FRONT SUSPENSION 3C – 11 REMOVAL Preparation: 1) Raise the vehicle and support the frame with suitable 2) Remove wheel and tire assembly. Refer to “Wheels 3) Remove the brake caliper. Refer to “Brakes” in section 4) Remove the hub assembly. Refer to “Hub and Disk” in 5) Remove outer track rod from the knuckle. Refer to 1. Torsion Bar Loosen torsion bar by height control arm adjust bolt. 2. Wheel speed sensor (if equipped with ABS) 3. Back Plate 4. Lower Ball Joint Remover: 5-8840-2005-0 (J-29107) CAUTION: 5. Upper Ball Joint Remover: 5-8840-2121-0 (J-36831) CAUTION: 6. Knuckle Assembly 7. Oil Seal 8. Washer 9. Needle Bearing Remover: 5-8840-0019-0 (J-23907) |
