category

Universal and semi-universal
ISOFIX child seats which can

be installed on the rear seats

IL-SU

IUF

IL-SU

ADVICE ON CHILD
SEATS

Children under the age of 10 must not

travel in the "forward facing" position

on the front passenger seat, unless

the rear seats are already occupied by

other children, cannot be used or are

absent.

Disarm the passenger air bag * when a

"rear facing" child seat is installed on

the front seat.
Otherwise, the child would risk being

seriously injured or killed if the air bag

were to inﬂ ate.

As a safety precaution, do not leave:

- one or more children alone and un-

supervised in a vehicle,

- a child or an animal in a vehicle

which is exposed to the sun, with

the windows closed,

- the keys within reach of children

inside the vehicle.

To protect young children from the

rays of the sun, ﬁ t side blinds on the

rear windows.

* According to country.

The incorrect installation of a child seat

in a vehicle compromises the child's

protection in the event of an accident.

Remember to fasten the seat belts or

the child seat harness keeping the
slack

in relation to the child's body to

a minimum

, even for short journeys.

For optimum installation of the

"forward facing" child seat, ensure that

the back of the child seat is in contact
with the back of the vehicle's seat and
that the head restraint does not cause

any discomfort.
If the head restraint has to be
removed, ensure that it is stored or

attached securely to prevent it from

being thrown around the vehicle in the

event of sharp braking.

Installing a booster seat
The chest part of the seat belt must

be positioned on the child's shoulder

without touching the neck.

Ensure that the lap part of the seat

belt passes correctly over the child's

thighs.
PEUGEOT recommends the use of

a booster seat which has a back, ﬁ t-

ted with a seat belt guide at shoulder

level.

REMOTE CONTROL KEY

The  remote  control  in  the  key  locks,
deadlocks and unlocks the doors and
boot  at  a  distance  and  folds  and  un-
folds the exterior mirrors.
The  key  permits  mechanical  and  in-
dependent operation of the glove box
lock, of the passenger air bag disarm-
ing control and of the boot access from
the  rear  seat  locks  as  well  as  switch-
ing on of the ignition.
From the driver's door, the key permits
electrical  control  of  the  locking  or  un-
locking of the doors and boot.
If one of the doors or the boot is open,
the central locking does not function.

Unfolding/Folding the key

To unfold or fold the key, press button
A

ﬁ rst.

Deadlocking

This renders the external and internal
door controls inoperative.
It also deactivates the internal central
locking button.

Normal locking

This renders the external door controls
inoperative.
It also deactivates the internal central
locking button.
 Press button B for complete locking

of the vehicle.

 Press button B for more than

2 seconds for automatic closing of
the windows and tilting of the sunroof,
if it is open, in addition to locking.

Each action is conﬁ rmed by ﬁ xed light-

ing of the direction indicators for ap-
proximately two seconds.
The exterior mirrors fold at the same
time.

Using the key
 Turn the key in the door lock to

lock the vehicle.



Within ﬁ ve seconds, turn the key

again to deadlock the vehicle.

Each action is conﬁ rmed by ﬁ xed light-

ing of the the direction indicators for
approximately two seconds.

When the windows are closed
automatically using the remote
control,  ensure  that  no  one  is
preventing  them  from  closing
correctly.

Using the remote control
 Pressing button B permits com-

plete  locking  of  the  vehicle  or
pressing  button  B for more than
2 seconds  permits automatic clos-
ing of the windows and tilting of the
sunroof, if it is open, in addition to
locking.



Within ﬁ ve seconds, a second

press permits deadlocking of the
vehicle.

Each action is conﬁ rmed by ﬁ xed light-

ing of the direction indicators for ap-
proximately two seconds.

  When the windows are closed
automatically using the remote
control,  ensure  that  no  one  is
preventing  them  from  closing
correctly.

The folding and unfolding of the ex-
terior mirrors can be deactivated by a
PEUGEOT dealer.

The complete or selective

unlocking can be conﬁ gu-

red by means of a para-
meter, via the multifunction
display "Personalisation-

Conﬁ guration" menu.

boot

 Press button D to unlock and open

the boot.

This action also unlocks the doors.
If the permanent locking of the boot is
activated, opening is only possible via
button D on the remote control.

When the vehicle is locked,
if unlocking is activated inad-
vertently, without a door being
opened within 30 seconds, the
vehicle will lock automatically.

This function can be conﬁ gu-

red by means of a parame-
ter, via the multifunction
display "Personalisation-

Conﬁ guration" menu.

