CARRIER COVER DLN-253 < ON-VEHICLE REPAIR > [REAR FINAL DRIVE: M226 ] C E F G H I J K L M A B DLN N O P CARRIER COVER Removal and Installation INFOID:0000000005275574 REMOVAL 1. Drain the differential gear oil. Refer to DLN-250, "Changing Differential Gear Oil" 2. Disconnect the parking brake cable and brake tube from the car- 3. Remove the carrier cover bolts and separate the carrier cover CAUTION: • Do not damage the mating surface. mating surface. INSTALLATION 1. Apply a bead of sealant to the mating surface of the carrier "Recommended Chemical Products and Sealants" CAUTION: Remove any old sealant adhering to the mating surfaces. 2. Install the carrier cover to the gear carrier. Tighten the bolts to 3. Connect the parking brake cable and brake tube to the carrier 4. Fill the rear final drive assembly with recommended differential gear oil. Refer to . Tool number : KV10111100 (J-37228) LDIA0126E PDIA1061E |
