Opel Astra Twintop (2012 year). Manual - part 14





210

Service and maintenance

Fixed service interval

When service is due, InSP appears in

the service display for approx.

10 seconds when the ignition is

switched on. Have the next service

performed by a workshop within

one week or 500 km (whichever

occurs first).
Service display 3 94.

Flexible service interval

The service interval is based on

several parameters depending on

usage and is calculated using these

parameters.
If the remaining distance is less than

1500 km, InSP is displayed with

a remaining distance of 1000 km

when the ignition is switched on and

off. If less than 1000 km remain,

InSP is displayed for several

seconds. Have the next service

performed by a workshop within

one week or 500 km (whichever

occurs first).

Display of remaining distance:

1. Switch off ignition.
2. Briefly press the trip odometer

reset button. The odometer

reading is shown.

3. Press and hold the reset button for

about 2 seconds. InSP and the

remaining distance are displayed.

Service display 3 94.

Recommended fluids,

lubricants and parts

Recommended fluids and

lubricants

Only use products that have been

tested and approved. Damage

resulting from the use of non-

approved materials will not be

covered by the warranty.

Warning

Operating materials are

hazardous and could be

poisonous. Handle with care. Pay

attention to information given on

the containers.

Engine oil

Engine oil is identified by its quality

and its viscosity. Quality is more

important than viscosity when

selecting which engine oil to use. The

oil quality ensures e.g. engine

cleanliness, wear protection and oil

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Service and maintenance

211

aging control, whereas viscosity

grade gives information on the oil's

thickness over a temperature range.
Dexos is the newest engine oil quality

that provides optimum protection for

gasoline and diesel engines. If it is

unavailable, engine oils of other listed

qualities have to be used.

Recommendations for gasoline

engines are also valid for

Compressed Natural Gas (CNG),

Liquified Petroleum Gas (LPG) and

Ethanol (E85) fueled engines.
Select the appropriate engine oil

based on its quality and on the

minimum ambient temperature

3

 215.

Topping up engine oil

Engine oils of different manufacturers

and brands can be mixed as long as

they comply with the required engine

oil quality and viscosity.
Use of engine oil with only

ACEA A1/B1 or only A5/B5 quality is

prohibited, since it can cause long-

term engine damage under certain

operating conditions.

Select the appropriate engine oil

based on its quality and on the

minimum ambient temperature

3

 215.

Additional engine oil additives

The use of additional engine oil

additives could cause damage and

invalidate the warranty.

Engine oil viscosity grades

The SAE viscosity grade gives

information of the thickness of the oil.
Multigrade oil is indicated by two

figures, e.g. SAE 5W-30. The first

figure, followed by a W, indicates the

low temperature viscosity and the

second figure the high temperature

viscosity.
Select the appropriate viscosity grade

depending on the minimum ambient

temperature 3 215.
All of the recommended viscosity

grades are suitable for high ambient

temperatures.

Coolant and antifreeze

Use only silicate-free long life coolant

(LLC) antifreeze.
The system is factory filled with

coolant designed for excellent

corrosion protection and frost

protection down to approx. -28 °C.

This concentration should be

maintained all year round. The use of

additional coolant additives that

intend to give additional corrosion

protection or seal against minor leaks

can cause function problems. Liability

for consequences resulting from the

use of additional coolant additives will

be rejected.

Brake and clutch fluid

Only use high-performance brake

fluid approved for the vehicle, consult

your workshop.
Over time, brake fluid absorbs

moisture which will reduce braking

effectiveness. The brake fluid should

therefore be replaced at the specified

interval.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

212

Service and maintenance

Brake fluid should be stored in

a sealed container to avoid water

absorption.
Ensure brake fluid does not become

contaminated.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Technical data

213

Technical data

Vehicle identification .................. 213
Vehicle data ............................... 215

Vehicle identification

Vehicle Identification

Number

The Vehicle Identification Number is

stamped on the identification plate

and on the floor pan, under the floor

covering, visible under a cover.

The Vehicle Identification Number

may be embossed on the instrument

panel visible through the windscreen.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

214

Technical data

Identification plate

The identification plate is located on

the front right door frame.

