BODY HARNESS
GROUND
CONNECT TO
CONN.
NO.
CELL CODE
B10/B18
A/T CONTROL DEVICE
B63
AT-NONDTC, EL-ILL
DOOR MIRROR SWITCH
B78
EL-MIRROR
DOOR MIRROR LH
D39
EL-DEF
DOOR MIRROR RH
D68
EL-DEF
FRONT DOOR LOCK ACTUATOR LH
D42
EL-D/LOCK, EL-THEFT
FRONT DOOR LOCK ACTUATOR LH
D36
EL-S/LOCK, EL-MULTI, EL-THEFT
FRONT DOOR LOCK ACTUATOR RH
D80
EL-D/LOCK, EL-THEFT
FRONT DOOR LOCK ACTUATOR RH
D41
EL-S/LOCK, EL-MULTI, EL-THEFT
FRONT POWER SOCKET
B65
EL-CIGER
FRONT SIDE AIR BAG MODULE LH
B99
RS-SRS
FRONT SIDE AIR BAG MODULE RH
B107
RS-SRS
FUEL LEVEL SENSOR UNIT (TD27Ti)
C9
EL-METER, EL-WARN
FUEL LEVEL SENSOR UNIT (ZD30DDTi)
C11
EL-METER, EL-WARN
HEATED SEAT LH
B17
EL-HSEAT
HEATED SEAT RH
B24
EL-HSEAT
HEATED SEAT SWITCH LH
B19
EL-HSEAT
HEATED SEAT SWITCH RH
B22
EL-HSEAT
HIGH-MOUNTED STOP LAMP
T8
EL-STOP/L
KEY CYLINDER SWITCH LH
D8
EL-S/LOCK, EL-THEFT
KEY CYLINDER SWITCH RH
D61
EL-S/LOCK, EL-THEFT
LICENSE PLATE LAMP LH
C5
EL-TAIL/L
LICENSE PLATE LAMP RH
C6
EL-TAIL/L
POWER WINDOW MAIN SWITCH (LHD MODELS)
D40
EL-WINDOW, EL-D/LOCK, EL-S/
LOCK, EL-MULTI, EL-THEFT
POWER WINDOW MAIN SWITCH (RHD MODELS)
D69
EL-WINDOW, EL-S/LOCK,
EL-MULTI, EL-THEFT
REAR COMBINATION LAMP LH
C4
EL-TAIL/L, EL-BACK/L, EL-R/FOG,
EL-TURN, EL-THEFT
REAR COMBINATION LAMP RH
C7
EL-TAIL/L, EL-BACK/L, EL-R/FOG,
EL-TURN, EL-THEFT
REAR DOOR LOCK ACTUATOR LH
D56
EL-S/LOCK, EL-MULTI, EL-THEFT
REAR DOOR LOCK ACTUATOR RH
D76
EL-S/LOCK, EL-MULTI, EL-THEFT
REAR POWER SOCKET
B66
EL-CIGER
REAR WINDOW DEFOGGER
T6
EL-DEF
REAR WIPER MOTOR
T4
EL-WIP/R
STOP LAMP LH
B14
EL-STOP/L
STOP LAMP RH
B30
EL-STOP/L
THEFT WARNING HORN
B112
EL-THEFT
ULTRASONIC CANCEL SWITCH
B77
EL-THEFT
B96
SHIELD WIRE (AIR BAG DIAGNOSIS SENSOR UNIT)
B100
RS-SRS
B109
SHIELD WIRE (AIR BAG DIAGNOSIS SENSOR UNIT)
B105
RS-SRS
GROUND DISTRIBUTION
EL-24
