Wheel runout Unit: mm (in) Wheel type Steel Aluminum 16 ″ x 7J 16 ″ x 7J Radial runout limit 0.5 (0.020) 0.3 (0.012) Lateral runout limit 0.8 (0.031) 0.3 (0.012) Wheel bearing Axial end play limit mm (in) 0 Lock nut Tightening torque N ⋅ m (kg-m, ft-lb) 78 - 98 (7.9 - 10, 57 - 72) Retightening torque N ⋅ m (kg-m, in-lb) 0.5 - 1.5 (0.05 - 0.15, 4 - 13) TIGHTENING TORQUE Unit N ⋅ m kg-m ft-lb Clutch Pedal stopper lock nut 12 - 15 1.2 - 1.5 8.7 - 10.8 Master cylinder push rod 8 - 11 0.8 - 1.1 5.8 - 8.0 Manual transmission Drain and filler plugs FS5R30A 25 - 34 2.5 - 3.5 18 - 25 Differential carrier Drain and filler plugs R180A 39 - 59 4 - 6 28.8 - 43.5 H233B 59 - 98 6 - 10 43.5 - 72.3 Front axle and front suspen- Tie-rod lock nut 60 - 70 6.1 - 7.1 44.3 - 51.6 Brake system Air bleeder valve 7 - 9 0.7 - 0.9 5.1 - 6.5 Wheel and tire Wheel nut 118 - 147 12.0 - 15.0 87.0 - 108.4 SERVICE AND SPECIFICATIONS (SDS) Chassis and Body Maintenance (Cont’d) MA-50 |
