2A – 58 SUPPLEMENTAL RESTRAINT SYSTEM STEERING WHEEL & COLUMN 1. Inflator Module 1) Loosen the inflator module fixing bolt from behind the steering wheel assembly using a driver or equivalent until the inflator module can be released from steering assembly. 2) Disconnect the yellow 2way SRS connector located behind the inflator module. WARNING 2. Horn Lead 3. Steering Wheel Fixing Nut 4. Steering Wheel 1) Apply a setting mark across the steering wheel and shaft so parts can be reassembled in their 2) Move the front wheels to the straight ahead position and use special tool. Steering wheel remover: 5-8840-0016-0 (J-29752) NOTE: 827RS014 827RS016 430RS004 Up Setting mark |
