4-118

Monitor, heater, air conditioner, audio, phone and voice recognition systems

SKIP (FORWARD):

Select the “

” key to skip the chapter(s) of

the disc forward. The chapters will advance the
number of times the ENTER button is pushed.

To skip the chapter(s) forward, it is also possible
to push the “

” button on the keypad of the

remote controller.

SKIP (REWIND):

Select the “

” key to skip the chapter(s) of

the disc backward. The chapters will go back
the number of times the ENTER button is
pushed.

To skip the chapter(s) backward, it is also
possible to push the “

” button on the

keypad of the remote controller.

Commercial Skip (if so

equipped):

This function is only for DVD-VIDEO and DVD-
VR.

Select the “

” or “

” key to skip forward or

backwards by the set amount as defined in the
DVD settings menu.

To skip forward or backward, it is also possible
to push the “

” or “

” button on the

keypad of the remote controller.

SAA2498

Front screen (models with navigation system)

SAA3656

Rear screen (models with navigation system)

SAA3087

Front screen (models without navigation system)

SAA3657

Rear screen (models without navigation system)

Setting keys

Select the “Settings” key with the multi-function
controller and push the ENTER button to adjust
the following settings.

The items indicated with “ * ” can also be set
from the rear display. Push the “ DVD” button on
the remote controller while a DVD is being
played. Select the preferred item using the
joystick “

” on the remote controller and

push the ENTER “

” button.

Key (DVD-VIDEO) (models with navigation
system):

Keys for the DVD menu operation are displayed.

: Move the cursor to select a DVD menu.

Enter: Enter the selected menu.

Move: Change the display location by moving
the operation key.

Back: Return to the previous screen.

Hide: Hide the operation key.

Title Menu (front)/Menu (rear) (DVD-VI-
DEO):

Menus specific to each disc will be shown. For
details, see the instructions attached to the disc.

Title Search (DVD-VIDEO):

A scene that belongs to a specified title will be
displayed each time the “+” side or “

í” side is

selected.

10 Key Search (DVD-VIDEO, VIDEO-CD,
CD-DA):

Select the “10 Key Search” key and push the
ENTER button to open the number entry screen.

Input the number you want to search for and
select the “OK” key with the multi-function
controller. Then push the ENTER button. The
specified Title/Chapter or Group/Track will be
played.

Angle (DVD-VIDEO):

If the DVD contains different angles (such as
moving images), the current image angle can be
switched to another one.

Select the “Angle” key and push the ENTER
button. When the “+” side or “

í” side is

selected, the angle will change.

Angle Mark (DVD-VIDEO):

When this item is turned on, an angle mark will
be shown on the bottom of the screen if the
scene can be seen from a different angle.

Menu Skip (DVD-VIDEO):

DVD menus are automatically configured and
the contents will be played directly when the
“Menu Skip” key is turned on. Note that some
discs may not be played directly even if this item
is turned on.

CM Skip (DVD-VIDEO) (models with navi-
gation system):

The number of seconds for CM Skip can be set
to 15, 30 or 60 seconds.

DRC (DVD-VIDEO):

DRC (Dynamic Range Compression) allows
tuning of the dynamic range of sound recorded
in the Dolby Digital format.

DVD Language (DVD-VIDEO, VIDEO-CD):

Select the “DVD Language” key and push the
ENTER button to open the number entry screen.

Input the number corresponding to the preferred
language and select the “OK” key with the multi-
function controller. Then push the ENTER
button. The DVD top menu language will be
changed to the one selected.

Display:

Adjust the image quality of the screen, select the
preferred adjustment items and push the ENTER
button.

Audio:

Choose the preferred language using the multi-
function controller and push the ENTER button.

Subtitle (DVD-VIDEO):

Choose the preferred language using the multi-
function controller and push the ENTER button.

Monitor, heater, air conditioner, audio, phone and voice recognition systems

4-119

4-120

Monitor, heater, air conditioner, audio, phone and voice recognition systems

To turn off the subtitles, push and hold the
ENTER button until a beep sounds.

Display Mode (DVD-VIDEO, VIDEO-CD):

Choose from the “Full”, “Wide”, “Normal” or
“Cinema” mode using the multi-function con-
troller and push the ENTER button again.

