Peugeot 108 (2016 year). Instruction

Audio and Telematics

191

108_en_Chap10a_Autoradio-toyota-tactile-1_ed01-2016

Level 1

Level 2

Level 3

Comment

Audio source

FM radio
configuration

update the list of stations

update the list to take account of reception.

List of stations

Choose to list by "Broadcaster" or "Alphabetic".

FM traffic announcements

Activate or deactivate options.

FM alternative frequencies

Change regional code

FM radiotext

Presets

List of preset stations.

Stations

List of radio stations received.

Manual

Search for stations step by step or
automatically.

Audio source

Presets

List of preset stations.

Manual

Search for stations step by step or
automatically.

Audio source

DAB

DAB radio
configuration

update the list of stations

update the list to take account of reception.

L-Band

Activate or deactivate options.

DAB traffic announcements

DAB alternative frequencies

DAB radiotext

Presets

List of preset stations.

Stations

List of radio stations received.

Manual

Search for stations step by step or
automatically.

Audio and Telematics

193

108_en_Chap10a_Autoradio-toyota-tactile-1_ed01-2016

Level 1

Level 2

Level 3

Comment

Audio source

uSB

Scan

Choose the play setting.

Random play

Repeat play

Previous track

Play

Next track

Audio source

Bluetooth audio

telephone

First connection, refer to the telephone section.

Audio play

System configuration

Activate or deactivate options.

Random play

Choose the play setting.

Repeat play

Previous track

Play

Next track

Audio source

A / V

Screen format

Normal

Choose the most suitable screen format.

Stretched

Zoom

Full screen

Display in full screen mode.

Audio and Telematics

194

108_en_Chap10a_Autoradio-toyota-tactile-1_ed01-2016

Radio

* Depending on equipment.

Selecting a station

Press on "Audio source" to display
the carousel of sound sources.

Select "FM".

Select the "Station" tab then select
a radio station from the stations
received.

Select the "Manual" tab to search for
a station.

Select "FM radio configuration"
then "update the list of stations" to
refresh the list.

If necessary, select change of source
by pressing on the "Audio source"
shortcut in the upper bar of the
carousel.

Select "AM" or "DAB"*.

Press on "Audio source" to display
the carousel of sound sources.

Select "FM".

Press the step by step buttons to
search for frequencies up or down.

Press the automatic buttons to
search for frequencies up or down.

turn the button at bottom right of the
screen to search for frequencies up
or down.

the exterior environment (hills, buildings,
tunnel, car park, below ground...)
may prevent reception, even in RDS
alternative frequencies mode. this
phenomenon is normal in the propagation
of radio waves and is in no way indicative
of a fault with the audio system.

Changing a radio frequency

Audio and Telematics

195

108_en_Chap10a_Autoradio-toyota-tactile-1_ed01-2016

Select a radio station or frequency
(refer to the "Changing a frequency"
section).

Press on "Audio source" to display
the carousel of audio sources.

Select "FM".

Select "FM radio configuration".

Activate/deactivate "Change of
regional code".

Select the "Presets" tab then make
a long press on one of the numbered
preset locations.

Preset a station

Activate/ Deactivate RDS

RDS, if activated, allows you to continue
listening to the same station by automatic
retuning to alternative frequencies.
However, in certain conditions, coverage
of an RDS station may not be assured
throughout the entire country as radio
stations do not cover 100 % of the
territory. this explains the loss of
reception of the station during a journey.

Audio and Telematics

196

108_en_Chap10a_Autoradio-toyota-tactile-1_ed01-2016

DAB (Digital Audio Broadcasting) radio

Display "DAB" waveband.

Display the name and "Radiotext" for
the current station.

Short-cut: access to the choice of
audio source, telephone functions and
SmartphoneLink

mode.

Select the radio station.

Preset stations.
Short press: select the preset
radio station.
Long press: preset a radio
station.

"Next multiplex".

Next radio station.

Display the name and number of the
"Multiplex" service being used.

"Previous multiplex".

"DAB radio configuration".

Previous radio station.

If the "DAB" radio station being listened
to is not available, the "FM" waveband
appears in the screen.

Audio and Telematics

197

108_en_Chap10a_Autoradio-toyota-tactile-1_ed01-2016

Press on "Audio source" to display
the carousel of sound sources.