Key in ignition

A buzzer sounds on opening the driver's
door, if the key has been left in the ignition.

LOCATING YOUR VEHICLE

To locate your vehicle, if you have
locked or deadlocked it, in a car park:
 press button B on the remote con-

trol, the courtesy lights come on

and the direction indicators ﬂ ash

for a few seconds.

Unlocking

Selective (if activated)
 Press button C to unlock the driver's

door only.



Press the button again to unlock

the passenger door and the boot.

Each action is conﬁ rmed by rapid

ﬂ ashing of the direction indicators for

approximately two seconds.
The exterior mirrors unfold at the same
time.

Complete
 Press button C for complete un-

locking of the vehicle.

This is conﬁ rmed by rapid ﬂ ashing of

the direction indicators for approxi-
mately two seconds.
The exterior mirrors unfold at the same
time.

CHANGING THE REMOTE
CONTROL BATTERY

Battery ref.: CR1620/3 volts.
To change the battery, unclip the casing
using a coin at the notch.

REPROGRAMMING THE
REMOTE CONTROL

      Switch off the ignition.
     Switch the ignition on again.
     Press  the  remote  control  locking

button immediately for a few seconds.

 Switch off the ignition and remove

the remote control key from the
ignition lock. The remote control is
now working again.

ELECTRONIC ENGINE
IMMOBILISER

This  locks  the  engine  control  system
a  few  moments  after  the  ignition  has
been  switched  off  and  therefore  pre-
vents starting of the vehicle by anyone
who does not have the key.
The  ignition  key  has  an  electronic  chip
which has a special code. When the igni-
tion is switched on, the code is recognised
and starting is possible.

Do not discard the batteries,
they contain metals which are
harmful to the environment.
Take them to an approved col-
lection point.

If the system does not func-

tion  correctly,   the  warning
light comes on on the instru-
ment  panel  display,  accom-
panied  by  an  audible  signal
and a message on the multi-
function display.

In this case, your vehicle will not start.
Contact a PEUGEOT dealer as soon
as possible.

If the remote control does not work
after the battery has been changed,
re-programme the remote control.

Make a careful note of the

number on each key. The

key number is coded on the

label attached to the key.

If the keys are lost, a PEUGEOT

dealer can rapidly supply you with

new keys.

The high frequency remote control is

a sensitive system; do not operate it

while it is in your pocket as there is

a possibility that it may unlock your

vehicle, without you being aware of it.
The remote control does not oper-

ate when the key is in the ignition,

even when the ignition is switched

off, except for reprogramming.

Do not operate the deadlocking

function if there is anyone inside

the vehicle.

Driving with the doors locked may

make access to the passenger com-
partment by the emergency services

more difﬁ cult in an emergency.

As a safety precaution (with chil-

dren on board), remove the ignition

key when you leave the vehicle,

even for a short time.

Do not repeatedly press the button

of your remote control out of range

and out of sight of your vehicle.

You run the risk of stopping it from

working and the remote control

would have to be reprogrammed.

When purchasing a second-hand

vehicle, have the key codes memo-
rised by a PEUGEOT dealer to

ensure that the keys in your pos-

session are the only ones which

can start the vehicle.

Do not make any modiﬁ cations to

the electronic engine immobiliser

system.

  When the windows are closed
automatically using the remote
control,  ensure  that  no  one  is
preventing  them  from  closing
correctly.

The folding and unfolding of the ex-
terior mirrors can be deactivated by a
PEUGEOT dealer.

The complete or selective

unlocking can be conﬁ gu-

red by means of a para-
meter, via the multifunction
display "Personalisation-

Conﬁ guration" menu.

boot

 Press button D to unlock and open

the boot.

This action also unlocks the doors.
If the permanent locking of the boot is
activated, opening is only possible via
button D on the remote control.

When the vehicle is locked,
if unlocking is activated inad-
vertently, without a door being
opened within 30 seconds, the
vehicle will lock automatically.

This function can be conﬁ gu-

red by means of a parame-
ter, via the multifunction
display "Personalisation-

Conﬁ guration" menu.

Key in ignition

A buzzer sounds on opening the driver's
door, if the key has been left in the ignition.

LOCATING YOUR VEHICLE

To locate your vehicle, if you have
locked or deadlocked it, in a car park:
 press button B on the remote con-

trol, the courtesy lights come on

and the direction indicators ﬂ ash

for a few seconds.

Unlocking

Selective (if activated)
 Press button C to unlock the driver's

door only.



