USB (Universal Serial Bus)
Connection Port (if so equipped)

WARNING

Do not connect, disconnect or operate the
USB device while driving. Doing so can be
a distraction. If distracted you could lose
control of your vehicle and cause an acci-
dent or serious injury.

CAUTION

● Do not force the USB device into the

USB port. Inserting the USB device
tilted or up-side-down into the port may
damage the port. Make sure that the
USB device is connected correctly into
the USB port.

● Do not grab the USB port cover (if so

equipped) when pulling the USB device
out of the port. This could damage the
port and the cover.

● Do not leave the USB cable in a place

where it can be pulled unintentionally.
Pulling the cable may damage the port.

The vehicle is not equipped with a USB device.
USB devices should be purchased separately as
necessary.

This system cannot be used to format USB de-
vices. To format a USB device, use a personal
computer.

In some jurisdictions, the USB device for the front
seats plays only sound without images for regu-
latory reasons, even when the vehicle is parked.

This system supports various USB connection
port devices, USB hard drives and iPod® play-
ers. Some USB devices may not be supported by
this system.

● Partitioned USB devices may not play cor-

rectly.

● Some characters used in other languages

(Chinese, Japanese, etc.) may not appear
properly in the display. Using English lan-
guage characters with a USB device is rec-
ommended.

General notes for USB (if so equipped) use:

● Refer to your device manufacturer’s owner

information regarding the proper use and
care of the device.

Notes for iPod® (if so equipped) use:

iPod® is a trademark of Apple Inc., registered in
the U.S. and other countries.

● Improperly plugging in the iPod® may cause

a checkmark to be displayed on and off
(flickering). Always make sure that the
iPod® is connected properly.

● An iPod® nano (1st Generation) may remain

in fast forward or rewind mode if it is con-
nected during a seek operation. In this case,
please manually reset the iPod®.

● An iPod® nano (2nd Generation) will con-

tinue to fast-forward or rewind if it is discon-
nected during a seek operation.

● An incorrect song title may appear when the

Play Mode is changed while using an iPod®
nano (2nd Generation).

● Audiobooks may not play in the same order

as they appear on an iPod®.

● Large video files cause slow responses in an

iPod®. The vehicle center display may mo-
mentarily black out, but will soon recover.

● If an iPod® automatically selects large video

files while in the shuffle mode, the vehicle
center display may momentarily black out,
but will soon recover.

Monitor, climate, audio, phone and voice recognition systems

4-29

CD eject button

CD insert slot

SCAN button

DISP button

RPT/RDM button

TUNE/FOLDER knob / MENU button

AUX IN jack

AUX button

CD button

10. AM button
11. FM button

12. VOL (volume) control knob

(power) button

13. Station select (1 - 6) buttons
14. TRACK

button

15.

SEEK button

FM/AM RADIO WITH COMPACT
DISC (CD) PLAYER (Type A) (if so
equipped)

For all operation precautions, see “Audio opera-
tion precautions” in this section.

Audio main operation

VOL (volume) control knob/

(power) button

Place the ignition switch in the ACC or ON
position, then press the VOL (volume) control
knob/

(power) button. If you listen to the

radio with the engine not running, place the igni-
tion in the ACC position. The mode (radio or CD)
that was playing immediately before the system
was turned off resumes playing.

When no CD is loaded, the radio comes on.
Pressing

the

VOL

(volume)

control

knob/

(power) button again turns the sys-

tem off.

LHA8804

4-30

Monitor, climate, audio, phone and voice recognition systems

Turn

the

VOL

(volume)

control

knob

(power) button to the right to increase

volume or to the left to decrease volume.

MENU button (Bass, Treble, Balance,
Fade, Speed Sensitive Volume and Clock):

Press the MENU button to change the mode as
follows:

Bass

→ Treble → Balance → Fade → Spd. Sen.

