Opel Frontera UE. Manual - part 456





8A–10

LIGHTING SYSTEM

High Mounted Stoplight Bulb (2Door Model)

Removal

1. Disconnect the battery ground cable.

2. Remove the cover (2).

3. Remove the bulb (1).

803RX002-1

Installation

To install, follow the removal steps in the reverse order.

Backup Light Bulb

Removal

1. Disconnect the battery ground cable.

2. Remove the rear combination light assembly.

• Refer to the Taillight Bulb removal step 2 in this

section.

3. Remove the bulb holder (2).

• Remove the two wing nuts (1).

825RX054

• Remove the bulb (3) by turning it

counterclockwise while pushing it at the same
time.

825RX056

Installation

To install, follow the removal steps in the reverse order.

LIGHTING SYSTEM

8A–11

Front Turn Signal Light Bulb

Removal

1. Disconnect the battery ground cable.

2. Remove the radiator grille.

• Refer to Engine Hood and Fender in section.

3. Remove the front turn signal light (2).

• Remove three screws.

4. Remove the bulb (1).

• Remove the front turn signal light socket by

turning it counterclockwise.

• Remove the bulb by turning it counterclockwise

while pushing it at the same time.

825RW067

Installation

To install, follow the removal steps in the reverse order.

Side Turn Signal Light Bulb

Removal

1. Disconnect the battery ground cable.

2. Remove the side turnsignal light assembly.

• Pushing in the rear direction of vehicle, pull out it

toward you.

3. Remove the bulb (1) by turning it counterclockwise.

801RW024

Installation

To install, follow the removal steps in the reverse order.

8A–12

LIGHTING SYSTEM

Rear Turn Signal Light Bulb

Removal

1. Disconnect the battery ground cable.

2. Remove the rear combination light assembly.

• Refer to the Taillight Bulb in this section.

3. Remove the bulb holder (2).

• Remove the two wing nuts (2).

825RX054

• Remove the bulb (3) by turning it

counterclockwise while pushing it at the same
time.

825RX057

Installation

To install, follow the removal steps in the reverse order.

Dome Light Bulb

Removal

1. Disconnect the battery ground cable.

2. Remove the lens (2).

3. Remove the bulb (1).

• Pull out the bulb.

825RW075

Installation

To install, follow the removal steps in the reverse order.

LIGHTING SYSTEM

8A–13

Courtesy Light Bulb

Removal

1. Disconnect the battery ground cable.

2. Remove the lens (2).

3. Remove the bulb (1).

• Pull out the bulb.

825RW076

Installation

To install, follow the removal steps in the reverse order.

Map Light Bulb

Removal

1. Disconnect the battery ground cable.

2. Remove the lens (2).

3. Remove the bulb (1).

• Pull out the bulb.

825RW105

Installation

To install, follow the removal steps in the reverse order.
