6C–7 ENGINE FUEL Fuel Pump Relay General Description In order to control the FP operation, the FP relay is When it is turned to “START” position, the Power Train Fuel Tank Fuel Tank and Associated Parts 035RW048 Legend (1) Fender Liner Evapo Hose (3) Undercover (4) Fuel Tank Wiring Connector Tube/Quick–Connect Fittings (7) Fuel Tank Removal CAUTION: When repair to the fuel system has been 1. Disconnect battery ground cable. 3. Drain fuel. Tighten drain plug to the specified torque after Torque: 20 N·m (2.0 Kg·m/14 lb ft) — M8 4. Remove fender liner (1) of wheel well on rear right side. 5. Fuel filler hose, air breather hose and evapo hose (2). remove under cover(3). |