Press the button again to unlock

the passenger door and the boot.

Each action is conﬁ rmed by rapid

ﬂ ashing of the direction indicators for

approximately two seconds.
The exterior mirrors unfold at the same
time.

Complete
 Press button C for complete un-

locking of the vehicle.

This is conﬁ rmed by rapid ﬂ ashing of

the direction indicators for approxi-
mately two seconds.
The exterior mirrors unfold at the same
time.

CHANGING THE REMOTE
CONTROL BATTERY

Battery ref.: CR1620/3 volts.
To change the battery, unclip the casing
using a coin at the notch.

REPROGRAMMING THE
REMOTE CONTROL

      Switch off the ignition.
     Switch the ignition on again.
     Press  the  remote  control  locking

button immediately for a few seconds.

 Switch off the ignition and remove

the remote control key from the
ignition lock. The remote control is
now working again.

ELECTRONIC ENGINE
IMMOBILISER

Do not discard the batteries,
they contain metals which are
harmful to the environment.
Take them to an approved col-
lection point.

If the system does not func-

tion  correctly,   the  warning
light comes on on the instru-
ment  panel  display,  accom-
panied  by  an  audible  signal
and a message on the multi-
function display.

In this case, your vehicle will not start.
Contact a PEUGEOT dealer as soon
as possible.

If the remote control does not work
after the battery has been changed,
re-programme the remote control.

CHANGING THE REMOTE
CONTROL BATTERY

Battery ref.: CR1620/3 volts.
To change the battery, unclip the casing
using a coin at the notch.

REPROGRAMMING THE
REMOTE CONTROL

      Switch off the ignition.
     Switch the ignition on again.
     Press  the  remote  control  locking

button immediately for a few seconds.

 Switch off the ignition and remove

the remote control key from the
ignition lock. The remote control is
now working again.

ELECTRONIC ENGINE
IMMOBILISER

Do not discard the batteries,
they contain metals which are
harmful to the environment.
Take them to an approved col-
lection point.

If the system does not func-

tion  correctly,   the  warning
light comes on on the instru-
ment  panel  display,  accom-
panied  by  an  audible  signal
and a message on the multi-
function display.

In this case, your vehicle will not start.
Contact a PEUGEOT dealer as soon
as possible.

If the remote control does not work
after the battery has been changed,
re-programme the remote control.

Make a careful note of the

number on each key. The

key number is coded on the

label attached to the key.

If the keys are lost, a PEUGEOT

dealer can rapidly supply you with

new keys.

The high frequency remote control is

a sensitive system; do not operate it

while it is in your pocket as there is

a possibility that it may unlock your

vehicle, without you being aware of it.
The remote control does not oper-

ate when the key is in the ignition,

even when the ignition is switched

off, except for reprogramming.

Do not operate the deadlocking

function if there is anyone inside

the vehicle.

Driving with the doors locked may

make access to the passenger com-
partment by the emergency services

more difﬁ cult in an emergency.

As a safety precaution (with chil-

dren on board), remove the ignition

key when you leave the vehicle,

even for a short time.

Do not repeatedly press the button

of your remote control out of range

and out of sight of your vehicle.

You run the risk of stopping it from

working and the remote control

would have to be reprogrammed.

When purchasing a second-hand

vehicle, have the key codes memo-
rised by a PEUGEOT dealer to

ensure that the keys in your pos-

session are the only ones which

can start the vehicle.

Do not make any modiﬁ cations to

the electronic engine immobiliser

system.

THE ALARM

This provides two types of surveil-
lance:
-

exterior protection: it sounds if
a door, the boot or the bonnet is
opened.

interior protection: it sounds if the
volume inside the passenger compart-
ment changes (breaking of a window
or a movement inside the vehicle).

When the alarm is triggered, the si-
ren sounds and the direction indica-

tor lights ﬂ ash for approximately thirty

seconds.
After triggering, the alarm remains set,
ten times in succession.
On  the  eleventh  time  it  will  become
inactive  again,  until  the  next  cycle  of
disarming then setting of the alarm.
  Warning:   if  button   A   indicator  light

ﬂ ashes rapidly, the alarm has been

triggered while you were away from
your vehicle.

Incorrect operation

When  the  ignition  is  switched  on,  if
button   A   lights  for  ten  seconds,  there
is a fault in the siren connection.
Contact  a   PEUGEOT   dealer  to  have
the system checked.

Remote control failure,

alarm set

 Unlock the doors with the key and

open the door. The alarm is trig-
gered.

