MANUAL TRANSMISSION 7B–9 16. Remove the slave cylinder heat protector. (6VE1) 225RW006 18. Remove two transmission harness clamps and bracket (6VE1). 19. Remove the slave cylinder. 206RW002 20. Remove the two dust cover from transmission case. 22. Remove two engine rear mount nuts. (6VE1) 022RT002 23. Remove third crossmember (6VE1). (4JX1). (4JX1) 022RW013 25. Remove two engine rear mount bolts (6VE1). (6VE1). 27. Remove three flywheel under cover (6VE1). |