Play Mode:

Choose the preferred play mode using the multi-
function controller and push the ENTER button.

Remote controller operation

Use the remote controller to adjust the following
items.

Rear display open/close:

To open or close the flip-down rear display, push
the “

” button.

Joystick:

Use the joystick “

” to select the items

displayed on the rear screen.

ENTER button:

Push the ENTER “

” button to make the

selected item complete on the rear screen.

BACK button:

Push to go back to the previous screen or
cancel the selection.

Display tilt:

Adjust the display angle by pushing the DIS-
PLAY TILT button “

”.

DVD mode:

To select the DVD mode, push the DVD button.

USB mode (if so equipped):

To select the USB mode, push the USB button.

AUX mode:

To select the AUX (auxiliary input jacks), mode,
push the AUX button.

Volume:

To control the speaker volume level, push the
VOL button “

”.

Display:

To adjust the rear display screen (aspect, color
system, 3D Y/C filter and picture mode etc.),
push the DISP button.

Sound:

To change the language, push the SOUND
button. Each time the button is pushed, the
language will change to each language stored in
the DVD.

Track/Channel:

To skip to the previous or next DVD scene
selection, push the TRACK CH button “

”.

Keypad:

: PLAY/PAUSE button

: STOP button

: FORWARD button

: REWIND button

: FORWARD button for commercial skip (for

DVD-VIDEO and DVD-VR)

: REWIND button for commercial skip (for

DVD-VIDEO and DVD-VR)

Rear display settings

To adjust rear display setting, select the
preferred key and push the ENTER

button.

The following settings are available:

Aspect:

Select the display size from “CINEMA”, “WIDE”,
“FULL” or “NORMAL” using the joystick on the
remote controller.

Picture Mode:

To adjust the display brightness automatically,
select the “Brightness” key and then select from
“DARKER”, “NORMAL” or “BRIGHTER”. When
adjusting manually, select “OFF” and adjust
using the joystick on the remote controller and
tilt the joystick to the right or left.

To adjust tint, color, contrast or black level,
select a key using the joystick on the remote

controller and tilt the joystick to the right or left.

Push the BACK button on the remote controller
to apply the settings and return to the previous
display.

To return the adjustment levels to the default
value, select “Execute” next to “Initialization”
using the joystick on the remote controller and
push the ENTER

button. The “Execute” key

is deactivated when the picture mode settings
are already in the default value.

Color System:

To choose the color system, select from
“NTSC”, “PAL”, “PAL-60”, “PAL-M”, “PAL-N” or
“AUTO” using the joystick on the remote
controller and tilt the joystick to the right or left.

3D Y/C filter:

Set to ON/OFF using the joystick on the remote
controller. When turned on, small characters
and an outline of the shapes will be displayed
more clearly than when turned off.

CARE AND MAINTENANCE

Use a lightly dampened, lint free cloth to clean
the surfaces of your Mobile Entertainment
System (DVD player face, screen, remote
controller, etc.).

CAUTION

. Do not use any solvents or cleaning

solutions when cleaning the video
system.

. Do not use excessive force on the

monitor screen.

. Avoid touching or scratching the

monitor screen as it may become
dirty or damaged.

. Do not attempt to operate the

system in extreme temperature con-
ditions [below

í4

8F (í208C) and

above 158

8F (708C)].

. Do not attempt to operate the

system in extreme humidity condi-
tions (less than 10% or more than
75%).

When installing a car phone or a CB radio in
your vehicle, be sure to observe the following
cautions, otherwise the new equipment may
adversely affect the electronic control modules
and electronic control system harness.

WARNING

. A cellular phone should not be used

for any purpose while driving so full
attention may be given to vehicle
operation. Some jurisdictions prohi-
bit the use of cellular phones while
driving.

. If you must make a call while your

vehicle is in motion, the hands-free
cellular phone operational mode (if
so equipped) is highly recom-
mended. Exercise extreme caution
at all times so full attention may be
given to vehicle operation.

. If you are unable to devote full

attention to vehicle operation while
talking on the phone, pull off the
road to a safe location and stop
your vehicle.

