A/T Shift Lock

General Description

The circuit consists of stoplight switch or brake
switch and shift lock controller.
This system is designed not to allow shift lever to be
shifted from “P” position to any other position
without depressing brake pedal while starter switch
is turned on.
The solenoid pin at the lower portion of shift lever
retracts when brake pedal is not depressed, thus
causing shift lever cam to be locked by link lever.

WIRING SYSTEM

8D–299

Circuit Diagram (RHD)

0.5

L/W

3.0

B/Y

0.85

L/W

C-4 10A
ELEC. IGN.

STARTER SW

(IG1)

BATT.(+)

STOPLIGHT

SHIFT LOCK

SOLENOID

PARKING POSITION

DETECTING SW

1

B-32

0.85
G/W

0.85
G/W

0.85

G/Y

0.85

G/Y

0.85
G/W

0.85

G/Y

4

2

B-32

B-32

B-32

6

0.5

B

2.0

B

BODY-LH

B-2

2.0

B

BODY-CTR

B-26

2.0

B

BODY-RH

B-18

AC GENERATOR

(L)

5.0

W

C-14 15A
STOP, A/T CONT

5

B-32

13

H-15

0.85
W/G

STOPLIGHT
SW

1

B-14

7

H-32

B-14

2

4

1

(W/O CRUISE
 CONTROL)

BRAKE
SW

B-13

B-13

(W/ CRUISE
 CONTROL)

SHIFT LOCK CONTROLLER

D08RW659

8D–300

WIRING SYSTEM

Parts Location (RHD)

Legend

(1) B-13 or B-14
(2) Shift Lever
(3) H-32
(4) B-2
(5) B-26

(6) Shift Lock Controller (B-32)
(7) B-18
(8) Relay and Fuse Box
(9) H-15

(10) Fuse Box

3

4

5

6

7

8

9

10

1

2

D08RWA08

WIRING SYSTEM

8D–301

Circuit Diagram (LHD)

0.5

L/W

3.0

B/Y

0.5

L/W

C-4 10A
ELEC. IGN.

STARTER SW

(IG1)

BATT.(+)

STOPLIGHT

SHIFT LOCK

SOLENOID

PARKING POSITION

DETECTING SW

1

B-32

0.85
G/W

0.85
G/W

0.85

G/Y

0.85

G/Y

0.85
G/W

0.85

G/Y

4

2

B-32

B-32

B-32

6

0.5

B

2.0

B

BODY-CTR

B-26

AC GENERATOR

(L)

5.0

W

C-14 15A
STOP, A/T CONT

5

B-32

11

H-15

0.85
W/G

STOPLIGHT
SW

1

B-14

7

H-32

B-14

2

4

1

(W/O CRUISE
 CONTROL)

BRAKE
SW

B-13

B-13

(W/ CRUISE
 CONTROL)

SHIFT LOCK CONTROLLER

D08RW956
