P0335 CKP SENSOR (POS) EC-667 < COMPONENT DIAGNOSIS > [VQ40DE] C D E F G H I J K L M A EC N P O P0335 CKP SENSOR (POS) Component Description INFOID:0000000005273634 The crankshaft position sensor (POS) is located on the oil pan facing On Board Diagnosis Logic INFOID:0000000005273635 DTC Confirmation Procedure INFOID:0000000005273636 NOTE: Turn ignition switch OFF and wait at least 10 seconds. 2. Turn ignition switch ON. 3. Turn ignition switch OFF and wait at least 10 seconds. TESTING CONDITION: 1. Crank engine for at least 2 seconds and run it for at least 5 seconds at idle speed. 2. Check 1st trip DTC. 3. If 1st trip DTC is detected, go to Diagnosis Procedure INFOID:0000000005273637 1. CHECK GROUND CONNECTIONS PBIB0562E PBIB2744E DTC No. Trouble diagnosis name DTC detecting condition Possible cause P0335 Crankshaft position sen- • The crankshaft position sensor (POS) signal is not detected by the ECM during the first • The proper pulse signal from the crankshaft position sensor (POS) is not sent to ECM • The crankshaft position sensor (POS) signal is not in the normal pattern during engine run- • Harness or connectors (The sensor circuit is open or shorted) • Crankshaft position sensor (POS) |