Vol. (Speed Sensitive Volume)

→ AUX IN Volume

→ Clock → Clock Adjust

To adjust the Bass, Treble, Fade and Balance,
press the MENU button until the desired mode
appears in the display. Press the

SEEK or

TRACK

button to adjust the setting to the

desired level (-5 to +5). Balance adjusts the
sound between the right and left speakers. Fade
adjusts the sound between the front and rear
speakers.

Once you have adjusted the sound quality to the
desired level, press the MENU button repeatedly
until the radio or CD display reappears. Other-
wise, the radio or CD display will automatically
reappear after about 10 seconds.

Speed Sensitive Volume (SSV) adjusts the vol-
ume of the audio system as the vehicle’s driving
speed changes. It can be set as follows:

OFF

→ LOW → MID → HIGH

DISP (display) button:

Press the DISP (display) button while a CD is
playing to change the text shown in the audio
display as follows:

For CDs:

Running Time

→ Album Title: → Artist Name: →

Song Title

For MP3 CDs:

Running Time

→ Folder Title: → Album Title: →

Artist Name:

→ Song Title:

If the text information is too long to fully be dis-
played on the screen; press and hold the DISP
button for longer than 1.5 seconds to scroll
through the rest of the text.

Press the DISP (display) button while the radio is
playing to toggle the audio display between sta-
tion number and RDS.

Clock operation

To turn the clock display on or off, press the
MENU button repeatedly until “Clock” appears
on the display. Turn the TUNE/FOLDER knob to
toggle the setting (ON or OFF).

Clock set

1. Press the MENU button repeatedly until

“Adjust Clock” appears on the display.

2. Press the MENU button.

3. “Change Hour” will appear on the screen.

Turn the TUNE/FOLDER knob to adjust the
hours and then press MENU.

4. “Change Minute” will appear on the screen.

Turn the TUNE/FOLDER knob to adjust the
minutes and then press MENU.

The display will return to the regular clock display
after 10 seconds if no further adjustment is per-
formed.

FM/AM radio operation

AM and FM buttons:

Press the AM button to change the band to AM.

If another audio source is playing when the AM
button is pressed, the audio source playing will
automatically be turned off and the last radio
station played will begin playing.

Press the FM button to change the band as
follows:

FM1

→ FM2 → FM1

If another audio source is playing when the FM
button is pressed, the audio source playing will
automatically be turned off and the last radio
station played will begin playing.

Monitor, climate, audio, phone and voice recognition systems

4-31

The FM stereo indicator (ST) illuminates during
FM stereo reception. When the stereo broadcast
signal is weak, the radio automatically changes
from stereo to monaural reception.

SEEK and TRACK (tuning)

buttons:

Press the SEEK button

to tune from low to

high frequencies and stop at the next broadcast-
ing station.

Press the TRACK button

to tune from high

to low frequencies and stop at the next broad-
casting station.

Press and hold either button to seek at a faster
speed.

SCAN (tuning) button:

Press the SCAN button. SCAN illuminates in the
display window. Scan tuning begins from low to
high frequencies. Scan tuning stops for 5 sec-
onds at each broadcasting station that has suffi-
cient signal strength. When scanning, SCAN
blinks in the display. Pressing the SCAN button
again during this 5 second period stops scan
tuning and the radio remains tuned to that station.

1 to 6 Station memory operations:

Twelve stations can be set for the FM band (6 for
FM1, 6 for FM2) and six stations can be set for
the AM band.

1. Choose the radio band AM, FM1 or FM2

using the AM or FM button.

2. Tune to the desired station using manual,

SEEK or SCAN tuning. Press and hold any
of the desired station memory buttons (1 –
6) until a beep sound is heard.

3. The channel indicator will then come on and

the sound will resume. Programming is now
complete.

4. Other buttons can be set in the same man-

ner.

If the battery cable is disconnected or if the fuse
opens, the radio memory will be canceled. In that
case, reset the desired stations.