 Switch on the ignition. The alarm is

disarmed.

* According to country.

Setting the alarm

 Switch off the ignition and get out

of the vehicle.

 Set the alarm, by locking or dead-

locking using the remote control
(button A

indicator light ﬂ ashes

once per second).

If you wish to lock or deadlock your
vehicle without setting the alarm, lock
it (one turn of the key) or deadlock it

(a second turn within ﬁ ve seconds

maximum) using the lock.

The  alarm  is  activated  automatically
two minutes after the last closure of a
door or the boot.
In order to avoid accidental triggering
of  the  alarm  when  a  door  or  the  boot
is  opened,  it  is  essential  to  press  the
unlocking button on the remote control
again.

Before  setting  the  alarm,  en-
sure  that  all  of  the  accesses
(doors,  bonnet,  boot)  are
closed correctly.

Disarming

Unlock  the  vehicle  with  the  remote
control key.
The  alarm  is  disarmed,  indicator  light   A
goes out when the ignition is switched on.

To set the alarm with exterior

protection only

If,  while  you  are  away  from  the  vehi-
cle,  you  wish  to  leave  a  window  par-
tially open or a pet inside the vehicle,
you should choose exterior protection
only.
      Switch off the ignition,
     In the next ten seconds, press but-

ton A until the indicator light is on
continuously,

 Get out of the vehicle,
 Set the alarm by locking or dead-

locking using the remote control
(button A

indicator light ﬂ ashes

once a second).

ELECTRIC WINDOWS

1. Driver's electric window switch.

2. Passenger's electric window

switch.

  Automatic operation:
To open or close the window, press or
pull the switch fully: the window opens
or closes completely when the switch
is released. Pressing the switch again
stops the movement of the window.
The  electric  window  switches  remain
operational for approximately one min-
ute  after  the  key  has  been  removed
from the ignition.
Once this time has elapsed, the electric
windows  will  not  operate.  To  reactivate
them, switch the ignition on again.

  Safety auto-reverse
When the window rises and meets an
obstacle, it stops and immediately par-
tially lowers again.
In  the  event  of  unwanted  opening
of  the  window  on  closing,  press  the
switch  until  the  window  opens  com-
pletely, then pull the switch immediate-
ly until the window closes. Continue to
hold the switch for approximately one
second after the window has closed.
The safety auto-reverse function is not
active during this operation.

REINITIALISATION OF THE
WINDOWS

Following  reconnection  of  the  bat-
tery,  the  safety  auto-reverse  function
must  be  reinitialised:  the  safety  auto-
reverse  function  is  not  active  during
these operations.
   -

with the door closed, lower the win-
dow completely, then raise it, it will
rise in steps of a few centimetres
each time the switch is pressed.
Repeat the operation until the win-
dow closes completely,

continue to press the switch for at
least one second after reaching
this position, window closed.

Always  remove  the  key  from
the  ignition  when  leaving  the
vehicle, even for a short time.
In  the  event  of  contact  during

operation  of  the  windows,  you  must
reverse  the  movement  of  the  window.
To do this, press the switch concerned.
When the driver operates the passen-
ger  electric  window  switch,  he  must
ensure  that  no  one  is  preventing  cor-
rect closing of the window.
The  driver  must  ensure  that  the  pas-
sengers use the electric windows cor-
rectly.
Be  aware  of  children  when  operating
the windows.

  Manual operation:
To  open  or  close  the  window,  press  or
pull the switch gently. The window stops
as soon as the switch is released.

DOORS

Opening the doors from

outside

Opening the doors from inside

Locking/unlocking from the

inside

 Press the button.
This allows the doors and the boot to
be locked or unlocked.

To make it easier to open the door, the
window lowers automatically by a few
centimetres.
It rises and adjusts automatically on
closing to guarantee perfect sealing.

Before  carrying  out  any  work
which  requires  disconnection
of  the  battery,  lower  the  win-
dows  to  permit  opening  and
closing of the doors.

In the event of a battery cut-off or if the
automatic  lowering  fails  (window  iced
up  for  example),  it  is  still  possible  to
open the doors. However, it is impera-
tive  that  the  doors  are  not  slammed
when closed.
The  safety  auto-reverse  is  inopera-
tive during the automatic raising of the
windows.
Contact  a   PEUGEOT   dealer  as  soon
as possible.
When  using  a  high  pressure  washer
on  your  vehicle,  it  is  recommended
that the end of the gun is kept at least
50  cm  away  from  the  windows  and
door seals.