Monitor, heater, air conditioner, audio, phone and voice recognition systems

4-121

CAR PHONE OR CB RADIO

4-122

Monitor, heater, air conditioner, audio, phone and voice recognition systems

CAUTION

. Keep the antenna as far away as

possible from the electronic control
modules.

. Keep the antenna wire more than 8

in (20 cm) away from the electronic
control system harness. Do not
route the antenna wire next to any
harness.

. Adjust the antenna standing-wave

ratio as recommended by the man-
ufacturer.

. Connect the ground wire from the

CB radio chassis to the body.

. For details, it is recommended you

visit a NISSAN dealer.

*Type A is models with navigation system.

WARNING

. Use a phone after stopping your

vehicle in a safe location. If you
have to use a phone while driving,
exercise extreme caution at all
times so full attention may be given
to vehicle operation.

. If you find yourself unable to devote

full attention to vehicle operation
while talking on the phone, pull off
the road to a safe location and stop
your vehicle before doing so.

CAUTION

To avoid draining the vehicle battery,
use a phone after starting the engine.

Your vehicle is equipped with Bluetooth

Hands-Free Phone System. If you are an owner
of a compatible Bluetooth

enabled cellular

phone, you can set up the wireless connection
between your cellular phone and the in-vehicle
phone module. With Bluetooth

wireless tech-

nology, you can make or receive a telephone call

with your cellular phone in your pocket.

Once a cellular phone is connected to the in-
vehicle phone module, no phone connecting
procedure is required anymore. Your phone is
automatically connected with the in-vehicle
phone module when the ignition switch is
pushed to the ON position with the registered
cellular phone turned on and carried in the
vehicle.

You can register up to 5 different Bluetooth

cellular phones in the in-vehicle phone module.
However, you can talk on only one cellular phone
at a time.

The NISSAN Voice Recognition system sup-
ports the phone commands, so dialing a phone
number using your voice is possible. For more
details, see “NISSAN Voice Recognition system
(models with navigation system)” (P.4-154).

Before using the Bluetooth

Hands-Free Phone

System, refer to the following notes.
. Wireless LAN (Wi-Fi) and the Bluetooth

functions share the same frequency band
(2.4 GHz). Using the Bluetooth

and the

wireless LAN functions at the same time may
slow down or disconnect the communica-
tion and cause undesired noise. It is
recommended that you turn off the wireless
LAN (Wi-Fi) when using the Bluetooth

functions.

Bluetooth

HANDS-FREE PHONE

SYSTEM (Type A) (if so equipped)

. Set up the wireless connection between a

compatible cellular phone and the in-vehicle
phone module before using the Bluetooth

Hands-Free Phone System.

. Some Bluetooth

enabled cellular phones

may not be recognized by the in-vehicle
phone module. Please visit
www.nissanusa.com/bluetooth for a recom-
mended phone list.

. You will not be able to use a hands-free

phone under the following conditions:
— Your vehicle is outside of the telephone

service area.

— Your vehicle is in an area where it is

difficult to receive radio waves; such as in
a tunnel, in an underground parking
garage, behind a tall building or in a
mountainous area.

— Your cellular phone is locked in order not

to be dialed.

. When the radio wave reception is not good

or ambient sound is too loud, it may be
difficult to hear the other person’s voice
during a call.

. Immediately after the ignition switch is

pushed to the ON position, it may be
impossible to receive a call for a short
period of time.

. Do not place the cellular phone in an area

surrounded by metal or far away from the in-
vehicle phone module to prevent tone quality
degradation and wireless connection dis-
ruption.

. While a cellular phone is connected through

the Bluetooth

wireless connection, the

battery power of the cellular phone may
discharge quicker than usual.

. If the Bluetooth

Hands-Free Phone System

seems to be malfunctioning, please visit
www.nissanusa.com/bluetooth for trouble-
shooting help.

. Some cellular phones or other devices may

cause interference or a buzzing noise to
come from the audio system speakers.
Storing the device in a different location
may reduce or eliminate the noise.

. Refer to the cellular phone Owner’s Manual

regarding the telephone pairing procedure
specific to your phone, battery charging,
cellular phone antenna, etc.

