REAR PROPELLER SHAFT DLN-177 < DISASSEMBLY AND ASSEMBLY > [PROPELLER SHAFT: 3S1330-2BJ100] C E F G H I J K L M A B DLN N O P 4. Make sure that the journal moves smoothly and is below the . Center Support Bearing 1. Apply a thin coat of multi-purpose grease to both the propeller shaft tube and the inside surface of the 2. Install the center support bearing on the propeller shaft tube 3. Install a new clamp over the boot on the slip yoke. 4. Align the matching marks and install the slip yoke on the propeller shaft tube. 5. Clean the surfaces and position the boot over the propeller shaft tube and tighten the clamp. 6. Install the center support bearing bracket, then install the rear LDIA0119E LDIA0153E WDIA0066E |
