Opel Mokka X (2019 year). Manual - part 8

118

Lighting

Pull lever to deactivate high beam.
High beam assist 3 120.

High beam assist

This feature automatically activates

the high beam at night when vehicle

speed is faster than40 km/h.
It switches automatically back to low

beam when:

● The camera or a sensor in the

windscreen detects the lights of

oncoming or preceding vehicles.

● The vehicle speed drops below

20 km/h.

● It is foggy or snowy.
● Driving in urban areas.

If there are no restrictions detected,

the system switches back to high

beam.

Activation

The high beam assist is activated by

pushing the indicator lever twice. The

high beam is switched on

automatically at a speed above

40 km/h.
The green control indicator f

illuminates continuously when the

assist is activated, the blue one 7

illuminates when high beam is on.
Control indicator f 3 96.

Deactivation

Push indicator lever once. It is also

deactivated when front fog lights are

switched on.

If a headlight flash is activated when

the high beam is on, the high beam

assist will be deactivated.
If a headlight flash is activated when

the high beam is off, the high beam

assist will remain activated.
The latest setting of the high beam

assist will remain after the ignition is

switched on again.

Headlight flash

Pull lever to activate the headlight

flash.
Pulling lever deactivates high beam.
AFL-LED headlights 3 120.

Lighting

119

Headlight range adjustment

Manual headlight range

adjustment

To adapt headlight range to the

vehicle load to prevent dazzling: turn

thumb wheel ? to required position.
0 : front seats occupied

1 : all seats occupied

2 : all seats occupied and load

compartment laden

3 : driver's seat occupied and load

compartment laden

Dynamic automatic headlight

levelling 3 120.

Headlights when driving

abroad

The asymmetrical headlight beam

extends visibility at the edge of the

road at the passenger side.
However, when driving in countries

where traffic drives on the opposite

side of the road, adjust the headlights

to prevent dazzling of oncoming

traffic.

Vehicles with halogen headlight

system

The adjusting screws are located

above the headlight.

Turn the adjusting screws with the

screwdriver clockwise by half a turn.
To reset to left-hand traffic mode, turn

adjuster elements on both headlight

housings anticlockwise by half a turn.

Caution

Have the adjustment of the

headlights checked after

deactivation.
We recommend consulting a

workshop.

120

Lighting

Vehicles with adaptive forward

lighting system

1. Key in ignition switch.
2. Pull turn signal lever and hold

(headlight flash).

3. Switch on ignition.
4. After approx. five seconds the

control indicator f starts flashing

and an acoustic signal sounds.

On another version the headlights are

adjusted for driving on the opposite

side of the road via the vehicle

personalisation menu. Select the

relevant setting in Settings, I Vehicle.
Vehicle personalisation 3 106.

Every time the ignition is switched on,

control indicator f flashes as a

reminder for approx. four seconds.
For deactivation, operate the same

procedure as described above.

Control indicator f will not flash when

function is deactivated.
Control indicator f 3 96.

Daytime running lights

Daytime running lights increase

visibility of the vehicle during daylight.
They are switched on automatically

during daytime when engine is

running.
The system switches between

daytime running lights and headlights

automatically, depending on the

lighting conditions.
Automatic light control 3 117.

Adaptive forward lighting

The Adaptive forward lighting

functions are only available with LED

headlights for low and high beam.

Light range, light distribution and

intensity of light are variably triggered

depending on the lighting conditions,

road type and driving situation.

LED headlights for low and high

beam

LED headlights for low and high beam

ensure better visibility under all

conditions.
Operation is the same as for halogen

headlights.
Light switch 3 116.
High beam 3 117.
Headlight flash 3 118.
Headlights when driving abroad

3

 119.

Automatic light control 3 117.

