7B–60 MANUAL TRANSMISSION 2. Install the synchronizer outer ring, synchronizer cone ring, and synchronizer pull ring to the 226RW121 3. Turn to 30 degree the reverse synchronizer pull ring. 226RW080 4. Install the hub sleeve No.3 and reverse block ring set to the counter 5th gear. NOTE: Check the hub sleeve No.3 direction, as shown. Reference: While pushing the 3 inserts, 226RW184 5. Slide the hub sleeve No.3. 226RW123 |
