Nissan Frontier D40. Manual - part 41

AV-156

< ECU DIAGNOSIS >

[PREMIUM AUDIO (CREW CAB)]

AUDIO AMP

12

(GR)

28

(O)

Rear door speak-
er RH and rear
door tweeter RH

Output

Ignition

switch

ON

Receive audio sig-
nal

13

 (W)

29

(P)

Front door tweet-
er RH

Output

Ignition

switch

ON

Receive audio sig-
nal

14

(Y)

30

(GR)

Front tweeter LH

Output

Ignition

switch

ON

Receive audio sig-
nal

15

(BR)

31

(L)

Front door speak-
er LH

Output

Ignition

switch

ON

Receive audio sig-
nal

16

(LG)

32

(R)

Front door speak-
er RH

Output

Ignition

switch

ON

Receive audio sig-
nal

17

(R/B)

Ground

Battery

Input

–

–

Battery voltage

20

(B)

Ground

Ground

–

Ignition

switch

ON

–

–

21

 (Y)

5

(BR)

Audio sound sig-
nal front RH

Input

Ignition

switch

ON

Receive audio sig-
nal

Terminal

(wire color)

Item

Signal

input/

output

Condition

Reference value

(Approx.)

+

–

SKIA0177E

SKIA0177E

SKIA0177E

SKIA0177E

SKIA0177E

SKIA0177E

AV

AUDIO AMP

AV-157

< ECU DIAGNOSIS >

[PREMIUM AUDIO (CREW CAB)]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

22

(W)

6

(B)

Audio sound sig-
nal front LH

Input

Ignition

switch

ON

Receive audio sig-
nal

23

(L)

7

(B/W)

Audio sound sig-
nal rear RH

Input

Ignition

switch

ON

Receive audio sig-
nal

24

(BR)

8

(B/R)

Audio sound sig-
nal rear LH

Input

Ignition

switch

ON

Receive audio sig-
nal

Terminal

(wire color)

Item

Signal

input/

output

Condition

Reference value

(Approx.)

+

–

SKIA0177E

SKIA0177E

SKIA0177E

AV-158

< ECU DIAGNOSIS >

[PREMIUM AUDIO (CREW CAB)]

SATELLITE RADIO TUNER

SATELLITE RADIO TUNER

Reference Value

INFOID:0000000005274970

PHYSICAL VALUES

AWNIA1778ZZ

Terminal

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

22

(R)

21

(G)

Satellite radio sound signal
LH

Output

Ignition

switch

ON

When satellite radio mode
is selected

24

(B)

23

(W)

Satellite radio sound signal
RH

Output

Ignition

switch

ON

When satellite radio mode
is selected

25

—

Shield

—

—

—

—

26

—

Shield

—

—

—

—

28

(O)

Ground

Request signal
(SAT

→

CONT)

Output

Ignition

switch

ON

When satellite radio mode
is selected

29

(P)

Ground

Communication signal
(SAT

→

CONT)

Output

Ignition

switch

ON

When satellite radio mode
is selected

SKIB3609E

SKIB3609E

SKIA9299J

SKIA9300J

AV

SATELLITE RADIO TUNER

AV-159

< ECU DIAGNOSIS >

[PREMIUM AUDIO (CREW CAB)]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

30

(L)

Ground

Communication signal
(CONT

→

SAT)

Input

Ignition

switch

ON

When satellite radio mode
is selected

32

(R/B)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

36

(G/B)

Ground

ACC power supply

Input

Ignition

switch

ACC

—

Battery voltage

37

—

Satellite antenna

Input

—

—

—

Terminal

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIA9301J