Lighting

121

AFL-LED lighting functions

AFL-LED lighting functions are active

automatically with light switch in

position AUTO. AFL-LED includes

following functions:

● curve and cornering lights
● town light
● country light
● motorway light
● high beam assist
● reverse parking function
● eco mode
● dynamic automatic headlight

levelling

Curve and cornering lights

On tight bends or when turning off,

depending on the steering angle or

the indicator light signal, an additional

left or right reflector is switched on

which illuminates the road in the

direction of travel. It is activated up to

a speed of 70 km/h.

Town light

Activated automatically at a speed up

to approx. 55 km/h. In situations with

exterior ambient light both cornering

lights are switched on with reduced

intensity. The light is wide and

symmetrical.

Country light

Activated automatically at a speed of

approx. 55 km/h. The beam of light

and the brightness is different

between the left and the right side.

High beam assist

This feature allows high beam to

function as the main driving light at

night and when vehicle speed

exceeds 40 km/h.
It switches automatically to low beam

when:

● The camera or a sensor in the

windscreen detects the lights of

oncoming or preceding vehicles.

● The vehicle speed drops below

20 km/h.

● It is foggy or snowy.
● Driving in urban areas.

If there are no restrictions detected,

the system switches back to high

beam.

122

Lighting

Activation

The high beam assist is activated by

pushing the indicator lever twice. The

high beam is switched on

automatically at a speed above

40 km/h.
The green control indicator f

illuminates continuously when the

assist is activated, the blue one 7

illuminates when high beam is on.
Control indicator f 3 96.

Deactivation

Push indicator lever once. It is also

deactivated when front fog lights are

switched on.

If a headlight flash is activated when

the high beam is on, the high beam

assist will be deactivated.
If a headlight flash is activated when

the high beam is off, the high beam

assist will remain activated.
The latest setting of the high beam

assist will remain after the ignition is

switched on again.

Reverse parking function

To assist driver's orientation when

parking, both corner lights and

reversing light illuminate when

headlights are on and reverse gear is

engaged. They remain illuminated for

a short time after disengaging reverse

gear or until driving faster than

7 km/h in a forward gear.

Eco mode

If the vehicle stops, e. g. due to traffic

lights, an energy saving mode for

headlights is activated.

Dynamic automatic headlight

levelling

To prevent oncoming traffic from

being dazzled, headlight levelling is

automatically adjusted based on

vehicle inclination information.

Fault in AFL-LED lighting system

When the system detects a failure in

the LED headlight system, f

illuminates and a warning is displayed

in the Driver Information Centre.

Hazard warning flashers

Operated by pressing ¨.

Lighting

123

Turn lights

lever up

: right turn signal

lever down : left turn signal
A resistance point can be felt when

moving the lever.
Constant flashing is activated when

the lever is being moved beyond the

resistance point. It is deactivated

when the steering wheel is moved in

the opposite direction or lever is

manually moved back to its neutral

position.

Activate temporary flashing by

holding the lever just before the

resistance point. Turning lights will

flash until lever is being released.
To activate three flashes, tap the

lever briefly without passing the

resistance point.
With a trailer connected, turn signal

flashes six times and tone frequency

changes when pressing the lever until

resistance is felt and then releasing.
Move the lever to the resistance point

and hold for flashing until lever is

released.

Front fog lights

Operated by pressing >.

Rear fog light

Operated by pressing ø.
Light switch in position AUTO:

switching on rear fog light will switch

headlights on automatically.
Light switch in position 8: rear fog

light can only be switched on with

front fog lights.

Reversing lights

The reversing light comes on when

the ignition is on and reverse gear is

selected.

124

Lighting

Misted light covers

The inside of the light housing may

mist up briefly in poor, wet and cold

weather conditions, in heavy rain or

after washing. The mist disappears

quickly by itself. To help, switch on the

headlights.

Interior lighting

Instrument panel

illumination control

Brightness of the following lights can

be adjusted when the exterior lights

are on:

● instrument panel illumination
● steering wheel controls

Turn thumb wheel A and hold until

the desired brightness is obtained.

