7B–66 MANUAL TRANSMISSION 38. Install clutch housing. 1. Install the clutch housing to the transmission case. Torque: 36 N·m (3.7 kg·m/27 lb ft) NOTE: Tighten the all bolts evenly. 241RW001 39. Install the switches. 1. Install the new gasket to the 1st and 2nd switch. 2. Install the 1st and 2nd switch assembly (8). Torque: 39 N·m (4.0 kg·m/29 lb ft) 3. Install the new gasket to the backup light switch. 4. Install the backup light switch assembly (6). Torque: 44 N·m (4.5 kg·m/33 lb ft) 5. Install the new gasket to the neutral switch. 6. Install the neutral switch (7) to the transfer adapter (4JX1). Torque: 37 N·m (3.8 kg·m/27 lb ft) (4JX1) 220RW093 40. Install the clutch release bearing (3) and clutch shift fork (5). 1. Fitting surface of the cylinder push rod. 2. Apply the clutch release grease. 1. The spline surface of the top gear shaft. 3. Install the clutch shift fork (5). 4. Install the snap pin. 5. Install the clutch release bearing (3) to the clutch shift fork (5). 220RW086 |
