Nissan Terrano r20e. Manual - part 68





Diagnostic Procedure 2 (Warning lamp stays
on when ignition switch is turned ON)

CHECK FUSE.
Check 10A fuse

19

. For fuse layout, refer

to POWER SUPPLY ROUTING in EL sec-
tion.

OK

E

NG

q

A

(Go to next page.)

CHECK WARNING LAMP.
1. Disconnect ABS actuator and electric

unit connector.

2. Connect suitable wire between ABS

actuator and electric unit harness con-
nector

F29

terminals

q

13

,

q

21

and ground.

Warning lamp should not activate.

OK

E

NG

q

B

(Go to next page.)

CHECK HARNESS CONNECTOR.
Check ABS actuator and electric unit pin
terminals for damage or the connection of
ABS actuator and electric unit harness
connector. Reconnect ABS actuator and
electric unit harness connector. Then
retest.

NG

E

OK

Inspection end

CHECK ABS MOTOR GROUND.
1. Turn ignition switch OFF.

2. Disconnect ABS actuator and electric

unit connector.

3. Check continuity between ABS actuator

and electric unit connector

F29

(body

side) terminal

q

16

and ground.

Continuity should exist.

OK

E

NG

Check the following.

I

Harness connector

F29

I

Harness for open or short
between ABS actuator
and electric unit and
ground

If NG, repair harness or
connector.

REPLACE.
Replace ABS actuator and electric unit.

YBR271

NBR345

NBR326

H

H

H

H

TROUBLE DIAGNOSES

BR-69

q

A

REPLACE.
Replace fuse.
Does the fuse blow out when ignition
switch is turned ON?

Yes

E

No

Inspection end

CHECK ABS ACTUATOR AND ELEC-
TRIC UNIT POWER SUPPLY CIRCUIT
FOR SHORT.
1. Disconnect battery cable and ABS

actuator and electric unit connector

F29

.

2. Check continuity between ABS actuator

and electric unit connector

F29

body

side terminal

q

15

and ground.

Continuity should not exist.

OK

E

NG

Check the following.

I

Harness connector

F29

I

Harness for open or short
between ABS actuator
and electric unit and fuse

If NG, repair harness or
connector.

REPLACE.
Replace ABS actuator and electric unit.

q

B

CHECK ABS WARNING LAMP CON-
TROL CIRCUIT.
1. Disconnect combination meter connector

LHD:

F118

and

F119

, or RHD:

M837

and

M838

.

2. Check continuity between ABS actuator

and electric unit connector

F29

(body

side) terminal and combination meter
connector LHD:

F118

and

F119

, or

RHD:

M837

and

M838

.

OK

E

NG

Check the following.

I

Harness connectors
LHD:

F118

and

F119

, or

RHD:

M837

and

M838

and

F29

I

Harness for open or
short between ABS
actuator and electric unit
and combination meter

If NG, repair harness or
connectors.

CHECK COMBINATION METER.
Check combination meter. Refer to WARN-
ING LAMPS in EL section.

F29

LHD:

F119

RHD:

M838

LHD:

F118

RHD:

M837

Continu-

ity

Terminal

q

13

q

1

Yes

Terminal

q

21

q

44

Yes

NBR327

YBR270

H

H

H

H

H

TROUBLE DIAGNOSES

Diagnostic Procedure 2 (Warning lamp stays
on when ignition switch is turned ON) (Cont’d)

BR-70

Diagnostic Procedure 3 (ABS actuator solenoid
valve and solenoid valve relay)

Malfunction code Nos. 41, 42, 45, 46, 55, 56, 63

CHECK FUSIBLE LINK.
Check 40A. For fusible link layout, refer to
POWER SUPPLY ROUTING in EL section.

OK

E

NG

q

A

(Go to next page.)

CHECK FUSE.
Check 10A fuse

19

. For fuse layout, refer

to POWER SUPPLY ROUTING in EL sec-
tion.

OK

E

NG

q

B

(Go to next page.)

CHECK CONNECTOR.
1. Disconnect ABS actuator and electric

unit connector. Check terminals for
damage or loose connection. Then
reconnect connector.

2. Carry out self-diagnosis again.

Does warning lamp activate again?

Yes

E

No

Inspection end

CHECK ABS ACTUATOR AND ELECTRIC
UNIT GROUND CIRCUIT.
Refer to ABS ACTUATOR AND ELECTRIC
UNIT GROUND in Ground Circuit Check,
BR-66.

OK

E

NG

Repair harness and con-
nector.

CHECK SOLENOID VALVE RELAY
POWER SUPPLY CIRCUIT.
1. Disconnect ABS actuator and electric

unit connector.

2. Check voltage between ABS actuator

and electric unit connector

F29

(body

side) terminal

q

18

and ground.

Battery voltage should exist.

OK

E

NG

Check the following.

I

Harness connector

F29

,

LHD:

F68

and

M784

, or

RHD:

F79

and

M744

I

Harness for open or
short between ABS
actuator and electric unit
and fusible link

If NG, repair harness or
connector.

REPLACE.
Replace ABS actuator and electric unit.

NBR329

NBR330

H

H

H

H

H

TROUBLE DIAGNOSES

BR-71

q

A

REPLACE.
Replace fusible link.
Does the fusible link blow out when
ignition switch is turned ON?

Yes

E

No

Inspection end

CHECK SOLENOID VALVE RELAY
POWER SUPPLY CIRCUIT.
1. Disconnect battery cable and ABS

actuator and electric unit connector.

2. Check continuity between ABS actuator

and electric unit connector

F29

(body

side) terminal

q

18

and ground.

Continuity should not exist.

OK

E

NG

Check the following

I

Harness connector

F29

, LHD:

F68

and

M784

, or RHD:

F79

and

M744

I

Harness for open or short
between ABS actuator
and electric unit and fus-
ible link

If NG, repair harness or
connector.

REPLACE.
Replace ABS actuator and electric unit.

q

B

REPLACE.
Replace fuse.
Does the fuse blow out when ignition
switch is turned ON?

No

E

Yes

Check the following.

I

Harness connector

F29

,

M822

, LHD:

F66

and

M787

, or RHD:

F76

:

,

F136

:

,

M743

:

and

M829

:

I

Harness for open or
short between ABS
actuator and electric unit
and fuse

If NG, repair harness or
connector.

END
Inspection end

NBR331

H

H

H

H

H

TROUBLE DIAGNOSES

Diagnostic Procedure 3 (ABS actuator solenoid
valve and solenoid valve relay) (Cont’d)

BR-72