Interior lights

Courtesy light

Front

press v : off

w

: automatic switching on

and off

press u : on

Lighting

125

Rear

⃒ : on

w

: automatic switching on and off

§

: off

Reading lights

The front reading lights are located in

the overhead console.
Press s and t to turn each light on

or off.

Glove box lighting

Illuminates when the glovebox is

opened.

Sunvisor lights

Illuminates when the cover is opened.

Lighting features

Entry lighting

Welcome lighting

Following lights are switched on for a

short time by unlocking the vehicle

with the radio remote control:

● low beam
● sidelights
● tail lights
● number plate lights
● instrument panel light
● interior lights

This function works only in the dark

and facilitates locating the vehicle.
Activation or deactivation of this

function can be changed in the

vehicle settings.
Vehicle personalisation 3 106.
The following lights will additionally

switch on when driver's door is

opened:

● illumination of some switches
● some interior lights

126

Lighting

Exit lighting

Low beam, sidelights and tail lights

illuminate the surrounding area for an

adjustable time after leaving the

vehicle.

Switching on

Activation, deactivation and duration

of lighting of this function can be

changed in the vehicle settings.
Vehicle personalisation 3 106.

1. Switch off ignition.
2. Remove ignition key.
3. Open driver's door.

4. Pull turn signal lever.
5. Close driver's door.

If the driver's door is not closed the

lights switch off after a few seconds.
The lighting is switched off

immediately if the turn signal lever is

pulled while the driver's door is open.

Battery discharge protection

To prevent discharge of the battery

when the ignition is switched off,

some interior lights are switched off

automatically after some time.

Climate control

127

Climate control

Climate control systems ............. 127

Heating and ventilation system 127

Air conditioning system ........... 128

Electronic climate control

system .................................... 129

Auxiliary heater ........................ 131

Air vents ..................................... 131

Adjustable air vents ................. 131

Fixed air vents ......................... 132

Maintenance .............................. 132

Air intake ................................. 132

Air conditioning regular

operation ................................ 132

Service .................................... 132

Climate control systems

Heating and ventilation

system

Controls for:

● air distribution
● temperature
● fan speed
● demisting and defrosting

Heated rear window Ü 3 37.

Temperature

red : warm

blue : cold

Heating will not be fully effective until

the engine has reached normal

operating temperature.

Air distribution

l

: to windscreen and front door

windows

M

: to head area

K

: to foot well and windscreen

Combination settings are possible.

Fan speed

Adjust the air flow by switching the fan

to the desired speed.

Demisting and defrosting

● Press V: fan automatically

switches to higher speed, the air

distribution is directed towards

the windscreen.

● Set temperature control to

warmest level.

● Switch on heated rear window Ü.
● Open side air vents as required

and direct them towards the door

windows.

128

Climate control

Air conditioning system

In addition to the heating and

ventilation system, the air

conditioning system has controls for:
n

: cooling

4

: air recirculation

Cooling n

Press n to switch on cooling. The

LED in the button illuminates to

indicate activation. Cooling is only

functional when the engine is running

and climate control fan is switched on.
Press n again to switch off cooling.

The air conditioning system cools and

dehumidifies (dries) as soon as the

outside temperature is above a

specific level. Therefore

condensation may form and drip from

under the vehicle.
If no cooling or drying is required,

switch off the cooling system for fuel

saving reasons. Activated cooling

may inhibit Autostops.
Stop-start system 3 139.

Air recirculation system 4

Press 4 to activate air recirculation

mode. The LED in the button

illuminates to indicate activation.
Press 4 again to deactivate air

recirculation mode.

9 Warning

The exchange of fresh air is

reduced in air recirculation mode.

In operation without cooling the air

humidity increases, so the

windows may mist up from inside.

The quality of the passenger

compartment air deteriorates,

which may cause the vehicle

occupants to feel drowsy.

In warm and very humid ambient air

conditions, the windscreen may mist

up from outside when cold air is

directed towards it. If windscreen

mists up from outside, activate

windscreen wiper and deactivate l.

