GENERAL INFORMATION 0A–5

7. In this manual, the following action symbols

are used to indicate the type of service
operations to be performed.

. . .

Remove or disconnect

. . .

Adjust

. . .

Install or connect

. . .

Clean

. . .

Disassemble

. . .

Pay close attention - Important

. . .

Reassemble

. . .

Tighten to specified torque

. . .

Align the marks

. . .

Use special tool(s)

. . .

Correct direction

. . .

Lubricate with oil

. . .

Inspect

. . .

Lubricate with grease

. . .

Take measurement

. . .

Use liquid gasket

8. The service standard is indicated in terms of

“Standard” and “Limit”.
The “Standard” means the assembly standard
and standard range within which the parts are

considered serviceable.
“Limit” indicates the limit value (Correction or
replacement is necessary when measurement
is beyond this limit.)

VEHICLE IDENTIFICATION NUMBER (VIN)

This is the legal identification of the vehicle.
It appears on the manufacturer’s Plate attached to the left
of the engine compartment front end. VIN number is also
stamped on the rear right side of the frame.

VIN

VIN

ISUZU MOTORS LTD.

JAC

UBS

26

G

Y

7

200001

Sequential Number

Plant Code

Model Year (Y: 2000)

Wheel Base (D: Short, G: Long)

Engine Type (26: 6VE1, 73: 4JX1)

Vehicle Model

World Manufacturer Identifier

ENGINE SERIAL NUMBER

The engine serial number is stamped on the left rear lower
area of the cylinder block above the starter.

4JX1

6VE1

0A–6 GENERAL INFORMATION

IDENTIFICATION

905RW014

905RW016

GENERAL INFORMATION 0A–7

TRANSMISSION SERIAL NUMBER

Manual: Stamped on the left side of the transmission

intermediate plate.

Automatic: Stamped on the identification plate, located on

the left side of the transmission above the
mode switch.

96

0000 000

018

PART No.

SERIAL No.

SAL

HYDRAMATIC

STRASBOURG

MADE  IN FRANCE

G 20

272

FP

SERVICE PARTS IDENTIFICATION PLATE

The Vehicle Information Plate (Service Parts ID plate) is
provided on all vehicle models.
It is located on the center dash wall inside the engine
compartment. The plate lists the VIN (Vehicle Identification
Number), paint information and all production options and
special equipment on the vehicle when it was shipped
from the factory.

Service parts ID plate

ISUZU MOTORS L T D. JAPAN

V.I.N.
M.D.
ENGINE
GRADE

TRANS.
TIRE

BODY TYPE

B. COLOR/TRIM

OPTION

905RW015

905RW018

905RW007

0A–8 GENERAL INFORMATION

LIFTING INSTRUCTIONS

CAUTION:

•

If a lifting device other than the original jack
is used, it is most important that the device
be applied only to the correct lifting points.
Raising the vehicle from any other point
may result in serious damage.

•

When jacking or lifting a vehicle at the
frame side rail or other prescribed lift
points, be certain that lift pads do not
contact the catalytic converter, brake
pipes or cables, or fuel lines. Such contact
may result in damage or unsatisfactory
vehicle performance.

LIFTING POINTS AND SUPPORTABLE POINT LOCATIONS

Long wheel Base Model

Short Wheel Base Model

Lifting point

Supportable point
