FRONT SUSPENSION 3C – 19 REMOVAL Preparation: 1) Raise the vehicle and support the frame with suitable 2) Remove wheel and tire assembly. Refer to “Wheels 3) Remove the outer track rod from the knuckle. Refer to 4) Remove the retaining ring from the front axle driving 5) Support lower control arm with a jack. 1. Nut and Washer, Front 2. Nut and Washer, Rear 3. Torsion Bar Refer to “Torsion Bar” in this section. 4. Torsion Bar Arm Bracket 5. Stabilizer Link Disconnect the link at the lower control arm. 6. Shock Absorber Remove the shock absorber lower end from the lower 7. Lower Ball Joint Remove the lower ball joint from the lower control 8. Bolt, Front 9. Bolt, Rear 10. Lower Control Arm 11. Bolt, Torsion Bar Arm 12. Bolt, Lower Ball Joint 13. Bushing, Front Remover: 5-8840-2123-0 (J-36833) |
