SEAT BELT SYSTEM 9A–7 Inspection of retractor 1. ELR (Emergency Locking Retractor) lock inclining angle check. ● When the retractor is moved gently from its installing 2. ELR lock check. ● When the seat belt is drawn slowly with the retractor 3. ALR (Automatic Locking Retractor)/ELR check (Except for driver’s seat). ● When rewound after winding out the seat belt, make CAUTION: Do not disassemble the retractor. Installation To install, follow the removal steps in the reverse order, 1. Tighten the seat belt anchor bolts to the specified torque. Torque: 39 N·m (4.0 kg·m/29 lb ft) |
