6A–76 ENGINE MECHANICAL (6VD1 3.2L) 015RS031 D Remove any ridge or carbon build up from the top 9. Remove the piston rings (8) with a piston ring expander. Arrange the removed piston rings in the 015RS022 10. Remove the piston pin (9) using 5–8840–0551–0 piston pin service set and piston support with a press. NOTE: Keep the parts removed from each cylinder 015RX001 Legend (1) Press Ram 11. Piston (10) 12. Connecting rod (11) Inspection and Repair Pistons Carefully clean away all the carbon adhering to the piston NOTE: Never use a wire brush to clean the pistons. Piston Diameter 1. Measure the piston outside diameter with micrometer at the piston grading position and a right angle to the Piston grading position : 43.0 mm (1.6929 in) |
