*: Special tool or commercial equivalent
Tool number
Tool name
Description
KV111045SO
Cam bushing replacer
set
q
1
KV11104510
Replacer bar
q
2
KV1104520
Guide plate
q
3
KV11104530
Adapter
(1st bushing)
q
4
ST15243000
Drift
Removing cam bushing or installing cam
bushing
KV10109300*
Injection pump drive
gear holder
Preventing drive gear from rotating
KV11103000*
Injection pump drive
gear puller
Removing drive gear
q
1
ED19601000
Compression gauge
q
2
ED19600600
Compression gauge
adapter (for glow plug
hole)
q
3
ED19600700
Compression gauge
adapter (for injector
hole)
Checking compression pressure
WS39930000*
Tube presser
Pressing the tube of liquid gasket
KV119E0030
Nozzle holder socket
Removing and installation injection
nozzle assembly
ST11032000*
Valve guide reamer
8.0 mm (0.315 in) dia.
Reaming valve guide
PREPARATION
TD27Ti
Special Service Tools (Cont’d)
EM-98