Compact disc (CD) player operation

Place the ignition switch in the ACC or ON
position, and carefully insert the compact disc
into the slot with the label side up. The compact
disc is automatically pulled into the slot and starts
to play.

If the radio is already operating, it automatically
turns off and the compact disc begins to play.

CD button:

When the CD button is pressed with a compact
disc loaded and the radio playing, the radio turns
off and the last used compact disc starts to play.

SEEK and TRACK

(Fast Forward, Rewind)

buttons:

When the SEEK button

or TRACK

button is pressed while the compact disc is play-
ing, the compact disc plays at an increased
speed while fast forwarding or rewinding. When
the button is released, the compact disc returns
to normal play speed.

SEEK and TRACK buttons:

When the SEEK

button is pressed while

the compact disc is playing, the next track follow-
ing the present one starts to play from the begin-
ning. Press the SEEK

button several times

to skip several tracks. Each time the button is
pressed, the CD advances one additional track.
The track number appears in the display window.
(When the last track on the compact disc is
skipped, the first track is played.)

4-32

Monitor, climate, audio, phone and voice recognition systems

When the TRACK

button is pressed, the

track being played returns to the beginning.
Press the TRACK

button several times to

skip back several tracks. Each time the button is
pressed the CD moves back one track.

RPT/RDM button:

Press the RPT/RDM button while a compact disc
is playing to change the play pattern as follows:

CD:

TRACK REPEAT

→ DISC RANDOM → DISC

REPEAT

MP3/WMA CD:

FOLDER REPEAT

→ TRACK REPEAT → DISC

RANDOM

→ FOLDER RANDOM → DISC RE-

PEAT

TRACK REPEAT: The track that is currently play-
ing will be repeated.

DISC RANDOM: The order of the tracks on the
disc will be mixed during play.

DISC REPEAT: The disc currently playing will be
repeated.

FOLDER REPEAT: The tracks in the current
folder will be repeated.

FOLDER RANDOM: The order of the tracks in
the folder will be mixed during play.

SCAN (CDs) button:

Press the SCAN button for less than 1.5 seconds
to scan all tracks of the current disc for 10 sec-
onds per track. The SCAN icon is flashed during
scan mode.

The scan mode is canceled once it scans through
all tracks on the disc, or if the SCAN button is
pressed during scan mode.

CD EJECT:

When the

button is pressed with a com-

pact disc loaded, the compact disc will be
ejected.

When the

button is pressed while the

compact disc is playing, the compact disc will
eject and the system will turn off.

AUX (Auxiliary) button:

The AUX IN jack is located on the CD player. The
AUX IN audio input jack accepts any standard
analog audio input such as from a portable cas-
sette tape/CD player, MP3 player or laptop com-
puters.

Press the AUX button to play a compatible device
when it is plugged into the AUX IN jack.

Press the MENU button repeatedly until “AUX IN
Volume” appears on the screen to control the
incoming volume level of the auxiliary input de-
vice. Turn the TUNE/FOLDER knob to adjust the
level between 0 and +3.

Additional features

For more information about the Bluetooth® audio
interface

available

with

this

system,

see

“Bluetooth® streaming audio without Navigation
System” in this section.

Monitor, climate, audio, phone and voice recognition systems

4-33

CD eject button

RPT button

RDM button

Display screen

SCAN button

USB button

AUX button

A-Z button

ENTER button and TUNE/MENU con-
trol knob

10.

(back) button

11. SETUP button

12. DISP button
13. Station select (1–6) buttons
14.

Forward and Backward

SEEK/TRACK buttons

15. VOL (volume control knob)/

(power) button

16. CD button
17. FM•AM button

FM/AM RADIO WITH COMPACT
DISC (CD) PLAYER (Type B) (if so
equipped)

For all operation precautions, see

⬙Audio opera-

tion precautions

⬙ in this section.

Audio main operation

VOL (volume) control knob /

(power) button

Place the ignition switch in the ACC or ON
position, then press the VOL (volume) control
knob /

(power) button. If you listen to the

radio with the engine not running, place the igni-
tion in the ACC position. The mode (radio or CD)
that was playing immediately before the system
was turned off resumes playing.

