2A – 86 SUPPLEMENTAL RESTRAINT SYSTEM STEERING WHEEL & COLUMN INSTALLATION 11. Steering column assembly Align the setting marks on the universal joint and Tighten the steering column fixing bolt (dash panel) Steering Column Bolt Torque N·m (kg·m/lb·ft) 19 (1.9 / 14) Tighten the steering column fixing bolt ( pedal Steering Column Bolt Torque N·m (kg·m/lb·ft) 17 (1.7 / 13) Tighten the universal joint to the specified torque. Universal Joint Torque N·m (kg·m/lb·ft) 25 (2.5 / 18) 10. Lock cylinder assembly 9. Shift lock cable (for A/T) 8. Cushion rubber 7. Snap ring 6. Combination switch After installation of combination switch assembly, 5. Steering column cover 4. Steering wheel Align the setting marks made when removing. CAUTION: Tighten the steering wheel fixing nut to the specified Steering wheel Nut Torque N·m (kg·m/lb·ft) 34 (3.5 / 25) 3. Steering lower cover Install the engine hood opening lever. 2. Lower cluster assembly 1. Front console assembly Connect the wiring harness connectors. Install the transmission (for M/T) and transfer control |