Information on identification plate:
1 = Manufacturer

2 = Type approval number

3 = Vehicle Identification Number

4 = Permissible gross vehicle

weight rating in kg

5 = Permissible gross train weight

in kg

6 = Maximum permissible front axle

load in kg

7 = Maximum permissible rear axle

load in kg

8 = Vehicle-specific or country-

specific data

The combined total of front and rear

axle loads must not exceed the

permissible gross vehicle weight. For

example, if the front axle is bearing its

maximum permissible load, the rear

axle can only bear a load that is equal

to the gross vehicle weight minus the

front axle load.
The technical data is determined in

accordance with European

Community standards. We reserve

the right to make modifications.

Specifications in the vehicle

documents always have priority over

those given in this manual.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Technical data

215

Vehicle data

Recommended fluids and lubricants

European service schedule

Required engine oil quality

All European countries

(except Belarus, Moldova, Russia, Serbia, Turkey)

Only Israel

Engine oil quality

Petrol engines

(including CNG, LPG, E85)

Diesel engines

Petrol engines

(including CNG, LPG, E85)

Diesel engines

dexos 1

dexos 2

In case dexos quality is unavailable you may use max. 1 litre engine oil quality ACEA C3 once between each oil change.

Engine oil viscosity grades

All European countries and Israel
(except Belarus, Moldova, Russia, Serbia, Turkey)

Ambient temperature

Petrol and diesel engines

down to -25 °C

SAE 5W-30 or SAE 5W-40

below -25 °C

SAE 0W-30 or SAE 0W-40

-------------------------------------------------------------------------------------------------------------------------------------------------------------

216

Technical data

International service schedule

Required engine oil quality

All countries outside Europe

except Israel

Only Belarus, Moldova, Russia, Serbia, Turkey

Engine oil quality

Petrol engines

(including CNG, LPG, E85)

Diesel engines

Petrol engines

(including CNG, LPG, E85)

Diesel engines

dexos 1

dexos 2

In case dexos quality is unavailable you may use the oil qualities listed below:

All countries outside Europe

except Israel

Only Belarus, Moldova, Russia, Serbia, Turkey

Engine oil quality

Petrol engines

(including CNG, LPG, E85)

Diesel engines

Petrol engines

(including CNG, LPG, E85)

Diesel engines

GM-LL-A-025

GM-LL-B-025

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Technical data

217

All countries outside Europe

except Israel

Only Belarus, Moldova, Russia, Serbia, Turkey

Engine oil quality

Petrol engines

(including CNG, LPG, E85)

Diesel engines

Petrol engines

(including CNG, LPG, E85)

Diesel engines

ACEA A3/B3

ACEA A3/B4

ACEA C3

API SM

API SN

Engine oil viscosity grades

All countries outside Europe (except Israel),
including Belarus, Moldova, Russia, Serbia, Turkey

Ambient temperature

Petrol and diesel engines

down to -25 °C

SAE 5W-30 or SAE 5W-40

below -25 °C

SAE 0W-30 or SAE 0W-40

down to -20 °C

SAE 10W-30

1)

 or SAE 10W-40

1)

1)

Permitted, but usage of SAE 5W-30 or SAE 5W-40 with dexos quality is recommended.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

218

Technical data

Engine data

Sales designation

1.2

1.4

1.6

1.6

1.8

Engine identifier code

Z 12 XEP

Z 14 XEP

Z 16 XER,
A 16 XER

Z 16 LET,
A 16 LET

Z 18 XER,
A 18 XER

Number of cylinders

4

4

4

4

4

Piston displacement [cm

3

]

1229

1364

1598

1598

1796

Engine power [kW]

59

66

85

132

103

at rpm

5600

5600

6000

5500

6300

Torque [Nm]

110

125

155

230

175

at rpm

4000

4000

4000

1980-5500

3800

Fuel type

Petrol

Petrol

Petrol

Petrol

Petrol

Octane rating RON
recommended

95

95

95

95

95

possible

98

98

98

98

98

possible

91

91

91

91

Oil consumption [l/1000 km]

0.6

0.6

0.6

0.6

0.6

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Technical data

219

Sales designation

2.0 Turbo

2.0 Turbo

1.3 CDTI

1.7 CDTI

1.7

Engine identifier code

Z 20 LER

Z 20 LEH

Z 13 DTH

Z 17 DTH

Z 17 DTJ,
A 17 DTJ

Number of cylinders

4

4

4

4

4

Piston displacement [cm

3

]