When no CD is loaded, the radio comes on.
Pressing the VOL (volume) control knob /
(power) button again turns the system off.

LHA3016

4-34

Monitor, climate, audio, phone and voice recognition systems

Turn the VOL (volume) control knob /
(power) button to the right to increase volume or
to the left to decrease volume.

AUX button:

The AUX IN audio input jack accepts any stan-
dard analog audio input such as from a portable
cassette tape/CD player, MP3 player or a laptop
computer. Press the AUX button to play a com-
patible device plugged into the AUX IN jack.
Pressing the AUX button repeatedly will cycle
through available input sources:

AUX line in

→ USB (if so equipped) → BT AUDIO

Streaming

→ AUX line in

NOTE:

Sources only shown in menu if they are
connected and/or detected.

DISP (display) button

Pressing the DISP button displays song informa-
tion, if available, such as artist, album, track name,
folder name, and source.

NOTE:

The DISP button only provides this infor-
mation in non-radio modes.

How to use the SETUP button

To select and/or adjust several functions, features
and modes that are available for your vehicle:

1. Press the SETUP button.

2. Turn the TUNE/MENU control knob until the

desired item is selected on the menu list and
then press the ENTER button.

Menu item

Result

Audio

Selecting this item allows user to adjust various audio settings.

Bass

Adjusts the bass to the desired level.

Treble

Adjusts the treble to the desired level.

Balance

Adjusts the balance to the desired level. Balance adjusts the sound level between the left and right speakers.

Fade

Adjusts the fade to the desired level. Fade adjusts the sound level between the front and rear speakers.

AUX Vol.

Controls the volume level of incoming sound when an auxiliary device is connected tot the system. Available options are LOW, MID, and HIGH.

Clock

Selecting this item allows user to adjust various clock settings.

Set Time

Allows user to set time manually.

ON/OFF

Switches clock display on or off.

Format 12h:24h

Allows user to change time format between 12 hour and 24 hour.

Bluetooth

See “Bluetooth® Hands-Free Phone System without Navigation System” in this section for more information.

Language

Allows user to change system language.

List of Languages

Available language are Spanish, Portuguese, English, and French.

Scroll Direction

Allows user to change the scrolling direction used by the TUNE/MENU control knob.

Clockwise

Select up or down and press ENTER button.

Monitor, climate, audio, phone and voice recognition systems

4-35

TUNE/MENU control knob/Enter button:

Turn the TUNE/MENU control knob to the left or
right to scroll and then press ENTER to select
desired item.

A–Z button:

When listening to music via USB or iPod®,
pressing the A-Z button will launch a quick
search function in music browser that will allow
user to search for music alphabetically using the
TUNE/MENU control knob.

RDM and RPT button:

When listening to music via USB or iPod®,
pressing the RDM button will shuffle the songs
being played. Pressing the RPT button will repeat
the song being played.

(back) button:

Pressing the

(back) button will return the

user to the previous menu.

FM/AM radio operation

FM-AM button:

Press the FM·AM button to change the band as
follows:

→ FM1 → FM2 → AM

If another audio source is playing when the
FM·AM button is pressed, the audio source play-
ing will automatically be turned off and the last
radio station played will begin playing.

If the FM-AM button is pressed for more than
1.5 seconds, the AUTOSTORE function will be
initiated. The “AST” icon will appear and “AU-
TOSTORE” may appear on the display screen, a
beep is heard and the radio mutes. The system
will then automatically detect the 6 stations with
the strongest frequency and save them as pre-
sets. Once AUTOSTORE is complete, the “AST”
icon will disappear and “AUTOSTORE COM-
PLETE” may appear on the display screen.

TUNE/MENU control knob (Tuning):

Turn the TUNE/MENU control knob to the left or
right for manual tuning.