. The antenna display on the monitor will not

coincide with the antenna display of some
cellular phones.

. Keep the interior of the vehicle as quiet as

possible to hear the caller’s voice clearly as
well as to minimize its echoes.

. If reception between callers is unclear,

adjusting the incoming or outgoing call
volume may improve the clarity.

REGULATORY INFORMATION

FCC Regulatory information

. CAUTION: To maintain compliance with

FCC’s RF exposure guidelines, use only
the supplied antenna. Unauthorized antenna,
modification, or attachments could damage
the transmitter and may violate FCC regula-
tions.

. Operation is subject to the following two

conditions:

1. this device may not cause interference and

2. this device must accept any interference,

including interference that may cause un-
desired operation of the device

IC Regulatory information

. Operation is subject to the following two

conditions: (1) this device may not cause
interference, and (2) this device must accept
any interference, including interference that
may cause undesired operation of the
device.

. This Class B digital apparatus meets all

requirements of the Canadian Interference-
Causing Equipment Regulations.

Monitor, heater, air conditioner, audio, phone and voice recognition systems

4-123

4-124

Monitor, heater, air conditioner, audio, phone and voice recognition systems

Bluetooth trademark:

Bluetooth

is a trademark owned

by Bluetooth SIG, Inc., and
licensed to Clarion Co., Ltd.

VOICE COMMANDS

You can use voice commands to operate various
Bluetooth

Hands-Free Phone System features

using the NISSAN Voice Recognition system.

For more details, see “NISSAN Voice Recogni-
tion system (models with navigation system)”
(P.4-154).

SAA3603

CONTROL BUTTONS

1. TALK

/PHONE SEND

button

JVH0473X

CONNECTING PROCEDURE

1. Push the

button, and select the

“Connect Phone” key.

SAA2520

2. When a PIN code appears on the screen,

operate the compatible Bluetooth

cellular

phone to enter the PIN code.

If you have the phone corresponding to
Bluetooth

Secure Simple Pairing, select

MY-CAR on the cellular phone device
searching screen.

Select “Yes” if the PIN code displayed on

the cellular phone is the same as the one
displayed on the screen.

Both vehicle system and mobile side

approval operation on the screens will
make Bluetooth

pairing.

The connecting procedure of the cellular
phone varies according to each cellular

phone. See the cellular phone Owner’s
Manual for the details. You can also visit

www.nissanusa.com/bluetooth or call
NISSAN Consumer Affairs Department for
instructions on pairing NISSAN recom-
mended cellular phones.

When the connection process is completed,
the screen will return to the Phone menu
display.

PHONE SELECTION

Up to 5 cellular phones can be registered to the
system. To switch to connect another cellular
phone, push

button and select the “Con-

nected Phones” key. The registered cellular
phones are shown on the list. If you select a
cellular phone that is different from the one
currently connected, the newly selected phone
will be connected to the system.

QUICK DIAL

This vehicle has two phonebooks available for
hands-free use. Depending on the phone, the
system may automatically download the entire
cell phone’s phonebook into the “Phonebook”.
For the details about downloading a phonebook,
see “Phone setting” (P.4-130). If a phonebook
does not automatically download, the Quick Dial
may be set for up to 1,000 entries. This Quick
Dial allows the recording of a name to speak

while using the Voice Recognition system.

Monitor, heater, air conditioner, audio, phone and voice recognition systems

4-125

4-126

Monitor, heater, air conditioner, audio, phone and voice recognition systems

JVH1509X

1. Push the

button and select the “Quick

Dial” key.

2. Select the “Add New” key at the top of the

screen.

JVH1407X

3. Choose the method for entering the phone-

book entry. For this example, select “Enter
Number by Keypad”.

4. Input the name and phone number manually

using the keypad displayed on the screen.
(See “How to use touch screen (models
with navigation system)” (P.4-7).)

JVH1194X

5. Select the “Voicetag” key to record a name

to speak when using the NISSAN Voice
Recognition system.

6. Select the “Store” key and prepare to speak

the name after the tone.

7. When the voicetag is successfully saved,

select the “OK” key to save the Quick Dial
entry.

8. After the Quick Dial entry is saved, it will

show a screen that is ready to call the
number. Press the BACK button to return to
the Quick Dial.