Press "Audio source" to display the
carousel of audio sources.

Select "DAB".

Select "DAB radio configuration".

Activate "L-band".

Select "DAB radio configuration".

Activate "Alternative DAB
frequency".

Select the "Station" tab then select a
station from those received.

Select the "Manual" tab to search for
a station.

Digital radio provides higher quality
reception and also the display of
additional information (album artwork...)
on the radio station being listened to.
Select "DAB" in the carousel of audio
sources.
the range of multiplexes available is
displayed in alphabetical order.

Digital radio does not cover 100% of the
territory.
When the digital signal is weak, the
"Alternative DAB frequency" option
makes it possible to continue listening
to the same station, by automatically
switching to the corresponding "FM"
station (if there is one).

If the "DAB" station being listened to
is not available, or if "L-band" is not
activated, the sound will cut out while
the digital signal is too weak.

If "Alternative DAB frequency"
tracking is activated, there is a
difference of a few seconds when the
system switches to the "FM" analogue
radio station with sometimes a variation
in volume.
When the digital signal is restored, the
system automatically changes back
to "DAB".

DAB / FM station tracking

Digital radio

Audio and Telematics

198

108_en_Chap10a_Autoradio-toyota-tactile-1_ed01-2016

Media

uSB player

Insert a uSB memory stick into the uSB port
or connect a uSB peripheral device to the uSB
port using a suitable cable (not supplied).

the system builds playlists (in temporary
memory), an operation which can take
from a few seconds to several minutes at
the first connection.
Reduce the number of non-music files
and the number of folders to reduce the
waiting time.
the playlists are updated every time the
ignition is switched off or connection
of a uSB memory stick. However, the
audio system memorises these lists and
if they are not modified, the loading time
will be shorter.

Auxiliary (A/V) input

Connect a portable device (MP3 player…) to
the auxiliary JACK socket using an audio cable.

Audio and Telematics

199

108_en_Chap10a_Autoradio-toyota-tactile-1_ed01-2016

Press on "Audio source" to display
the carousel of audio sources.

Select the "uSB" auxiliary source.

Select the "A/V" auxiliary source.

use the play settings at the bottom of the
screen.

Selection of source

Pressing the "MoDe" button at the
steering mounted controls changes to
the next media, available if the source
is active.

Audio and Telematics

200

108_en_Chap10a_Autoradio-toyota-tactile-1_ed01-2016

Information and advice

the system accepts uSB mass storage
devices or Apple

players via the

uSB ports. the adaptor cable is not
supplied.
Control of the peripheral device is with
the audio system controls.
Other peripherals, not recognised on
connection, must be connected to the
auxiliary socket using a Jack cable (not
supplied).

It is advisable to restrict file names to
20 characters, without using of special
characters (e.g.: " " ? ; ù) to avoid any playing
and displaying problems.

use only uSB memory sticks formatted FAt 32
(File Allocation table).

the audio system plays files with the extension:
".wma", type Ver7 and Ver8 with bit rate
between 48 and 192 Kbps and type Ver9 with
bit rate between 48 and 320 Kbps.
".aac", with bit rate between 16 and 320 Kbps.
".mp3 - MPeg1" with bit rate between 32 and
320 Kbps and ".mp3 - MPeg2" with bit rate
between 8 and 160 Kbps.
the sampling rates supported are 11, 22, 44
and 48 KHz.

the system can alternatively read files
via the Bluetooth

system and the uSB

port.

It is recommended that the uSB cable
for the portable device is used.

Audio and Telematics

201

108_en_Chap10a_Autoradio-toyota-tactile-1_ed01-2016

Audio streaming

Once connected for streaming, the
telephone is considered as a media
source.
It is recommended that "Repeat" mode
be activated in the Bluetooth device.

Streaming allows audio files on your
telephone to be played via the vehicle's
speakers.

Connect the telephone: see the "telephone"
section, then "Bluetooth".
Choose either "Connect all" or "Connect as
audio player" profile.

If play does not start automatically, it may
be necessary to start audio play from the
telephone.
Control is from the peripheral device or by
using the audio system controls.

Connecting Apple

players

Connect the Apple

player to the uSB port

using a suitable cable (not supplied).
Play starts automatically.

