8F–75 BODY STRUCTURE 5. Remove tailgate fixing bolts. 681RS002 6. Remove tailgate assembly (LH). D Apply a setting mark (1) on the body side hinge and 681RW007 Installation To install, follow the removal steps in the reverse order, 1. Apply chassis grease to the tailgate hinge and the tailgate stopper moving surface. 2. Align the tailgate fitting to the body by referring to Body Dimension in this section. 3. Tighten the hinge bolts to the specified torque. Torque : 34 N • m (3.5kg·m/25 lb ft) |
