Nissan Frontier D40. Manual - part 307





NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

DLN-249

< SYMPTOM DIAGNOSIS >

[REAR FINAL DRIVE: M226 ]

C

E

F

G

H

I

J

K

L

M

A

B

DLN

N

O

P

SYMPTOM DIAGNOSIS

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NVH Troubleshooting Chart

INFOID:0000000005275570

Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.

×

: Applicable

Reference page

DLN-249

DLN-255

DLN-255

MA

-16

MA

-18

DL

N-13

3,

 "NVH T

rou

bl

es

ho

ot

in

g

 Cha

rt

"

RA

X-17

, "NVH T

rou

ble

s

h

o

o

tin

g Ch

art"

RSU-4

"NV

H

 T

rou

ble

s

hoo

ti

ng Cha

rt"

W

T

-4

1, "

N

V

H

 T

rou

bl

es

ho

oti

n

g

 Cha

rt"

RAX-1

7

"NVH T

ro

ubl

es

ho

ot

ing

 Cha

rt"

B

R

-6

, "

N

V

H

 T

rou

bl

es

ho

oti

n

g

 Cha

rt"

ST

-5,

"NVH T

ro

ubl

es

ho

ot

ing

 Cha

rt"

Possible cause and SUSPECTED PARTS

Ge

ar t

o

ot

h ro

ug

h

Gea

r co

nt

ac

t im

pro

p

e

r

T

o

ot

h s

u

rf

ac

es

 worn

Bac

k

las

h inc

o

rr

ec

t

Com

p

a

n

ion

fla

n

g

e

 e

x

c

e

ss

iv

e ru

no

ut

Gea

r oi

l im

p

rop

er

PROPELLER SHAF

T

AXLE AND SUSPE

NSION

TIRES

ROA

D

 WHEEL

AXLE SHAFT

BRAKES

STEERI

N

G

Symptom

Noise

×

×

×

×

×

×

×

×

×

×

×

×

×

DLN-250

< ON-VEHICLE MAINTENANCE >

[REAR FINAL DRIVE: M226 ]

DIFFERENTIAL GEAR OIL

ON-VEHICLE MAINTENANCE

DIFFERENTIAL GEAR OIL

Changing Differential Gear Oil

INFOID:0000000005275571

DRAINING

1.

Stop engine.

2.

Remove the drain plug from the rear final drive assembly to
drain the differential gear oil.

3.

Install the drain plug with sealant applied on the threads to the
rear final drive assembly. Tighten to the specified torque. Refer
to

DLN-255, "Disassembly and Assembly"

.

• Use High Performance Thread Sealant or equivalent. Refer to

GI-22, "Recommended Chemical Products and Sealants"

.

FILLING

1.

Remove the filler plug from the rear final drive assembly.

2.

Fill the rear final drive assembly with new differential gear oil
until the level reaches the specified level near the filler plug hole.

3.

Install the filler plug with sealant applied on the threads to the
rear final drive assembly. Tighten to the specified torque. Refer
to

DLN-255, "Disassembly and Assembly"

.

• Use High Performance Thread Sealant or equivalent. Refer to

GI-22, "Recommended Chemical Products and Sealants"

.

Checking Differential Gear Oil

INFOID:0000000005275572

DIFFERENTIAL GEAR OIL LEAKAGE AND LEVEL

1.

Make sure that differential gear oil is not leaking from the rear final drive assembly or around it.

2.

Check the differential gear oil level from the filler plug hole as
shown.

CAUTION:

Do not start engine while checking differential gear oil level.

3.

Install the filler plug with sealant applied on the threads to the
rear final drive assembly. Tighten to the specified torque. Refer
to

DLN-255, "Disassembly and Assembly"

.

• Use High Performance Thread Sealant or equivalent. Refer to

GI-22, "Recommended Chemical Products and Sealants"

.

LDIA0183E

Differential gear oil
grade and capacity

: Refer to

MA-16, "For North

America: Fluids and Lubri-
cants"

 or

MA-18, "For Mexi-

co: Fluids and Lubricants"

.