SEEK tuning:

Press the SEEK/TRACK button

to tune from low to high or high to low frequen-
cies and to stop at the next broadcasting station.
Hold either button to tune continuously. Then
release button once desired frequency is
reached.

Station select (1 to 6) memory operations:

Twelve stations can be set for the FM band (6 for
FM1, 6 for FM2) and six stations can be set for
the AM band.

1. Choose the radio band AM, FM1 or FM2

using the AM or FM button.

2. Tune to the desired station using manual or

SEEK tuning. Press and hold any of the
desired station memory buttons (1 – 6) until
a beep sound is heard.

3. The station memory position (P1–P6) will

now be displayed next to the band. Pro-
gramming is now complete.

4. Other buttons can be set in the same man-

ner.

If the battery cable is disconnected or if the fuse
opens, the radio memory will be canceled. In that
case, reset the desired stations.

Compact disc (CD) player operation

If the radio is already operating, it automatically
turns off and the compact disc begins to play.

CD button:

When the CD button is pressed with the system
off and the compact disc loaded, the system will
turn on and the compact disc will start to play.

4-36

Monitor, climate, audio, phone and voice recognition systems

When the CD button is pressed with a compact
disc loaded and the radio playing, the radio will
automatically be turned off and the compact disc
will start to play.

DISP button:

When the DISP button is pressed while a CD is
playing, the display will change as follows:

CD:

Track Time

→ Album → Artist →Track Time

CD with MP3 or WMA:

Track time

→ Folder title → Artist → Song title →

Track number

SEEK/TRACK (Reverse or

Fast Forward) button:

Press and hold the SEEK/TRACK button
or

for 1.5 seconds while the compact disc

is playing to reverse or fast forward the track
being played. The compact disc plays at an in-
creased speed while reversing or fast forwarding.
When the button is released, the compact disc
returns to normal play speed.

SEEK/TRACK button:

Press the SEEK/TRACK button

while a

CD or MP3/WMA CD is playing to return to the
beginning of the current track. Press the
SEEK/TRACK button

several times to skip

backward several tracks.

Press the SEEK/TRACK button

while a

CD or MP3/WMA CD is playing to advance one
track. Press the SEEK/TRACK button

sev-

eral times to skip forward several tracks. If the last
track on a CD is skipped, the first track on the
disc is played. If the last track in a folder of an
MP3/WMA CD is skipped, the first track of the
next folder is played.

button (MP3/WMA CD only):

If an MP3/WMA CD with multiple folders is play-
ing, press the

button once to view the

track list and again to view the folder list. To select
a folder or track, turn the TUNE/MENU knob to
scroll through the folders/songs and press the
ENTER button to make a selection.

RPT button:

When the RPT button (Preset station number 1)
is pressed while a compact disc is playing, the
Repeat mode is toggled.

RDM button:

When the RDM button (Preset station number 2)
is pressed while a compact disc is playing, the
Random mode is toggled.

EJECT button:

When the

button is pressed with a com-

pact disc loaded, the compact disc will eject and
the last source will be played.

Monitor, climate, audio, phone and voice recognition systems

4-37

CD eject button

2. RPT button
3. RDM button
4. Display screen
5. SCAN button

SEEK/CAT buttons

7. APPS button
8.

BACK button

9. ENTER/SETTING button and TUNE/

SCROLL control knob

10. Station select (1–6) buttons
11. VOL (volume) knob /

(power) button

12. DISP button
13. MEDIA button
14. XM button*
15. FM•AM button

*No satellite radio reception is available
when the XM button is pressed to access
satellite radio stations unless optional
satellite receiver and antenna are installed
and an SiriusXM® Satellite Radio service
subscription is active. Satellite radio is
not available in Alaska, Hawaii or Guam.

FM/AM/SAT RADIO WITH
COMPACT DISC (CD) PLAYER (Type
A) (if so equipped)

For all operation precautions, see “Audio opera-
tion precautions” in this section.

