6A – 42 ENGINE MECHANICAL 2. Cylinder head for cracks, especially between valve seats and in the exhaust ports. 3. Cylinder head deck for corrosion, sand particles in head and porosity. CAUTION: Do not attempt to weld the cylinder 4. Cylinder head lower surface for flatness. Use a straight edge and a feeler gauge to measure Cylinder Head Height: 5. Water jacket sealing plugs seating surfaces. the manifold cylinder head fitting face warpage. CAUTION: Do not attempt to weld the cylinder REASSEMBLY 1. Cylinder Head • Refer to “Cylinder Head Gasket”. 2. Glow Plug and Glow Plug Connector • Tighten glow plugs. Torque: 15 N·m (1.5 kg·m/11 lb ft) 011RW006 012RW053 |