If the vehicle has been locked
or deadlocked using the key
or the remote control, the but-
ton is inoperative.

In this case, use the key or the remote
control to unlock.

  Unlocking from the doors
You  can  unlock  from  the  inside  by
operating a door opening control.
If the "Access to the vehicle" function
is  activated  via  the  multifunction  dis-
play menu, opening:
   -

the driver's door, unlocks the door
concerned.

the passenger door, unlocks the
doors and the boot.

MANUAL LOCKING
(EMERGENCY MODE)

Automatic central locking of the

doors
The doors and boot can lock automati-
cally while driving (speed above 6 mph
[10 km/h]).
You can activate or deactivate this
function by pressing and holding the
button.

BOOT

To open the boot, press the push but-
ton and raise the tailgate.

Tailgate release

This enables the tailgate to be un-
locked in the event of a central locking
fault.
-

Fold back the rear seats to gain
access to the lock from inside the
boot,

Insert a small screwdriver into hole
A of the lock to unlock the tailgate.

  Note:   driving  with  the  doors
locked  may  make  access  to
the passenger compartment by
the  emergency  services  more

difﬁ cult in an emergency.

If the permanent locking of the
boot is activated, opening is
only possible by pressing the
remote control button.

  Passenger door
To  lock,  insert  the  key  in  the  control
located  on  the  edge  of  the  door  then
push to the left.

Driver's door
Insert the key in the lock to lock or un-
lock the door.

MANUAL LOCKING
(EMERGENCY MODE)

Automatic central locking of the

doors
The doors and boot can lock automati-
cally while driving (speed above 6 mph
[10 km/h]).
You can activate or deactivate this
function by pressing and holding the
button.

BOOT

To open the boot, press the push but-
ton and raise the tailgate.

Tailgate release

This enables the tailgate to be un-
locked in the event of a central locking
fault.
-

Fold back the rear seats to gain
access to the lock from inside the
boot,

Insert a small screwdriver into hole
A of the lock to unlock the tailgate.

  Note:   driving  with  the  doors
locked  may  make  access  to
the passenger compartment by
the  emergency  services  more

difﬁ cult in an emergency.

If the permanent locking of the
boot is activated, opening is
only possible by pressing the
remote control button.

  Passenger door
To  lock,  insert  the  key  in  the  control
located  on  the  edge  of  the  door  then
push to the left.

Driver's door
Insert the key in the lock to lock or un-
lock the door.

SUNROOF

  To tilt the roof:  press and hold part  A
of the switch.
  To open the roof in sliding mode:  tilt
the  sunroof,  then  press  part   A   of  the

switch brieﬂ y.
To close it in sliding mode: press
part B

of the switch brieﬂ y.

To close it in tilt mode: press and
hold part B of the switch.

Safety auto-reverse
When the sunroof is sliding closed and
meets an obstacle, it stops then par-
tially opens again.

Pressing  the  locking  button
on  the  remote  control  key  for
more  than  2  seconds  closes
the  sunroof  in  sliding  mode.

The sunroof remains tilted.
To close the sunroof completely, press
and hold part B of the switch before
getting out of the vehicle.

Always remove the key from
the ignition when leaving the
vehicle, even for a short time.
Always ensure that the sunroof

is  closed  correctly  before  leaving  the
vehicle.
In the event of contact during closing in
tilt mode, you must reverse the move-
ment of the roof. To do this, press the
switch concerned.
When  the  driver  closes  the  roof  in  tilt
mode,  he  must  ensure  that  no  one  is
preventing correct closing of the roof.
The  driver  must  ensure  that  the  pas-
sengers use the sunroof correctly.
Be  aware  of  children  when  operating
the roof.

  Notes:
In  the  event  of  unwanted  opening  of
the roof on closing (for example, in the
presence of ice), press and hold part  B
of the switch,

within the two seconds

which follow the triggering of the safety
auto-reverse,  until  the  sunroof  closes
completely.
Following  reconnection  of  the  bat-
tery  or  in  the  event  of  a  malfunction,
press  and  hold  part   B   of  the  switch,
the  sunroof  slides  "step  by  step"  until
it closes. Continue to press the switch
for   approximately  one  second   after
closing.

The safety auto-reverse function is

not active during these operations.

  Shutter
The sunroof shutter is manual.
To open it, slide it rearwards using the
handle.
To close it, slide it forwards using  the
handle.

Do not open the sunroof immedia-

tely after a shower or immediately

after washing the car.

Peugeot 407 C Dag (2008 year). Instruction - part 5
