4 DETECT MALFUNCTIONING PART Check the following. I Harness connectors E225, F108 I Harness connectors F135, M842 (RHD models) I Harness for open or short between engine coolant temperature sensor and ECM E Repair open circuit or short to ground or short to power in harness or connectors. 5 CHECK ENGINE COOLANT TEMPERATURE SENSOR 1. Remove engine coolant temperature sensor from the engine. SEF304X OK or NG OK E GO TO 6. NG E Replace engine coolant temperature sensor. 6 CHECK INTERMITTENT INCIDENT Refer to “TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT”, EC-78. E INSPECTION END DTC 0103 COOLANT TEMP SEN ZD30DDTi Diagnostic Procedure (Cont’d) EC-98 |
