16. A/T Does Not Hold Lock-up Condition

SYMPTOM:

A/T does not hold lock-up condition for more than 36 seconds.

Does self-diagnosis show damage to
engine speed signal circuit after cruise
test?

No

E

Yes

Check engine speed sig-
nal. Refer to AT-82.

1. Remove oil pan.
2. Check A/T fluid condition.

OK

E

NG

1. Remove control valve

assembly. Refer to
AT-118.

2. Check the following

items:

I

Torque converter clutch
control valve

I

Pilot valve

I

Pilot filter

3. Disassemble A/T.
4. Check torque converter

and oil pump assembly.

1. Remove control valve assembly. Refer

to AT-118.

2. Check the following items:

I

Torque converter clutch control valve

I

Pilot valve

I

Pilot filter

OK

F

OK

Check again.

OK

E

NG

1. Perform TCM input/

output signal inspection.

2. If NG, recheck TCM pin

terminals for damage or
loose connection with
harness connector.

INSPECTION END

17. Lock-up Is Not Released

SYMPTOM:

Lock-up is not released when accelerator pedal is released.

Does “ECU INPUT SIGNALS” in
Data Monitor show damage to closed
throttle position switch circuit?

----------------------------------------------------------------------------------------------------------------------- OR -----------------------------------------------------------------------------------------------------------------------

Does self-diagnosis show damage to
closed throttle position switch circuit?

No

E

Yes

Check closed throttle posi-
tion switch. Refer to AT-93.

Check again.

OK

E

NG

1. Perform TCM input/

output signal inspection.

2. If NG, recheck TCM pin

terminals for damage or
loose connection with
harness connector.

INSPECTION END

SAT835H

SAT171B

SAT146BA

H

H

H

H

H

H

H

DIAGNOSTIC PROCEDURES FOR SYMPTOMS

AT-112

18. Engine Speed Does Not Return To Idle

(Light Braking D

4

→

D

3

)

SYMPTOM:

I

Engine speed does not smoothly return to idle when A/T
shifts from D

4

to D

3

.

I

Vehicle does not decelerate by engine brake when turning
overdrive control switch OFF.

I

Vehicle does not decelerate by engine brake when shifting
A/T from “D” to “2” position.

Does self-diagnosis show damage to
overrun clutch solenoid valve circuit after
cruise test?

No

E

Yes

Check overrun clutch sole-
noid valve. Refer to AT-71.

Check throttle (accelerator) position sen-
sor. Refer to EC section [TROUBLE
DIAGNOSIS FOR “THROTTLE (ACCEL)
POSI SEN”].

OK

E

NG

Repair or replace throttle
(accelerator) position sen-
sor.

1. Remove oil pan.
2. Check A/T fluid condition.

OK

E

NG

1. Remove control valve

assembly. Refer to
AT-118.

2. Check the following

items:

I

Overrun clutch control
valve

I

Overrun clutch reducing
valve

I

Overrun clutch solenoid
valve

3. Disassemble A/T.
4. Check the following

items:

I

Overrun clutch assembly

I

Oil pump assembly

1. Remove control valve assembly. Refer

to AT-118.

2. Check the following items:

I

Overrun clutch control valve

I

Overrun clutch reducing valve

I

Overrun clutch solenoid valve

OK

F

OK

Check again.

OK

E

NG

1. Perform TCM input/

output signal inspection.

2. If NG, recheck TCM pin

terminals for damage or
loose connection with
harness connector.

INSPECTION END

YAT338

NAT262

SAT171B

H

H

H

H

H

H

DIAGNOSTIC PROCEDURES FOR SYMPTOMS

AT-113

19. Vehicle Does Not Start From D

1

SYMPTOM:

Vehicle does not start from D

1

on Cruise test — Part 2.

Does self-diagnosis show damage to
vehicle speed sensor

⋅

A/T (revolution

sensor), shift solenoid valve A, B or
vehicle speed sensor

⋅

MTR after cruise

test?

No

E

Yes

Check damaged circuit.
Refer to AT-52, AT-56,
AT-65 or AT-68.

Check again.

OK

E

NG

1. Perform TCM input/

output signal inspection.

2. If NG, recheck TCM pin

terminals for damage or
loose connection with
harness connector.

Go to 11. Vehicle Cannot Be Started From
D

1

, AT-107.

SAT832H

H

H

H

DIAGNOSTIC PROCEDURES FOR SYMPTOMS

AT-114

20. A/T Does Not Shift: D

2

→

D

1

When

Depressing Accelerator Pedal

SYMPTOM:

A/T does not shift from D

2

to D

1

when depressing accelerator

pedal fully at the specified speed.

Are 9. Vehicle Does Not Creep
Backward In “R” Position and 10.
Vehicle Does Not Creep Forward In
“D”, “2” Or “1” Position OK?

Yes

E

No

Go to 9. Vehicle Does Not
Creep Backward In “R” Position
and 10. Vehicle Does Not Creep
Forward In “D”, “2” Or “1”
Position, AT-105, AT-106.

Does “ECU INPUT SIGNAL”
show damage to park/neutral
position switch circuit?

----------------------------------------------------------------------------------------------------- OR -----------------------------------------------------------------------------------------------------

Does self-diagnosis show dam-
age to park/neutral position
switch circuit?

No

E

Yes

Check park/neutral position
switch. Refer to AT-93.

Check vehicle speed sensor

⋅

A/T

(revolution sensor) and vehicle
speed sensor

⋅

MTR. Refer to AT-52,

AT-56.

OK

E

NG

Repair or replace vehicle speed
sensor

⋅

A/T (revolution sensor)

and vehicle speed sensor

⋅

MTR.

Check throttle (accelerator) position
sensor. Refer to EC section
[TROUBLE DIAGNOSIS FOR
“THROTTLE (ACCEL) POSI SEN”
(DTC 43)].

OK

E

NG

Repair or replace throttle (accel-
erator) position sensor.

1. Remove oil pan.
2. Check A/T fluid condition.

OK

E

NG

1. Remove control valve. Refer

to AT-118.

2. Check the following items:

I

Shift valve A

I

Shift solenoid valve A

I

Pilot valve

I

Pilot filter

3. Disassemble A/T.
4. Check the following items:

I

Servo piston assembly

I

Brake band

I

Oil pump assembly

1. Remove control valve. Refer to

AT-118.

2. Check the following items:

I

Shift valve A

I

Shift solenoid valve A

I

Pilot valve

I

Pilot filter

OK

F

OK

Check again.

OK

E

NG

1. Perform TCM input/output

signal inspection.

2. If NG, recheck TCM pin termi-

nals for damage or loose con-
nection with harness connec-
tor.

INSPECTION END

SAT146BA

NAT262

SAT171B

H

H

H

H

H

H

H

DIAGNOSTIC PROCEDURES FOR SYMPTOMS

AT-115