Control is via the audio system.

the version of software in the audio
system may not be compatible with the
generation of your Apple

player.

the classifications available are those
of the portable device connected
(artists / albums / genres / tracks /
playlists / audio books / podcasts).
the default classification used is by
artist. to modify the classification used,
return to the first level of the menu
then select the desired classification
(playlists for example) and confirm to go
down through the menu to the desired
track.

Audio and Telematics

203

108_en_Chap10a_Autoradio-toyota-tactile-1_ed01-2016

Level 1

Level 2

Level 3

Comment

Contacts

After making choices, start the call.

Favourites

Call history

enter a number

Call

enter a number then start the call.

telephone/

message

configuration

Connect the
telephone

telephone

Select the services to use on the
peripheral device.

Audio player

Sounds
configuration

Ringtone

Choose settings, activate or
deactivate options.

Ringtone volume

Incoming SMS/MMS tone

Incoming SMS/MMS volume

Incoming e-mail tone

Incoming e-mail volume

Incoming call volume

Contacts/
call history
configuration

Automatic transfer

update telephone contacts

Sort contacts by

Add favourite

Remove favourite

Message
configuration

Display of incoming calls

Contacts/call history transfer state

telephone
display
configuration

Display of incoming calls

Contacts/call history transfer state

Audio and Telematics

204

108_en_Chap10a_Autoradio-toyota-tactile-1_ed01-2016

Press on "Audio source" to display
the carousel of audio sources.

Select "Bluetooth audio".

Select "Bluetooth configuration"

Activate the telephone's Bluetooth function
and ensure that it is "visible to all" (telephone
configuration).

Select the telephone in the list.

Select "Connect telephone".

Select the "telephone/message
configuration" tab.

Select your choice.

Select the "Add" tab in the system.

Press "oK" to confirm.

If the telephone is not detected, it is
recommended that you switch the Bluetooth
function on your telephone off and then on again.

As a safety measure and because they
require prolonged attention on the part
of the driver, the operations for pairing
the Bluetooth mobile telephone to the
hands-free system of the audio system
must be carried out with the vehicle
stationary.

Pairing a Bluetooth

telephone

A waiting screen is displayed with the Bluetooth
settings of the system and a default Bluetooth
PIN.

Once detected, select the name of the system
in your telephone.

the system displays that the services to be
used on the telephone are: "telephone" and
"Audio player".

the system offers to connect the telephone:
-

with "Connect all",

with "Connect as telephone" (hands-free
kit, telephone only),

with "Connect as audio player"
(streaming: wireless play of audio files on
the telephone).

enter the PIN code in the telephone then accept
the connection (depending on the telephone).

to change the connection choice,
Select "telephone".

Audio and Telematics

205

108_en_Chap10a_Autoradio-toyota-tactile-1_ed01-2016

the services available depend on
the network, the SIM card and the
compatibility of the Bluetooth telephone
used. Check the telephone manual and
with your network provider for details of
the services available to you.

the profiles compatible with the system
are: HFP, OPP, PBAP, A2DP, AVRCP,
MAP.

this function allows the connection or
disconnection of a peripheral device as
well as the deletion of a pairing.

Automatic reconnection

When the ignition is switched on, the last
telephone connected when the ignition was
switched off reconnects automatically, if this
connection made had been activated during the
pairing procedure (see previous pages).

Connection is confirmed by the display of a
message and the name of the telephone.

Managing paired
telephones

Press "telephone".

Select "telephone/message
configuration".

Select "Connect telephone" to
display the list of paired devices.

Select "Remove" then select the device in the
list and confirm.

Audio and Telematics

206

108_en_Chap10a_Autoradio-toyota-tactile-1_ed01-2016

Make a short press on this steering
mounted button to accept an
incoming call.

Press on this steering mounted
button to reject a call or to end a call.

Press "telephone".

Press the keypad tab.

enter the phone number using the
keypad then press the telephone
button to start the call.

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Making a call

use of the telephone is not
recommended while driving. We
recommended that you park safely
or make use of the steering mounted
controls.

Calling a new number

Press on "telephone".

Press this steering mounted button to
open the list of contacts.

Select the "Contacts" tab.

Select the desired contact
from the list offered to start
the call.

Calling a contact

Peugeot 108 (2016 year). Instruction - part 13