Maximum cooling

Briefly open the windows so that hot

air can disperse quickly.

● Switch on cooling n.
● Air recirculation system 4 on.
● Press air distribution switch M.
● Set temperature control to

coldest level.

● Set fan speed to highest level.
● Open all vents.

Climate control

129

Demisting and defrosting the

windows V

● Press V: fan automatically

switches to higher speed, the air

distribution is directed towards

the windscreen.

● Set temperature control to

warmest level.

● Switch on heated rear window Ü.
● Open side air vents as required

and direct them towards the door

windows.

Note

If V is pressed while the engine is

running, an Autostop will be inhibited

until V is pressed again.
If l is pressed with the fan switched

on and the engine running, an

Autostop will be inhibited until l is

pressed again or until the fan is

switched off.
If V is pressed while the engine is

in an Autostop, the engine will restart

automatically.

If l is pressed with the fan switched

on while the engine is in an

Autostop, the engine will restart

automatically.

Stop-start system 3 139.

Electronic climate control

system

Controls for:

● air distribution
● temperature
● fan speed

AUTO : automatic mode

4

: manual air recirculation

V

: demisting and defrosting

Heated rear window Ü 3 37.
The preselected temperature is

automatically regulated. In automatic

mode, the fan speed and air

distribution automatically regulate the

air flow.
The system can be manually adapted

via the use of air distribution and air

flow controls.
Each change of settings is shown in

the Info Display for a few seconds.
The electronic climate control system

is only fully operational when the

engine is running.

Automatic mode AUTO

Basic setting for maximum comfort:

● Press AUTO: the air distribution

and fan speed are regulated

automatically.

● Open all air vents.
● Press n to switch on cooling.
● Set the desired temperature.

130

Climate control

Temperature preselection

Temperatures can be set to the

desired value.
If the minimum temperature is set, the

climate control system runs at

maximum cooling.
If the maximum temperature is set,

the climate control system runs at

maximum heating.

Note

If the temperature is to be reduced

for climate comfort reasons, an

Autostop may be inhibited or the

engine will restart automatically

when cooling is switched on.
Stop-start system 3 139.

The temperature can be adjusted

separately for driver and front

passenger side.

Demisting and defrosting the

windows V

● Press V.
● Temperature and air distribution

are set automatically and the fan

runs at high speed.

● Switch on heated rear window Ü.
● To return to previous mode:

press V, to return to automatic

mode: press AUTO.

Note

If V is pressed while the engine is

running, an Autostop will be inhibited

until V is pressed again.
If l is pressed with the fan switched

on and the engine running, an

Autostop will be inhibited until l is

pressed again or until the fan is

switched off.
If V is pressed while the engine is

in an Autostop, the engine will restart

automatically.
If l is pressed with the fan switched

on while the engine is in an

Autostop, the engine will restart

automatically.

Stop-start system 3 139.

Manual settings

Climate control system settings can

be changed by activating the buttons

and rotary knobs as follows.

Changing a setting will deactivate the

automatic mode.

Fan speed Z

The selected fan speed is indicated

with x and a number in the display. If

the fan is switched off, the air

conditioning is also deactivated.
To return to automatic mode: Press

AUTO.

Air distribution l, M, K

Press appropriate button for desired

adjustment. The LED in the button

illuminates to indicate activation.
l

: to windscreen and front door

windows (air conditioning is

activated in the background to

help prevent windows from

fogging)

M

: to head area

K

: to foot well and windscreen

Combination of settings are possible.

Climate control

131

Return to automatic air distribution:

Deactivate corresponding setting or

press AUTO.

Cooling n

Press n to switch on cooling. The

LED in the button illuminates to

indicate activation. Cooling is only

functional when the engine is running

and climate control fan is switched on.
Press n again to switch off cooling.
The air conditioning system cools and

dehumidifies (dries) when outside

temperature is above a specific level.