Audio main operation

VOL (volume) /

(power) button:

Place the ignition switch in the ACC or ON
position and press the

(power) button

while the system is off to call up the mode (radio,
CD, AUX, Bluetooth® audio USB or iPod®) that
was playing immediately before the system was
turned off.

Type A

LHA3017

4-38

Monitor, climate, audio, phone and voice recognition systems

To turn the system off, press the

(power)

button.

Turn the VOL (volume) control knob to adjust the
volume.

This vehicle may be equipped with Speed Sen-
sitive Volume. When this feature is active, the
audio volume changes as the driving speed
changes.

ENTER/SETTING button:

Press the ENTER/SETTING button to show the
Settings screen on the display. Turn the
TUNE/SCROLL knob to navigate the options
and then press the ENTER/SETTING button to
make a selection.

Audio

Bass

Adjusts the bass to the desired level.

Treble

Adjusts the treble to the desired level.

Balance

Adjusts the balance to the desired level. Balance adjusts the sound level between the left and right speakers.

Fade

Adjusts the fade to the desired level. Fade adjusts the sound level between the front and rear speakers.

Speed Sens Vol. (Speed Sensitive Volume)

Adjusts the speed sensitive volume function, which increases the volume of the audio system as the speed of
the vehicle increases. Set to “OFF” to disable the feature. The higher the setting, the more the volume in-
creases in relation to vehicle speed.

AUX Vol.

Choose a setting from 0 to +3 to control the boost of incoming auxiliary device volume. A setting of 0 provides
no additional boost in volume. A setting of +3 provides the greatest boost in volume.

Brightness and Contrast

Adjust the brightness or contrast to adjust the appearance of the display screen.

Clock adjust

Press the ENTER/SETTING button to highlight the hours or minutes and then use the TUNE/SCROLL knob to
adjust the value. Press the ENTER/SETTING button again to set the value.

On-Screen Clock

Toggles ON or OFF the clock display on the upper right corner of the display screen.

RDS Display

Toggles ON or OFF the RDS information displayed on the screen while the radio is playing.

Language

Select the desired language for the system from the available options.

Bass, treble, balance and fade can also be adjusted by pressing the ENTER/SETTING button and turning the TUNE/SCROLL control knob to select the item
to adjust. When the desired item is shown on the display, turn the tuning to adjust and then press the ENTER/SETTING button until the display returns to
the main audio screen. If the button is not pressed for approximately 10 seconds, the radio or CD display will automatically reappear.

Monitor, climate, audio, phone and voice recognition systems

4-39

APPS button:

Press the APPS button to launch the Smart-
phone Integration Mode. See “NissanConnect™
APP Smartphone Integration” in this section for
more information about using this feature.

For more information on connecting your phone,
see the “Bluetooth® Hands-Free Phone system
without Navigation” section.

FM/AM/SAT radio operation

FM·AM button:

Press the FM·AM button to change the band as
follows:

→ FM1 → FM2 → AM

If another audio source is playing when the
FM·AM button is pressed, the audio source play-
ing will automatically be turned off and the last
radio station played will begin playing.

The FM stereo indicator (STEREO) is shown on
the screen during FM stereo reception. When the
stereo broadcast signal is weak, the radio auto-
matically changes from stereo to monaural re-
ception.

XM band select:

Pressing the XM button will change the band as
follows:

XM1*

→ XM2* → XM3* → XM1* (satellite, if so

equipped)

When the XM button is pressed while the ignition
switch is in the ACC or ON position, the radio will
come on at the last station played.

The last station played will also come on when
the VOL/

control knob is pressed to turn

the radio on.

*When the XM button is pressed, the satellite
radio mode will be skipped unless an optional
satellite receiver and antenna are installed and a
SiriusXM® Satellite Radio service subscription is
active. Satellite radio is not available in Alaska,
Hawaii and Guam.

If a compact disc is playing when the XM button
is pressed, the compact disc will automatically be
turned off and the last radio station played will
come on.