There are different methods to input a phone
number. Select one of the following options

instead of “Enter Number by Keypad” in step 3.
. Copy from Call History

The system will show a list of incoming,
outgoing or missed calls that were down-
loaded from the connected cellular phone
(depending on the phone’s compatibility).
Select one of these entries to save in the
Quick Dial.

. Copy from the Phonebook

The system will show the connected cellular
phone’s phonebook that was downloaded
(depending on the phone’s compatibility).
Select one of these entries to save in the
Quick Dial.

JVH0480X

Editing the Quick Dial

1. Push the SETTING button and select the

“Phone” key.

2. Select the “Edit Quick Dial” key.

3. Select the desired entry from the displayed

list.

4. Select the desired item to change.

JVH0478X

The following editing items are available:
. Entry #

Changes the displayed number of the
selected entry.

. Name

Edit the name of the entry using the keypad
displayed on the screen.

. Number

Edit the phone number using the keypad
displayed on the screen.

. Type

Select an icon from the icon list.

. Voicetag

Confirm and store the voicetag. Voicetags

Monitor, heater, air conditioner, audio, phone and voice recognition systems

4-127

4-128

Monitor, heater, air conditioner, audio, phone and voice recognition systems

allow easy dialing using the NISSAN Voice
Recognition system. (See “NISSAN Voice
Recognition system (models with navigation
system)” (P.4-154).)

To delete an entry, select the “Delete” key at
step 3.

JVH0479X

MAKING A CALL

To make a call, follow this procedure.

1. Push the

button on the steering wheel.

The “PHONE” screen will appear on the
display.

2. Select the “Phonebook” key on the

“PHONE” menu.

3. Select the desired entry from the list.

4. Confirm the correct entry by selecting for the

correct number from the list.

There are different methods to make a call.
Select one of the following options instead of
“Phonebook” in step 2 above.

. Quick Dial

Select an entry stored in the Quick Dial.

. Call History

Select an outgoing, incoming or missed call
downloaded from your cell phone (depend-
ing on your phone’s compatibility).

. Dial Number

Input the phone number manually using the
keypad displayed on the screen. (See “How
to use touch screen (models with navigation
system)” (P.4-7).)

SAA2525

RECEIVING A CALL

When you hear a phone ring, the display will
change to the incoming call mode. To receive a
call, perform one of the following procedures
listed below.

Select the “Answer” key.

Push the

button on the steering wheel.

There are some options available when receiving
a call. Select one of the following displayed on
the screen.
. Answer

Accept an incoming call to talk.

. Hold Call

Put an incoming call on hold.

. Reject Call

Reject an incoming call.
To finish the call, perform one of the
following procedures listed below.

Select the “Hang up” key.

Push the

button on the steering wheel.

SAA3587

DURING A CALL

There are some options available during a call.
Select one of the following displayed on the
screen if necessary.
. Hang up

Finish the call.

. Use Handset

Transfer the call to the cellular phone.

. Mute

Mute your voice to the person.

. Keypad

Using the touch tone, send digits to the
connected party for using services such as
voicemail.

Monitor, heater, air conditioner, audio, phone and voice recognition systems

4-129

4-130

Monitor, heater, air conditioner, audio, phone and voice recognition systems

. Cancel Mute

This will appear after “Mute” is selected.
Mute will be canceled.

. Switch Call*

Select “Switch Call” to answer another
incoming call. By selecting “Hang up”, you
can end a call and can speak to a caller who
is on hold again.
* This function may not be usable, depend-
ing on the model of phone.

To adjust the person’s voice to be louder or
quieter, push the volume control switch (+ or

í)

on the steering wheel or turn the volume control
knob on the instrument panel while talking on
the phone. This adjustment is also available in
the SETTING mode.

JVH0480X

PHONE SETTING

To set up the Bluetooth

Hands-Free Phone

System to your preferred settings, push the
SETTING button on the instrument panel and
select the “PHONE” key.

Edit Quick Dial

To edit the Quick Dial, use the same procedure
as described in “Quick Dial” (P.4-125).

Delete Quick Dial

The Quick Dial entries can be deleted all at the
same time or one by one.