Therefore condensation may form

and drip from under the vehicle.
If no cooling or drying is required,

switch off the cooling system for fuel

saving reasons. Activated cooling

may inhibit an Autostop.
Stop-start system 3 139.
Eco appears in the display when

cooling is deactivated.

Air recirculation mode 4

Press 4 once to activate the

manual air recirculation mode.

9

Warning

The exchange of fresh air is

reduced in air recirculation mode.

In operation without cooling the air

humidity increases, so the

windows may mist up from inside.

The quality of the passenger

compartment air deteriorates,

which may cause the vehicle

occupants to feel drowsy.

Air conditioning with the engine

not running

When ignition is off, the residual heat

or cooling in the system can be used

for climate control in passenger

compartment.

Auxiliary heater

Air heater

Quickheat is an electric auxiliary air

heater which automatically warms up

the passenger compartment more

quickly.

Air vents

Adjustable air vents

At least one air vent must be open

while the cooling is on.

To open the vent, turn the adjuster

wheel to the right. Adjust the air

amount at the vent outlet by turning

the adjuster wheel.

132

Climate control

Direct the flow of air by tilting and

swivelling the slats.
To close the vent, turn the adjuster

wheel to the left.

9 Warning

Do not attach any objects to the

slats of the air vents. Risk of

damage and injury in case of an

accident.

Fixed air vents

Additional air vents are located

beneath the windscreen and door

windows and in the foot wells.

Maintenance

Air intake

The air intake in front of the

windscreen in the engine

compartment must be kept clear to

allow air intake.
Remove any leaves, dirt or snow.

Air conditioning regular

operation

In order to ensure continuously

efficient performance, cooling must

be operated for a few minutes once a

month, irrespective of the weather

and time of year. Operation with

cooling is not possible when the

outside temperature is too low.

Service

For optimal cooling performance, it is

recommended to annually check the

climate control system, starting

three years after initial vehicle

registration, including:

● functionality and pressure test
● heating functionality
● leakage check
● check of drive belts
● cleaning of condenser and

evaporator drainage

● performance check

Note

Refrigerant R-134a contains

fluorinated greenhouse gases.

Driving and operating

133

Driving and

operating

Driving hints ............................... 134

Control of the vehicle ............... 134

Steering ................................... 134

Starting and operating ............... 134

New vehicle running-in ............ 134

Ignition switch positions ........... 135

Power button ........................... 136

Retained power off .................. 137

Starting the engine .................. 137

Overrun cut-off ........................ 139

Stop-start system .................... 139

Parking .................................... 141

Engine exhaust .......................... 142

Exhaust filter ............................ 142

Catalytic converter ................... 143

AdBlue ..................................... 144

Automatic transmission .............. 146

Transmission display ............... 146

Selector lever .......................... 147

Manual mode ........................... 148

Electronic driving programmes 148

Fault ........................................ 148

Interruption of power supply .... 149

Manual transmission .................. 149
Drive systems ............................ 150

All-wheel drive ......................... 150

Brakes ........................................ 151

Antilock brake system ............. 151

Parking brake .......................... 151

Brake assist ............................. 152

Hill start assist ......................... 152

Ride control systems ................. 152

Traction Control system .......... 152

Electronic Stability Control ...... 153

Descent control system ........... 154

Driver assistance systems ......... 155

Cruise control .......................... 155

Speed limiter ........................... 157

Forward collision alert ............. 158

Following distance indication ... 160

Parking assist .......................... 161

Rear view camera ................... 163

Traffic sign assistant ................ 165

Lane departure warning .......... 168

Fuel ............................................ 169

Fuel for petrol engines ............. 169

Fuel for diesel engines ............ 171

Fuel for liquid gas operation .... 171

Refuelling ................................ 172

Trailer hitch ................................ 176

General information ................. 176

Driving characteristics and

towing tips .............................. 176

Trailer towing ........................... 177

Towing equipment ................... 177
