4D2–24 TRANSFER CASE (TOD) Disassembly 1. Remove the ball bearing (for front output shaft). planetary gear assembly. 261RW040 3. While expanding the snap ring, remove the input shaft, ball bearing, carrier assembly, and thrust plate 261RW037 4. Remove the snap ring from the transfer case. 261RW036 5. Using snap ring pliers, remove the snap ring before the ball bearing. 265RW009 |