Download Phonebook

Download the contacts registered in a Blue-
tooth

cellular phone. Availability of this function

depends on each cellular phone. The memory
downloading procedure from the cellular phone
also varies according to each cellular phone.
See cellular phone Owner’s Manual for details.

Volume & Ringtone

The following kinds of phone volume can be set.
Pushing the

button and selecting the

“Volume & Ringtone” key can also operate the
same settings.
. Ringtone/Incoming Call/Outgoing Call

To increase or decrease the volume, select
the “Ringtone”, “Incoming Call” or “Out-
going Call” key and adjust it with the multi-
function controller.

. Automatic Hold

When this function is activated, an incoming
phone call is automatically held.

. Vehicle Ringtone

When this function is activated, a specific
ringtone that is different from the cellular
phone will sound when receiving a call.

Auto Downloaded

When this item is activated, the phonebook of a
hands-free phone is automatically downloaded
at the same time that the hands-free phone is
connected.

Monitor, heater, air conditioner, audio, phone and voice recognition systems

4-131

4-132

Monitor, heater, air conditioner, audio, phone and voice recognition systems

TROUBLESHOOTING GUIDE

The system should respond correctly to all voice commands without difficulty. If problems are encountered, try the following solutions.

Where the solutions are listed by number, try each solution in turn, starting with number 1, until the problem is resolved.

Symptom

Solution

The system fails to interpret the command correctly.

1. Ensure that the command is valid. (See “NISSAN Voice Recognition system (models with navigation system)”
(P.4-154).)

2. Ensure that the command is spoken after the tone.

3. Speak clearly without pausing between words and at a level appropriate to the ambient noise level in the vehicle.

4. Ensure that the ambient noise level is not excessive (for example, windows open or defroster on). NOTE: If it is too
noisy to use the phone, it is likely that the voice commands will not be recognized.

5. If more than one command was said at a time, try saying the commands separately.

The system consistently selects the wrong voicetag.

1. Ensure that the voicetag requested matches what was originally stored. (See “Quick Dial” (P.4-125).)

2. Replace one of the names being confused with a new name.

* Type B is models without navigation
system/without text message function.

WARNING

. Use a phone after stopping your

vehicle in a safe location. If you
have to use a phone while driving,
exercise extreme caution at all
times so full attention may be given
to vehicle operation.

. If you find yourself unable to devote

full attention to vehicle operation
while talking on the phone, pull off
the road to a safe location and stop
your vehicle before doing so.

CAUTION

To avoid draining the vehicle battery,
use a phone after starting the engine.

SAA3677

PHONE SEND

button

PHONE END

button

Your vehicle is equipped with the Bluetooth

Hands-Free Phone System. If you have a
compatible Bluetooth

enabled cellular phone,

you can set up the wireless connection between
your cellular phone and the in-vehicle phone
module. With Bluetooth

wireless technology,

you can make or receive a hands-free telephone
call in your vehicle.

Once your cellular phone is connected to the in-
vehicle phone module, no other phone connect-
ing procedure is required. Your phone is
automatically connected with the in-vehicle
phone module when the ignition switch is

pushed to the ON position with the connected
cellular phone turned on and carried in the
vehicle.

You can connect up to 5 different Bluetooth

cellular phones in the in-vehicle phone module.
However, you can talk on only one cellular phone
at a time.

Before using the Bluetooth

Hands-Free Phone

System, refer to the following notes.
. Wireless LAN (Wi-Fi) and the Bluetooth

functions share the same frequency band
(2.4 GHz). Using the Bluetooth

and the

functions.

. Set up the wireless connection between a

compatible cellular phone and the in-vehicle
phone module before using the Bluetooth

Hands-Free Phone System.

. Some Bluetooth

enabled cellular phones

may not be recognized by the in-vehicle
phone module. Please visit www.nissanusa.
com/bluetooth for a recommended phone
list and connecting.

. You will not be able to use a hands-free

phone under the following conditions:

Monitor, heater, air conditioner, audio, phone and voice recognition systems

4-133

Bluetooth

HANDS-FREE PHONE

SYSTEM (Type B) (if so equipped)

Content .. 18 19 20 21 ..
