6J–2 INDUCTION (X22SE 2.2L) Air Cleaner Filter Removal 1. Remove positive ventilation hose connector (1). 2. Remove intake air temperature sensor (2). 3. Remove air cleaner duct assembly (3). 4. Remove air cleaner element (4). 130RX001 Inspection Check the air cleaner filter for damage or dust clogging. Cleaning Method Tap the air cleaner filter gently so as not to damage the 130RW002 Installation 1. Install air cleaner element. 2. Attach the air cleaner duct cover to the body completely, then clamp it with the clip. 3. Install mass air temperature sensor. 4. Install positive crankcase ventilation hose connector. |
