FUEL SYSTEM 6C – 21 ACCELERATOR CONTROL ACCELERATOR CONTROL CABLE REMOVAL 1. Adjusting Nut • Loosen the adjust nut on the cable bracket 2. Accelerator Control Cable (on injection pump side) 3. Accelerator Control Cable (on accelerator pedal 4. Grommet 5. Accelerator Control Cable INSPECTION Check the following items, and replace the control cable • The control cable should move smoothly. • The control cable should not be bent or kinked. • The control cable should be free of damage and Removal Steps 1. Adjusting nut (Injection pump side) 3. Accelerator control cable (Accelerator pedal side) 4. Grommet Installation Steps To install, follow the removal steps in the |