While the radio is in XM mode, the operation can
be controlled through the touch-screen. Touch
the “Channels” key to display a list of channels.
Touch a channel displayed on the list to change
to that channel. Touch the “Categories” key to
display a list of categories. Touch a category
displayed on the list to display options within that
category.

TUNE/SCROLL knob (Tuning):

Turn the TUNE/SCROLL knob to the left or right
for manual tuning.

LHA1492

4-40

Monitor, climate, audio, phone and voice recognition systems

SEEK tuning:

Press the SEEK button

to tune

from low to high or high to low frequencies and to
stop at the next broadcasting station.

SCAN tuning:

Press the SCAN button to stop at each broad-
casting station for 5 seconds. SCAN will appear
on the screen while the radio is scan tuning.

Pressing the button again during this 5 second
period will stop SCAN tuning and the radio will
remain tuned to that station. If the SCAN button is
not pressed within 5 seconds, SCAN tuning
moves to the next station.

1 to 6 Station memory operations:

Six stations can be set for the AM band. Twelve
stations can be set for the FM band (6 for FM1, 6
for FM2). Eighteen channels can be set for the
satellite radio (6 for XM1, 6 for XM2, 6 for XM3).

1. Choose the radio band AM, FM1 or FM2

using the FM·AM select button, or choose
the satellite band XM1, XM2 or XM3 using
the XM button.

2. Tune to the desired station using manual,

SEEK or SCAN tuning. Press and hold any
of the desired station memory buttons (1 –

6) until the preset number is updated on the
display and the sound is briefly muted.

3. The channel indicator will then come on and

the sound will resume. Programming is now
complete.

4. Other buttons can be set in the same man-

ner.

If the battery cable is disconnected, or if the fuse
opens, the radio memory will be canceled. In that
case, reset the desired stations.

Compact disc (CD) player operation

If the radio is already operating, it automatically
turns off and the compact disc begins to play.

MEDIA button:

With a CD loaded, press the MEDIA button until
the CD mode is displayed on the screen.

CD/MP3 display mode:

While listening to an MP3/WMA CD, certain text
may be displayed on the screen if the CD has
been encoded with text information. Depending
on how the MP3/WMA CD is encoded, informa-
tion such as Artist, Song and Folder will be dis-
played.

The track number and the total number of tracks
in the current folder or on the current disc are
displayed on the screen as well.

SEEK/CAT (Reverse or

Fast Forward) button:

Press and hold the SEEK/CAT button
or

for 1.5 seconds while the compact disc

SEEK/CAT button:

Press the SEEK/CAT button

while a CD or

MP3/WMA CD is playing to return to the begin-
ning of the current track. Press the SEEK/CAT
button

several times to skip backward sev-

eral tracks.

Press the SEEK/CAT button

while a CD or

MP3/WMA CD is playing to advance one track.
Press the SEEK/CAT button

several times

to skip forward several tracks. If the last track on
a CD is skipped, the first track on the disc is
played. If the last track in a folder of an
MP3/WMA CD is skipped, the first track of the
next folder is played.

Monitor, climate, audio, phone and voice recognition systems

4-41

TUNE/SCROLL knob (MP3/WMA CD
only):

If a MP3/WMA CD with multiple folders is play-
ing, turn the TUNE/SCROLL knob to change
folders. Turn the knob to the left to skip back a
folder. Turn the knob to the right to skip ahead a
folder.

RPT button:

When the RPT button is pressed while a com-
pact disc is playing, the play pattern can be
changed as follows:

CD:

1 Track Repeat

←→ OFF

CD with MP3 or WMA:

1 Folder Repeat

→ 1 Track Repeat → OFF

1 Track Repeat: the current track will be re-
peated.

1 Folder Repeat: the current folder will be re-
peated.

OFF: No repeat play pattern is applied. The indi-
cator on the display will turn off.

The current play pattern of the CD is displayed on
the screen unless no pattern is applied.

