POWER ASSISTED BRAKE SYSTEM 5C – 61 4. Guide Bolt 3. Lock Bolt Lock Bolt Torque N·m (kg·m / lb·ft) 44 (4.5 / 32) 3 4 2. Brake Flexible Hose 1) Always use new gaskets. hose end into the anti-rotation cavity. Brake Flexible Hose Torque N·m (kg·m / lb·ft) 35 (3.5 / 26) Hooked edge Gasket 1. Wheel and Tire Assembly 1) Refer to Wheels and Tires in Suspension section. |
