SEAT BELT SYSTEM 9A–15 Rear Seat Lock Assembly Removal 1. Remove the seat lock cover(3). Installation To install, follow the removal steps in the reverse order, 1. Tighten the seat lock fixing bolts to the specified torque. Torque: 42 N·m (4.3 kg·m/31 lb ft) L.W.B 1 2 S.W.B 1 2 3 3 755RW040 Rear Seat Lock Assembly (Bench Type) Removal 1. Remove the seat lock cover(3). the both sides, and then remove the rear seat lock Installation To install, follow the removal steps in the reverse order, 1. Tighten the seat lock fixing bolts to the specified torque. Torque: 42 N·m (4.3 kg·m/31 lb ft) 1 2 3 760RW003 |
