8I–12 SUN ROOF/CONVERTIBLE TOP Sun Roof Motor Removal 1. Disconnect the battery ground cable. D Refer to the Headlining removal steps in Body 3. Disconnect the connector, and remove three nuts and two screws to remove the sun roof motor(1). 665RW034 Installation To install, follow the removal steps in the reverse order, 1. When installing the sun roof motor, close the sun roof glass completely. Main Data and Specifications Torque Specifications Application N·m kg·m lb ft lb in Sun Roof Frame Complete Assembly Fixing Bolts 10 1.0 — 87 Sun Roof Glass Fixing Screws 10 1.0 — 87 |
