6E–42 4JX1–TC ENGINE DRIVEABILITY AND EMISSIONS 4JX1-TC Engine (Automatic and Manual Transmission) Tech 2 Parameter Data List Units Displayed Typical Data Values (IDLE) Typical Data Values (2500 RPM) Refer To Battery Voltage Engine Volts 12.5 ∼ 14.5 13 ∼ 15 General Description Ignition Status Engine On/Off On On General Description Ignition Relay 2 Engine On/Off On On General Description Idle Switch Engine Inactive/ Active — — DTC P0510, P1510 Manifold Engine KPa 96 ∼ 106 110 ∼ 150 General Description DTC P0107, P0108 Rail Oil Engine MPa 3.5 ∼ 5 4.5 ∼ 10 General Description DTC P0192, P0193 Desired Rail Oil Engine MPa 4 ∼ 5 5 ∼ 9 General Description DTC P0192, P0193 Fuel Engine ° C ( ° F) 75 ∼ 85 75 ∼ 85 DTC P0182, P0183 Quick Warming Engine On/Off Off Off DTC P0380 Thermo Relay Engine On/Off — — DTC P1655 Actual EGR Engine KPa 58 ∼ 60 M/T 63 ∼ 66 A/T 95 ∼ 105 DTC P0405, P0406 Barometric Engine KPa 98 ∼ 102 98 ∼ 102 General Description Relative EGR Engine KPa –38 ∼ –45 M/T –34 ∼ –37 A/T 0 General Description Desired EGR Engine KPa –43 ∼ –40 M/T 36 A/T 0 General Description Brake Switch Engine Inactive/ Active — — DTC P1588 Gear Engine — — — — Vehicle Speed Engine Km/h 0 0 Transmission Diagnosis Rail Pressure Engine % 17 ∼ 22 18 ∼ 27 DTC P1193 EGR Status Engine Disable/ Enable Enable M/T Enable A/T Disable General Description EGR Switching Engine On/Off — — General Description Throttle Motor Engine Volts 3.1 ∼ 3.9 0.2 ∼ 0.9 DTC P1485, P1486, Throttle Motor Engine Steps 0 ∼ 1.0 0 ∼ 1.0 DTC P1488 Delirered Fuel Engine mm 3/st 6 ∼ 10 6 ∼ 12 General Description Injector Status Engine Disable/ Enable Enable Enable DTC P0201, P0202, Injector Pulse Engine ms 0.9 ∼ 1.25 0.7 ∼ 1.1 General Description Injector Start Engine ° CA — — General Description |