1998

1998

1248

1686

1686

Engine power [kW]

147

177

66

74

81

at rpm

5400

5600

4000

4400

3800

Torque [Nm]

262

320

200

240

260

at rpm

4200

2400-5000

1750-2500

2300

2300

Fuel type

Petrol

Petrol

Diesel

Diesel

Diesel

Octane rating RON
recommended

95

98

possible

98

95

possible

91

2)

91

2)

Oil consumption [l/1000 km]

0.6

0.6

0.6

0.6

0.6

2)

Possible only if high engine load, full load or driving in mountainous terrain with a caravan/trailer or high payload is

avoided.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

220

Technical data

Sales designation

1.7

1.9 CDTI

1.9 CDTI

1.9 CDTI

Engine identifier code

Z 17 DTR,
A 17 DTR

Z 19 DTL

Z 19 DT

Z 19 DTH

Number of cylinders

4

4

4

4

Piston displacement [cm

3

]

1686

1910

1910

1910

Engine power [kW]

92

74

88

110

at rpm

4000

3500

3500

4000

Torque [Nm]

280

260

280

320

at rpm

2300

1700-2500

2000-2750

2000-2750

Fuel type

Diesel

Diesel

Diesel

Diesel

Oil consumption [l/1000 km]

0.6

0.6

0.6

0.6

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Technical data

221

Performance

Saloon 5-door

Engine

Z12XEP

Z14XEP

Z16XER,
A16XER

Z16LET

Z18XER

Maximum speed

3)

 [km/h]

Manual transmission

171

178

191

221

208

Manual transmission automated

176

192

Automatic transmission

188

Engine

Z20LER

Z13DTH

Z17DTH

Z17DTJ

Z17DTR

Maximum speed [km/h]
Manual transmission

230

172

180

185 / 188

4)

195

Manual transmission automated

171

Automatic transmission

3)

The maximum speed indicated is achievable at kerb weight (without driver) plus 200 kg payload. Optional equipment

could reduce the specified maximum speed of the vehicle.

4)

For model with pollutant reduction.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

222

Technical data

Engine

A17DTJ

A17DTR

Z19DTL

Z19DT

Z19DTH

Maximum speed [km/h]
Manual transmission

186

195

180

194

208

Manual transmission automated

Automatic transmission

188

Saloon 3-door

Engine

Z14XEP

Z16XER,
A16XER

Z16LET,
A16LET

Z18XER,
A18XER

Z20LER

Maximum speed [km/h]
Manual transmission

180

193

223

210

234

Manual transmission automated

178

194

Automatic transmission

190

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Technical data

223

Engine

Z20LEH

Z13DTH

Z17DTH

Z17DTJ

Z17DTR,
A17DTR

Maximum speed [km/h]
Manual transmission

244

174

182

187 / 188

197

Manual transmission automated

174

Automatic transmission

Engine

A17DTJ

Z19DTL

Z19DT

Z19DTH

Maximum speed [km/h]
Manual transmission

188

182

196

210

Manual transmission automated

Automatic transmission

190

-------------------------------------------------------------------------------------------------------------------------------------------------------------

224

Technical data

Saloon 4-door

Engine

Z16XER,
A16XER

Z18XER,
A18XER

Z13DTH

Z17DTH

Z17DTJ

Maximum speed [km/h]
Manual transmission

191

207

172

180

188

Manual transmission automated

192

Automatic transmission

188

Station wagon

Engine

Z14XEP

Z16XER,
A16XER

Z16LET,
A16LET

Z18XER,
A18XER

Maximum speed [km/h]
Manual transmission

178

191

221

207

Manual transmission automated

192

Automatic transmission

188

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Technical data

225

Engine

Z20LER

Z13DTH

A17DTJ

Z17DTH

Z17DTJ

Maximum speed [km/h]
Manual transmission

230

172

185

180

185 / 188

Manual transmission automated

Automatic transmission

Engine

Z17DTR,
A17DTR

Z19DTL

Z19DT

Z19DTH

Maximum speed [km/h]
Manual transmission

195

180

193

207

Manual transmission automated

Automatic transmission

187

Van

Engine

Z14XEP

Z13DTH

Z17DTH

Z17DTJ

Maximum speed [km/h]
Manual transmission

178

172

180

185

Manual transmission automated

Automatic transmission

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     12      13      14      15     ..