RDM button:

When the RDM button is pressed while a com-
pact disc is playing, the play pattern can be
changed as follows:

CD:

1 Disc Random

←→ OFF

CD with MP3 or WMA:

1 Disc Random

→ 1 Folder Random → OFF

1 Disc Random: all tracks on the disc will be
played randomly.

1 Folder Random: all tracks in the current folder
will be played randomly.

OFF: No random play pattern is applied. The
indicator on the display will turn off.

The current play pattern of the CD is displayed on
the screen unless no pattern is applied.

EJECT button:

When the

button is pressed with a com-

pact disc loaded, the compact disc will eject and
the last source will be played.

When the

button is pressed twice with a

compact disc loaded, the compact disc will be

ejected further for easier CD removal. If the disc
is not removed within 20 seconds, the disc will
reload.

Additional features

For more information about the iPod® player
available with this system, see “iPod® player
operation without Navigation System” in this sec-
tion.

For more information about the USB interface
available with this system, see “USB interface
(models without Navigation System)” in this sec-
tion.

For more information about the Bluetooth® audio
interface

available

with

this

system,

see

“Bluetooth® streaming audio without Navigation
System” in this section.

4-42

Monitor, climate, audio, phone and voice recognition systems

CD eject button

2. FM-AM button
3. AUX button
4. CD insert slot

Backward seek button and

Forward seek button

6. BACK button
7. TUNE knob / AUDIO button
8. Display screen

9. ON-OFF button / VOL (volume) control

knob

10. CD button
11. SXM button*

*No satellite radio reception is available
when the SXM button is pressed to ac-
cess satellite radio stations unless op-
tional satellite receiver and antenna are
installed and a SiriusXM® Satellite Radio
service subscription is active. Satellite
radio is not available in Alaska, Hawaii
and Guam.

FM/AM/SAT RADIO WITH
COMPACT DISC (CD) PLAYER (Type
B) (if so equipped)

For all operation precautions, see “Audio opera-
tion precautions” in this section.

Audio main operation

ON-OFF button / VOL (volume) control knob:

Place the ignition switch in the ACC or ON
position and press the ON-OFF button while the
system is off to call up the mode (radio, CD, AUX,
Bluetooth® audio USB or iPod®) that was play-
ing immediately before the system was turned off.

LHA2895

Monitor, climate, audio, phone and voice recognition systems

4-43

To turn the system off, press the ON-OFF button.

Turn the VOL (volume) control knob to adjust the
volume.

This vehicle may be equipped with Speed Sen-
sitive Volume. When this feature is active, the
audio volume changes as the driving speed
changes.

Audio settings:

1. Press the [

] button.

2. Touch the “Settings” key.

3. Touch the “Audio” key.

Use the touch-screen to adjust the following
items to the desired setting:

Audio

Bass

Adjusts the bass to the desired level.

Treble

Adjusts the treble to the desired level.

Balance

Adjusts the balance to the desired level. Balance adjusts the sound level between the left and right speakers.

Fade

Adjusts the fade to the desired level. Fade adjusts the sound level between the front and rear speakers.

Speed Sensitive Vol.

Adjusts the speed sensitive volume function, which increases the volume of the audio system as the speed of the ve-
hicle increases. Set to “OFF” to disable the feature. The higher the setting, the more the volume increases in relation to
vehicle speed.

AUX Volume Level

Controls the volume level of incoming sound when an auxiliary device is connected to the system. Available options are
Low (Quiet), Medium, and High (Loud).

Bass, treble, balance and fade can also be adjusted by pressing the AUDIO control knob and turning it to select the item to adjust. When the desired item
is shown on the display, turn the tuning to adjust and then press the AUDIO button until the display returns to the main audio screen. If the button is not
pressed for approximately 10 seconds, the radio or CD display will automatically reappear.

4-44

Monitor, climate, audio, phone and voice recognition systems

Nissan Versa Sedan (2015 year). Instruction - part 11
