7A–102 AUTOMATIC TRANSMISSION (AW30-40LE) 248RY00006 248RY00007 248RY00008 248RY00009 12. Snap ring Using snap ring pliers, remove the snap ring. 13. Second coast brake piston assembly Applying compressed air to the oil hole, remove the second 14. Direct clutch and forward clutch Remove the direct clutch and forward clutch from the case. 15. E-ring and pin Remove the E-ring from the pin. |