LDIA0127E

LDIA0127E

FRONT OIL SEAL

DLN-251

< ON-VEHICLE REPAIR >

[REAR FINAL DRIVE: M226 ]

C

E

F

G

H

I

J

K

L

M

A

B

DLN

N

O

P

ON-VEHICLE REPAIR

FRONT OIL SEAL

Removal and Installation

INFOID:0000000005275573

REMOVAL

1.

Remove rear propeller shaft. Refer to

DLN-144, "Removal and Installation"

 (2S1330),

DLN-163, "Removal

and Installation"

 (3S1330) or

DLN-173, "Removal and Installation"

 (3S1330-2BJ100).

2.

Remove brake calipers and rotors. Refer to

BR-46, "Removal and Installation of Brake Caliper and Disc

Rotor"

.

3.

Measure the total preload torque. Refer to

DLN-264, "Inspection and Adjustment"

.

NOTE:
Record the total preload torque measurement.

4.

Remove the drive pinion lock nut using suitable tool.

5.

Put matching marks on the companion flange and drive pinion using paint.

CAUTION:

Use paint to make the matching marks. Do not damage the companion flange or drive pinion.

6.

Remove the companion flange using suitable tool.

7.

Remove oil seal/dust shield and discard.

CAUTION:

Do not reuse oil seal/dust shield

8.

Remove the front oil seal using Tool.

INSTALLATION

LDIA0122E

WDIA0249E

Tool number

: ST33290001 (J-34286)

LDIA0124E

DLN-252

< ON-VEHICLE REPAIR >

[REAR FINAL DRIVE: M226 ]

FRONT OIL SEAL

1.

Apply multi-purpose grease to the lips of the new front oil seal.
Then drive the new front oil seal in evenly until it becomes flush
with the gear carrier using Tool.

CAUTION:

• Do not reuse front oil seal.
• Do not incline the new front oil seal when installing.
• Apply multi-purpose grease to the lips and differential

gear oil to the circumference of the new front oil seal.

2.

Install oil seal/dust shield.

3.

Install the companion flange to the drive pinion while aligning the matching marks.

4.

Apply anti-corrosive oil to the threads of the drive pinion and the
seating surface of the new drive pinion lock nut and new drive
pinion lock nut washer. Then adjust the drive pinion lock nut
tightening torque using suitable tool A, and check the total pre-
load torque using Tool B.

• The total preload torque should be within the total preload

torque specification. When not replacing the collapsible
spacer, it should also be equal to the measurement taken dur-
ing removal plus an additional 0.56 N·m (0.06 Kg-m, 5 in-lb).

• If the total preload torque is low, tighten the drive pinion lock

nut in 6.8 N·m (0.69 Kg-m, 5ft-lb) increments until the total pre-
load torque is met.

CAUTION:

• Do not reuse drive pinion lock nut or drive pinion lock nut

washer.

• Apply anti-corrosive oil to the threads of the drive pinion

and the seating surface of the new drive pinion lock nut.

• Adjust the drive pinion lock nut tightening torque to the

lower limit first. Do not exceed the drive pinion lock nut specified torque. Refer to

DLN-255, "Dis-

assembly and Assembly"

.

• Do not loosen drive pinion lock nut to adjust the total preload torque. If the total preload torque

exceeds the specifications, replace the collapsible spacer and tighten it again to adjust. Refer to

DLN-255, "Disassembly and Assembly"

.

• After adjustment, rotate drive pinion back and forth 2 to 3 times to check for unusual noise, rota-

tion malfunction, and other malfunctions.

5.

Installation of the remaining components is in the reverse order of removal.

CAUTION:

Check the differential gear oil level after installation. Refer to

DLN-250, "Checking Differential Gear

Oil"

.

Tool number

: ST15310000 (

)

LDIA0125E

Tool number

B: ST3127S000 (J-25765-A)

Total preload torque:

Refer to

DLN-264, "Inspection

and Adjustment"

.

WDIA0380E
