6A – 14 ENGINE MECHANICAL

TIGHTENING TORQUE

Timing Gear Case, Timing Gear

N·m (kg·m/lb·ft)

75(7.6/55)

Apply engine oil to
thread and seat

8(0.8/69lb•in)

20(2.0/14)

51(5.2/38)

25(2.5/18)

020R200001

ENGINE MECHANICAL 6A – 15

Cylinder Head, Flywheel, Crank Case, Oil Pan

N·m (kg·m/lb·ft)

012R200008

1st

49N•m(5.0kg•m/36 Ib ft)

167(17.0/123)

8(0.8/69lb•in)

20(2.0/14)

20(2.0/14)

30(3.1/22)

24(2.4/17)

2nd

60

°

1st

59N•m(6.0kg•m/43 Ib ft)

Apply engine oil to thread

Apply engine oil to thread

Apply engine oil to thread

2nd

60

°

-90

°

3rd

60

°

-90

°

1st

29N•m(3.0kg•m/22 Ib ft)

2nd

45

°

-60

°

3rd

60

°

22(2.2/16)

6A – 16 ENGINE MECHANICAL

Intake / Exhaust Manifold

N·m (kg·m/lb·ft)

025R200009

For Europe

For Europe

20(2.0/14)

20(2.0/14)

20(2.0/14)

22(2.2/16)

22(2.2/16)

30(3.1/22)

27(2.8/20)

30(3.1/22)

20(2.0/14)

5 4 2 8 9 C

黒

01/0

01/08/30

ENGINE MECHANICAL 6A – 17

Timing Pulley

N·m (kg·m/lb·ft)

020R200002

20(2.0/14)

40(4.1/30)

60

°

-90

°

1st

2nd

10(1.0/87lb•in)

20(2.0/14)

50(5.1/37)

20(2.0/14)

9(0.9/78lb•in)

9(0.9/78lb•in)
