7A–38 AUTOMATIC TRANSMISSION (4L30–E) 20. Install harness protector. 815RW002 21. Install the front propeller shaft, and tighten the bolts to the specified torque. Torque: 63 N • m (6.4 kg·m/46 Ib ft) Front differential side bolt (W/TOD) Torque: 43 N • m (4.4 kg·m/32 Ib ft) 22. Install the rear propeller shaft, and tighten the bolts to the specified torque. Torque: 63 N • m (6.4 kg·m/46 Ib ft) 23. Connect the shift control rod to selector lever assembly. 24. Install the transfer protectors, and tighten the bolts to the specified torque. Torque: 37 N • m (3.8 kg·m/27 Ib ft) 25. Install the transfer control lever. console. 28. Install the front console. |
