POWER ASSISTED BRAKE SYSTEM 5C – 45 REMOVAL 1. Master Cylinder • Refer to Master Cylinder Assembly in this Section. 2. Vacuum Booster • Refer to Vacuum Booster Assembly in this 3. Yoke Clevis 4. Lock Nut 5. Retaining Clip 6. Valve Body Guard 7. Silencer 8. Filter 9. 2 gaskets and Spacer 10. Retainer • Use a small screwdriver to pry out the retainer. 11. Plate and Seal Assembly INSPECTION AND REPAIR Visual Check: Make necessary parts replacement if cuts, nicks, 1) Yoke clevis INSTALLATION 11. Plate and Seal Assembly 10. Retainer 9. 2 gaskets and Spacer 8. Filter 7. Silencer 6. Valve Body Guard 5. Retaining Clip 4. Lock Nut Lock Nut Torque N·m (kg·m / lb·ft) 20 (2.0 / 15) |
